MNIST Handwritten Digit Classification using CNN with PyTorch

Here is the code to load the MNIST dataset, normalize the data, split it into training, validation, and testing sets, build a CNN network, and train it using PyTorch:

import torch
import torch.nn as nn
import torch.optim as optim
from torchvision import datasets, transforms
import matplotlib.pyplot as plt

# Set random seed for reproducibility
torch.manual_seed(42)

# Define batch size
batch_size = 64

# Load MNIST dataset and apply transformations
transform = transforms.Compose([
    transforms.ToTensor(),
    transforms.Normalize((0.1307,), (0.3081,))
])

train_dataset = datasets.MNIST(root='./data', train=True, transform=transform, download=True)
test_dataset = datasets.MNIST(root='./data', train=False, transform=transform)

# Split data into training, validation, and testing sets
train_size = int(0.8 * len(train_dataset))
val_size = len(train_dataset) - train_size
train_dataset, val_dataset = torch.utils.data.random_split(train_dataset, [train_size, val_size])

# Create data loaders
train_loader = torch.utils.data.DataLoader(train_dataset, batch_size=batch_size, shuffle=True)
val_loader = torch.utils.data.DataLoader(val_dataset, batch_size=batch_size, shuffle=True)
test_loader = torch.utils.data.DataLoader(test_dataset, batch_size=batch_size, shuffle=True)

# Define CNN model
class Net(nn.Module):
    def __init__(self):
        super(Net, self).__init__()
        self.conv1 = nn.Conv2d(1, 32, kernel_size=3)
        self.conv2 = nn.Conv2d(32, 64, kernel_size=3)
        self.dropout1 = nn.Dropout2d(0.25)
        self.dropout2 = nn.Dropout2d(0.5)
        self.fc1 = nn.Linear(64 * 12 * 12, 128)
        self.fc2 = nn.Linear(128, 10)

    def forward(self, x):
        x = self.conv1(x)
        x = nn.functional.relu(x)
        x = self.conv2(x)
        x = nn.functional.relu(x)
        x = nn.functional.max_pool2d(x, 2)
        x = self.dropout1(x)
        x = torch.flatten(x, 1)
        x = self.fc1(x)
        x = nn.functional.relu(x)
        x = self.dropout2(x)
        x = self.fc2(x)
        return x

# Create an instance of the CNN model
model = Net()

# Define loss function and optimizer
criterion = nn.CrossEntropyLoss()
optimizer = optim.Adam(model.parameters(), lr=0.001)

# Train the model
epochs = 10
train_losses = []
val_losses = []
train_accs = []
val_accs = []

for epoch in range(epochs):
    train_loss = 0.0
    val_loss = 0.0
    train_acc = 0.0
    val_acc = 0.0

    # Training phase
    model.train()
    for images, labels in train_loader:
        optimizer.zero_grad()
        output = model(images)
        loss = criterion(output, labels)
        loss.backward()
        optimizer.step()
        train_loss += loss.item() * images.size(0)
        _, predicted = torch.max(output.data, 1)
        train_acc += (predicted == labels).sum().item()

    # Validation phase
    model.eval()
    with torch.no_grad():
        for images, labels in val_loader:
            output = model(images)
            loss = criterion(output, labels)
            val_loss += loss.item() * images.size(0)
            _, predicted = torch.max(output.data, 1)
            val_acc += (predicted == labels).sum().item()

    # Calculate average loss and accuracy
    train_loss /= len(train_loader.dataset)
    val_loss /= len(val_loader.dataset)
    train_acc /= len(train_loader.dataset)
    val_acc /= len(val_loader.dataset)

    train_losses.append(train_loss)
    val_losses.append(val_loss)
    train_accs.append(train_acc)
    val_accs.append(val_acc)

    print(f'Epoch {epoch+1}/{epochs}, Train Loss: {train_loss:.4f}, Val Loss: {val_loss:.4f}, Train Acc: {train_acc:.4f}, Val Acc: {val_acc:.4f}')

# Test the model
model.eval()
test_acc = 0.0
with torch.no_grad():
    for images, labels in test_loader:
        output = model(images)
        _, predicted = torch.max(output.data, 1)
        test_acc += (predicted == labels).sum().item()

test_acc /= len(test_loader.dataset)
print(f'Testing Accuracy: {test_acc:.4f}')

# Plot training and validation losses
plt.figure()
plt.plot(range(1, epochs+1), train_losses, label='Train')
plt.plot(range(1, epochs+1), val_losses, label='Validation')
plt.xlabel('Epochs')
plt.ylabel('Loss')
plt.legend()
plt.show()

# Plot training and validation accuracies
plt.figure()
plt.plot(range(1, epochs+1), train_accs, label='Train')
plt.plot(range(1, epochs+1), val_accs, label='Validation')
plt.xlabel('Epochs')
plt.ylabel('Accuracy')
plt.legend()
plt.show()

This code will print the testing accuracy and plot the training loss, validation loss, training accuracy, and validation accuracy as a function of epochs.
