timescale 1ns 1ps Company Engineer Create Date 211606 08032009 Design Name Module Name ctrl Project Name Target Devices Tool versions Description Dependencies Revision Revision 001

module MCtrl(input clk, input reset, input [31:0] Inst_in, input zero, input overflow, input MIO_ready, output reg MemRead, output reg MemWrite, output reg[2:0]ALU_operation, output [4:0]state_out,

            output reg CPU_MIO,
            output reg IorD,
            output reg IRWrite,
            output reg [1:0]RegDst,
            output reg RegWrite,
            output reg [1:0]MemtoReg,
            output reg ALUSrcA,
            output reg [1:0]ALUSrcB,
            output reg [1:0]PCSource,
            output reg PCWrite,
            output reg PCWriteCond,
            output reg Branch
            );

reg [4:0] state;

parameter IF = 5'b00000, ID=5'b00001, EX_R= 5'b00010, EX_Mem=5'b00011, EX_I= 5'b00100, Lui_WB=5'b00101, EX_beq=5'b00110, EX_bne= 5'b00111, EX_jr= 5'b01000, EX_JAL=5'b01001, Exe_J = 5'b01010, MEM_RD=5'b01011, MEM_WD= 5'b01100, WB_R= 5'b01101, WB_I=5'b01110, WB_LW=5'b01111, Error=11111;

parameter AND=3'b000, OR=3'b001, ADD=3'b010, SUB=3'b110, NOR=3'b100, SLT=3'b111, XOR=3'b011, SRL=3'b101;

`define CPU_ctrl_signals {PCWrite,PCWriteCond,IorD,MemRead,MemWrite,IRWrite,MemtoReg,PCSource,ALUSrcB,ALUSrcA,RegWrite,RegDst, CPU_MIO} // 1 0 0 0 0 0 10 10 00 0 0 00 0

assign state_out=state;

always @ (posedge clk or posedge reset) if (reset==1) begin CPU_ctrl_signals<=17'h12821; //12821 ALU_operation<=ADD; state <= IF; end else case (state) IF: begin if(MIO_ready)begin CPU_ctrl_signals<=17'h00060; ALU_operation<=ADD; state <= ID; end else begin state <=IF; `CPU_ctrl_signals<=17'h12821; end end

    ID: begin
        case (Inst_in[31:26])
        6'b000000:begin    //R-type OP
            `CPU_ctrl_signals<=17'h00010;
             state <= EX_R;
                 case (Inst_in[5:0])
                 6'b100000: ALU_operation<=ADD;  //R_add
                 6'b100010: ALU_operation<=SUB;  //R_sub
                 6'b100100: ALU_operation<=AND; //R_and
                 6'b100111: ALU_operation<=NOR; //R_nor
                 6'b000000: ALU_operation<=SLL;  //R_sll
                 6'b000010: ALU_operation<=SRL; //shfit 1bit right  R_srl
                 6'b001000: begin //R_jr
                                `CPU_ctrl_signals<=17'h10010;
                                ALU_operation<=ADD; state <= EX_jr;
                 end
                 default:  ALU_operation <= ADD;
                 endcase
        end

        6'b100011:begin //Lw ?
            `CPU_ctrl_signals<=17'h00050;
             ALU_operation<=ADD;
             state <= EX_Mem;
        end

        6'b101011:begin //Sw ?
            `CPU_ctrl_signals<=17'h00050;
            ALU_operation<=ADD;
            state <= EX_Mem;
        end

        6'b000010:begin //Jump  ?
            `CPU_ctrl_signals<=17'h10160;
            state <= Exe_J;
        end

        6'b000100:begin //Beq  I_beq
            `CPU_ctrl_signals<=17'h08090; Branch<=1;
            ALU_operation<= SUB; state <= EX_beq; end

        6'b000101:begin //Bne
            `CPU_ctrl_signals<=17'h08090; Branch<=0;
            ALU_operation<= SUB; state <= EX_bne;
        end

        6'b000011:begin //Jal  J_jal
            `CPU_ctrl_signals<=17'h1076c;
            state <= EX_JAL;
        end

        6'b001000:begin //Addi  I_addi
            `CPU_ctrl_signals<=17'h00050;
            ALU_operation <= ADD;
            state <= EX_I;
        end

        6'b001010:begin //Slti
            `CPU_ctrl_signals<=17'h00050;
                ALU_operation <= SLT;
                state <= EX_I;
        end

        6'b001111:begin //Lui
            `CPU_ctrl_signals<=17'h00468;
            state <= Lui_WB;
        end

        default: begin
            `CPU_ctrl_signals<=17'h12821;
            state <= Error;
            end
        endcase
    end     //end ID

    EX_Mem:begin
        if(Inst_in[31:26]==6'b100011)begin
            `CPU_ctrl_signals<=17'h06051; state <= MEM_RD; end
        else if(Inst_in[31:26]==6'b101011)begin
            `CPU_ctrl_signals<=17'h05051; state <= MEM_WD; end
    end

    MEM_RD:begin
        if(MIO_ready)begin
            `CPU_ctrl_signals<=17'h00208; state <= WB_LW; end
        else begin
            state <=MEM_RD; `CPU_ctrl_signals<=17'h06050; end
     end

    MEM_WD:begin
        if(MIO_ready)begin
            `CPU_ctrl_signals<=17'h12821;
            ALU_operation<=ADD; state <= IF; end
        else begin
            state <=MEM_WD; `CPU_ctrl_signals<=17'h05050; end
    end

    WB_LW:begin
        `CPU_ctrl_signals<=17'h12821;
        ALU_operation<=ADD; state <=IF; end

    EX_R:begin
            `CPU_ctrl_signals<=17'h0001a; state <= WB_R; end

    EX_I:begin
            `CPU_ctrl_signals<=17'h00058; state <= WB_I; end

    WB_R:begin
            `CPU_ctrl_signals<=17'h12821;
            ALU_operation<=ADD; state <= IF; end

    WB_I:begin
            `CPU_ctrl_signals<=17'h12821;
            ALU_operation<=ADD; state <= IF; end

    Exe_J:begin
            `CPU_ctrl_signals<=17'h12821;
            ALU_operation<=ADD; state <= IF; end

    EX_bne:begin
            `CPU_ctrl_signals<=17'h12821;
            ALU_operation<=ADD; state <= IF; end

    EX_beq:begin
            `CPU_ctrl_signals<=17'h12821;
            ALU_operation<=ADD; state <= IF; end

    EX_jr:begin
            `CPU_ctrl_signals<=17'h12821;
            ALU_operation<=ADD; state <= IF; end

    EX_JAL:begin
            `CPU_ctrl_signals<=17'h12821;
            ALU_operation<=ADD; state <= IF; end

    Lui_WB:begin
            `CPU_ctrl_signals<=17'h12821;
            ALU_operation<=ADD; state <= IF; end

    Error: state <= Error;
    default: begin
            `CPU_ctrl_signals<=17'h12821; Branch<=0;
            ALU_operation<=ADD; state <= Error; end
  endcase

endmodul
