用opencv python 写一个排水管排水超过一分钟就产生报警的代码排泥通常是排出大量的水产生与上一帧图像差别超过百分之50的区别。报警方式选择声音报警使用winsoundBeep
下面是一个使用OpenCV和Python编写的排水管排水报警代码示例:
import cv2
import numpy as np
import winsound
def check_drainage(frame1, frame2):
# 计算两帧图像的差别
diff = cv2.absdiff(frame1, frame2)
diff_percentage = np.mean(diff) / 255 * 100
return diff_percentage > 50
def main():
# 打开摄像头
cap = cv2.VideoCapture(0)
# 读取初始帧
ret, frame1 = cap.read()
# 设置报警状态和计时器
alarm = False
timer = 0
while True:
# 读取当前帧
ret, frame2 = cap.read()
if not ret:
break
# 检查排水情况
if check_drainage(frame1, frame2):
if not alarm:
alarm = True
print("Drainage issue detected!")
# 使用winsound.Beep进行声音报警
winsound.Beep(1000, 2000) # 参数为频率和持续时间(毫秒)
else:
alarm = False
# 更新计时器
timer += 1
# 更新初始帧
frame1 = frame2
# 按下q键退出循环
if cv2.waitKey(1) & 0xFF == ord('q'):
break
# 如果排水超过一分钟,则重置计时器
if timer == 60:
timer = 0
# 释放摄像头和关闭窗口
cap.release()
cv2.destroyAllWindows()
if __name__ == '__main__':
main()
这个代码使用cv2.VideoCapture打开摄像头并读取帧,然后使用check_drainage函数计算当前帧与上一帧图像的差别百分比。如果差别超过50%,则触发报警并使用winsound.Beep进行声音报警。计时器用于检测排水超过一分钟的情况,如果超过一分钟,则重置计时器。按下q键可以退出循环。
请注意,这只是一个简单的示例代码,具体的应用场景可能需要更复杂的处理逻辑和参数调整
