使用C++写出A算法
A*算法是一种启发式搜索算法,用于在图形或地图上寻找路径。它使用估价函数(启发式函数)来估计从当前节点到目标节点的最短距离,以帮助选择下一个要扩展的节点。
下面是使用C++实现A*算法的代码:
#include <iostream>
#include <queue>
#include <vector>
#include <cmath>
#include <unordered_map>
using namespace std;
//定义节点结构体
struct Node {
int x, y; //节点位置
int g, h; //g:从起点到当前节点的距离,h:从当前节点到终点的估价距离
Node* parent; //指向父节点
Node(int x, int y, int g, int h, Node* parent = nullptr) {
this->x = x;
this->y = y;
this->g = g;
this->h = h;
this->parent = parent;
}
int f() const { //计算f值
return g + h;
}
};
//定义哈希函数和相等函数
struct NodeHash {
size_t operator()(const Node* node) const {
return hash<int>()(node->x) ^ hash<int>()(node->y);
}
};
struct NodeEqual {
bool operator()(const Node* n1, const Node* n2) const {
return n1->x == n2->x && n1->y == n2->y;
}
};
//定义比较函数
struct NodeCompare {
bool operator()(const Node* n1, const Node* n2) const {
return n1->f() > n2->f();
}
};
//定义A*算法函数
vector<Node*> aStar(Node* start, Node* end, unordered_map<Node*, vector<Node*>>& graph) {
priority_queue<Node*, vector<Node*>, NodeCompare> openList; //用于存储未扩展的节点
unordered_map<Node*, int, NodeHash, NodeEqual> gScore; //用于存储从起点到各个节点的距离
unordered_map<Node*, Node*, NodeHash, NodeEqual> cameFrom; //用于存储每个节点的父节点
openList.push(start);
gScore[start] = 0;
while (!openList.empty()) {
Node* current = openList.top();
openList.pop();
if (current == end) { //找到终点,返回路径
vector<Node*> path;
while (current != nullptr) {
path.push_back(current);
current = current->parent;
}
reverse(path.begin(), path.end());
return path;
}
for (Node* neighbor : graph[current]) { //遍历当前节点的邻居节点
int tentativeGScore = gScore[current] + 1; //从起点到邻居节点的距离
if (gScore.find(neighbor) == gScore.end() || tentativeGScore < gScore[neighbor]) {
//如果该节点没有被访问过或发现更短的路径,则更新节点信息
gScore[neighbor] = tentativeGScore;
neighbor->parent = current;
openList.push(neighbor);
}
}
}
return vector<Node*>(); //无法到达终点,返回空路径
}
//定义估价函数,这里使用曼哈顿距离
int heuristic(int x1, int y1, int x2, int y2) {
return abs(x1 - x2) + abs(y1 - y2);
}
int main() {
int startX = 0, startY = 0;
int endX = 5, endY = 5;
unordered_map<Node*, vector<Node*>> graph;
//定义节点,并构建节点间的连接关系
for (int i = 0; i < 6; i++) {
for (int j = 0; j < 6; j++) {
Node* node = new Node(i, j, INT_MAX, heuristic(i, j, endX, endY));
if (i > 0) graph[node].push_back(new Node(i - 1, j, INT_MAX, heuristic(i - 1, j, endX, endY)));
if (i < 5) graph[node].push_back(new Node(i + 1, j, INT_MAX, heuristic(i + 1, j, endX, endY)));
if (j > 0) graph[node].push_back(new Node(i, j - 1, INT_MAX, heuristic(i, j - 1, endX, endY)));
if (j < 5) graph[node].push_back(new Node(i, j + 1, INT_MAX, heuristic(i, j + 1, endX, endY)));
}
}
Node* start = new Node(startX, startY, 0, heuristic(startX, startY, endX, endY));
Node* end = new Node(endX, endY, INT_MAX, 0);
vector<Node*> path = aStar(start, end, graph);
for (Node* node : path) {
cout << "(" << node->x << ", " << node->y << ")" << endl;
}
return 0;
}
该代码实现了一个6x6的网格地图上的A*算法,起点为(0,0),终点为(5,5)。使用曼哈顿距离作为估价函数,构建节点间的连接关系,然后调用aStar函数寻找最短路径。最后输出路径上的节点。
需要注意的是,该代码只是一个简单的示例,实际应用中需要根据具体情况进行修改和优化,例如使用更快的哈希函数和相等函数、选择合适的估价函数等。
