RS232 and RS485 serial information in EnglishRS232 and RS485 serial information1 RS232 specifications introductionCommunication as defined in the RS232 standard is an asynchronous serial communicatio

tream for error checking, which reduces the available bandwidth for actual data transfer.

3 RS485 specifications, introduction

The RS485 standard is also a serial communication method, but it is designed for communication over longer distances and with multiple devices on the same bus. It uses differential signaling, which means that instead of using a single wire for each signal, it uses two wires with opposite voltages to represent a signal. This reduces the susceptibility to noise and allows for longer cable lengths. RS485 also supports half-duplex communication, which means that data can be sent in both directions, but not at the same time.

4 RS485 communication

RS485 communication is based on a master-slave architecture, where one device acts as the master and controls the communication on the bus. The other devices are slaves and can only send data when requested by the master. The master device sends a message to a specific slave or to all slaves on the bus, and the addressed slave responds with its data. The master then collects the data from all the slaves and interprets it.

5 RS232 vs RS485

RS232 and RS485 are both serial communication methods, but they have different applications. RS232 is typically used for communication between a computer and a peripheral device, such as a printer or modem, over short distances. RS485 is used for communication between multiple devices over longer distances, such as in industrial automation or building automation systems. RS485 also supports multiple devices on the same bus, while RS232 is typically a point-to-point communication
