MACHINING_DATA.DEF

###############################################################################

Definitions File for Machining Data Database implemented in an ASCII text file

###############################################################################

REVISIONS:

00 23Mar99 Murthy R Mandaleeka Initial Version

01 26JUL99 Subhash Changed order of attributes

presented

02 29Oct99 Murthy R Mandaleeka Removed options

########################################################################## DB_PREFIX 'db(' DB_SUFFIX ')' ESS_PREFIX 'ess(' ESS_SUFFIX ')'

################################################################################

The list of DB_ALIAS

DB_ALIAS

{

DB_ID < identifier of parameter in a UG part file >

DB_ID_TYPE < Type of the identifier >

d _ double

i _ integer

s _ string

}

###############################################################################

DB_ALIAS libref { DB_ID LIBRF DB_ID_TYPE s DIALOG_NAME 'Speeds/Feeds Key' }

DB_ALIAS optype { DB_ID OPERTYPE DB_ID_TYPE s DIALOG_NAME 'Operation type ' RSET_NAME 'Cut Method' }

DB_ALIAS ptmtl { DB_ID PARTMAT DB_ID_TYPE s DIALOG_NAME 'Material Name' RSET_NAME 'Part Material'
}

DB_ALIAS tlmtl { DB_ID TOOLMAT DB_ID_TYPE s DIALOG_NAME 'Tool Material' RSET_NAME 'Tool Material' }

DB_ALIAS diam_in { DB_ID DIAM_IN DB_ID_TYPE d DIALOG_NAME 'Diam' RSET_NAME 'Diam - Inch' }

DB_ALIAS diam_mm { DB_ID DIAM_MM DB_ID_TYPE d DIALOG_NAME 'Diam' RSET_NAME 'Diam - mm' }

DB_ALIAS length_in { DB_ID LENGTH_IN DB_ID_TYPE d DIALOG_NAME 'Length' RSET_NAME 'Length - Inch' }

DB_ALIAS length_mm { DB_ID LENGTH_MM DB_ID_TYPE d DIALOG_NAME 'Length' RSET_NAME 'Length - mm' }

DB_ALIAS depthinch { DB_ID DPT_CUT_IN DB_ID_TYPE d DIALOG_NAME 'Depth' RSET_NAME 'Depth - Inch' }

DB_ALIAS depthmm { DB_ID DPT_CUT_MM DB_ID_TYPE d DIALOG_NAME 'Depth' RSET_NAME 'Depth - mm' }

DB_ALIAS stepover_in { DB_ID STEPOVER_IN DB_ID_TYPE d DIALOG_NAME 'Stepover' RSET_NAME 'Stepover - Inch' }

DB_ALIAS stepover_mm { DB_ID STEPOVER_MM DB_ID_TYPE d DIALOG_NAME 'Stepover' RSET_NAME 'stepover - mm' }

DB_ALIAS speedinch { DB_ID SURF_SPEED_FPM DB_ID_TYPE d DIALOG_NAME 'Speed' RSET_NAME 'Speed - Inch' }

DB_ALIAS speedmm { DB_ID SURF_SPEED_MPM DB_ID_TYPE d DIALOG_NAME 'Speed' RSET_NAME 'Speed - mm' }

DB_ALIAS feedinch { DB_ID FEED_IPT DB_ID_TYPE d DIALOG_NAME 'feed' RSET_NAME 'Feed - Inch' }

DB_ALIAS feedmm { DB_ID FEED_MMPT DB_ID_TYPE d DIALOG_NAME 'feed' RSET_NAME 'Feed - mm' }

DB_ALIAS approach_pct { DB_ID APPROACH_PCT DB_ID_TYPE i DIALOG_NAME 'Approach Percent' RSET_NAME 'Approach Percent' }

DB_ALIAS engage_pct { DB_ID ENGAGE_PCT DB_ID_TYPE i DIALOG_NAME 'Engage Percent' RSET_NAME 'Engage Percent' }

DB_ALIAS frstcut_pct { DB_ID FRSTCUT_PCT DB_ID_TYPE i DIALOG_NAME 'First Cut Percent' RSET_NAME 'First Cut Percent' }

DB_ALIAS stepover_pct { DB_ID STEPOVER_PCT DB_ID_TYPE i DIALOG_NAME 'Stepover Percent' RSET_NAME 'Stepover Percent' }

DB_ALIAS retract_pct { DB_ID RETRACT_PCT DB_ID_TYPE i DIALOG_NAME 'Retract Percent' RSET_NAME 'Retract Percent' }

DB_ALIAS return_pct { DB_ID RETURN_PCT DB_ID_TYPE i DIALOG_NAME 'Return Percent' RSET_NAME 'Return Percent' }

DB_ALIAS depart_pct { DB_ID DEPART_PCT DB_ID_TYPE i DIALOG_NAME 'Depart Percent' RSET_NAME 'Depart Percent' }

LIBREF optype

CLASS TECH_SETTINGS { TYPE TECH_SETTINGS QUERY '[1] == [1]' DIALOG libref optype ptmtl tlmtl depthinch speedinch feedinch RSET libref optype ptmtl tlmtl diam_in diam_mm length_in length_mm depthinch depthmm stepover_in stepover_mm speedinch speedmm feedinch feedmm approach_pct engage_pct frstcut_pct stepover_pct retract_pct return_pct depart_pct UI_NAME 'CAM Machining Data Library'
