The Point coal plugging switch English manualDREXELBROOKA Leader In Level Measurement SolutionsThePoint RFSeriesPoint Level Switch for Plugged Chute DetectionEliminate Costly Plugged Chuteswith Drexe

ting or buildup on the sensor, ensuring reliable and accurate detection of plugged chutes.

Installation and Operation:

The Point coal plugging switch is designed for easy installation and operation. Follow these steps to ensure proper installation:

1. Ensure power is disconnected before installation.

2. Mount the sensor flush to the chute wall using the provided mounting hardware.

3. Connect the wiring from the sensor to the control unit.

4. Power on the unit and set the sensitivity level according to your application.

5. The system is now ready to detect plugged chutes and provide alerts as needed.

Note: Regular maintenance and cleaning of the sensor is recommended to ensure optimal performance.

For further information or assistance with installation and operation, please refer to the user manual or contact Drexelbrook’s technical support team
