要控制不同标记的旋转角度,可以通过为每个标记设置自定义的图标来实现。可以使用BitmapDrawable类来创建一个可旋转的图标,并将其设置为每个标记的图标。

以下是一个示例代码,展示如何通过自定义图标来控制标记的旋转角度:

// 创建一个自定义的OverlayItem类,用于存储标记的位置和其他信息
class CustomOverlayItem extends OverlayItem {
    private float rotation;

    public CustomOverlayItem(GeoPoint point, String title, String snippet, float rotation) {
        super(title, snippet, point);
        this.rotation = rotation;
    }

    public float getRotation() {
        return rotation;
    }

    public void setRotation(float rotation) {
        this.rotation = rotation;
    }
}

// 创建一个自定义的ItemizedIconOverlay类,用于加载和显示标记
class CustomItemizedIconOverlay extends ItemizedIconOverlay<CustomOverlayItem> {
    public CustomItemizedIconOverlay(Context context, List<CustomOverlayItem> items, OnItemGestureListener<CustomOverlayItem> listener) {
        super(context, items, listener);
    }

    @Override
    protected void draw(Canvas canvas, MapView mapView, boolean shadow) {
        super.draw(canvas, mapView, shadow);

        // 绘制每个标记的旋转角度
        for (CustomOverlayItem item : mItemList) {
            Drawable marker = item.getMarker(0); // 获取标记的图标
            float rotation = item.getRotation(); // 获取标记的旋转角度

            if (marker instanceof BitmapDrawable && rotation != 0) {
                BitmapDrawable bitmapDrawable = (BitmapDrawable) marker;
                Bitmap bitmap = bitmapDrawable.getBitmap();

                // 创建一个旋转后的图标
                Matrix matrix = new Matrix();
                matrix.postRotate(rotation);
                Bitmap rotatedBitmap = Bitmap.createBitmap(bitmap, 0, 0, bitmap.getWidth(), bitmap.getHeight(), matrix, true);

                // 绘制旋转后的图标
                canvas.save();
                canvas.translate(item.getPoint().getX() - (rotatedBitmap.getWidth() / 2), item.getPoint().getY() - (rotatedBitmap.getHeight() / 2));
                canvas.drawBitmap(rotatedBitmap, 0, 0, null);
                canvas.restore();
            }
        }
    }
}

// 创建一个自定义的OnItemGestureListener类,用于处理标记的点击事件等
class CustomItemGestureListener implements ItemizedIconOverlay.OnItemGestureListener<CustomOverlayItem> {
    // 处理标记的点击事件
    @Override
    public boolean onItemSingleTapUp(int index, CustomOverlayItem item) {
        // 处理标记的点击事件
        return true;
    }

    // 处理标记的长按事件
    @Override
    public boolean onItemLongPress(int index, CustomOverlayItem item) {
        // 处理标记的长按事件
        return false;
    }
}

// 在使用的地方,创建一个CustomItemizedIconOverlay对象,并设置每个标记的旋转角度
List<CustomOverlayItem> items = new ArrayList<>();
// 添加标记
items.add(new CustomOverlayItem(new GeoPoint(40.7128, -74.0060), "New York", "Snippet", 45)); // 设置旋转角度为45度
items.add(new CustomOverlayItem(new GeoPoint(34.0522, -118.2437), "Los Angeles", "Snippet", 90)); // 设置旋转角度为90度

CustomItemizedIconOverlay itemizedOverlay = new CustomItemizedIconOverlay(context, items, new CustomItemGestureListener());
mapView.getOverlays().add(itemizedOverlay); // 将Overlay添加到地图中显示

在这个示例中,我们扩展了ItemizedIconOverlay类,并重写了draw方法来绘制每个标记的旋转角度。在CustomOverlayItem类中,我们添加了一个rotation属性来存储每个标记的旋转角度。在CustomItemGestureListener类中,我们可以处理标记的点击和长按事件,根据需要自定义处理逻辑。

请注意,这只是一个示例代码,您可能需要根据自己的需求进行进一步的定制和调整

osmdroid 使用 ItemizedIconOverlayOverlayItem itemizedOverlays 批量加载标记 如何控制不同的标记的旋转角度?
