本模具是一套6个工位带料级进模图41完成冲孔、落料、废料切除；采用自动送料机送料适用于大批量生产时选用条料自动送料装置。步距295mm模具长350mm宽280mm。模具结构见图凸模固定板与卸料板间距离为17mm模具整体闭合高度为200mm。改写降重

This mold is a set of 6 stations with material level feeding and progressive die (Figure 4.1), which completes punching, blanking, and waste removal. It uses an automatic feeding machine for feeding and is suitable for selecting automatic feeding devices for strip materials when mass production is required. The step distance is 29.5mm, the mold length is 350mm, and the width is 280mm. The mold structure is shown in the diagram.

The distance between the punch fixed plate and the discharge plate is 17mm, and the overall closing height of the mold is 200mm. Revised for simplification:

This mold has 6 stations and uses material level feeding and a progressive die to complete punching, blanking, and waste removal. It is suitable for mass production with automatic feeding machines for strip materials. The mold has a step distance of 29.5mm, a length of 350mm, and a width of 280mm. The punch fixed plate and discharge plate are 17mm apart, and the mold's overall closing height is 200mm
