Light source English manual 180OPERATION INSTRUCTIONXD-180 LAMP COLD LIGHT SOURCECONTENTSⅠGeneral Introduction···························P2ⅡCharacter Summary·························P2Ⅲ Main technical

onduction interference to the light source, the light source uses the independent electric circuit system, has the electromagnetic compatibility.Good cooling system, the fan can effectively cool down the heat of the light bulb, and extend the service life of the light bulb.3. The light source is compact in structure, easy to use, and can be used with various endoscopes, surgical instruments, and medical equipment. It is an ideal supplementary light source for medical endoscopes and other equipment that requires light.Ⅲ. Main technical parametersInput voltage: AC220V, 50HzInput power: 180WFuse: AC250V, 2.5AOutput power: 150W / 250WLight source: xenon lampLuminous flux: 8000LMColor temperature: 5600KService life: 500 hoursCooling system: forced air coolingNoise: ≤ 50dB(A)Dimensions: 300mm×200mm×140mmWeight: 4.5kgⅣ.Working Conditions1. Power supply voltage: AC220V, 50Hz2. Ambient temperature: 0-40°C3. Relative humidity: ≤ 80%4. Atmospheric pressure: 860hPa~1060hPa5. The installation location should avoid direct sunlight, strong magnetic fields, and vibrations.Ⅴ. Basic Components and configuration1. Light source main unit2. Power cord3. Spare fuse4. User manualⅥ.Operation description1. Connect the power cord to the socket on the back of the light source, and then connect the power cord to the AC220V power supply.2. Turn on the power switch on the front panel of the light source to start the light source.3. Adjust the brightness knob to adjust the brightness of the light source.4. When the light source is not in use, turn off the power switch and unplug the power cord from the power supply.Ⅶ. Notice1. Do not touch the light bulb when the light source is turned on, so as to avoid burns.2. Do not use the light source in a humid environment to avoid electric shock.3. When using the light source, pay attention to the heat dissipation of the light bulb to avoid damage to the light bulb due to overheating.4. When replacing the light bulb, be sure to turn off the power and wait for the light bulb to cool down before replacing it.5. Do not disassemble the light source by yourself.6. If the light source fails, please contact the manufacturer or professional maintenance personnel for repair.Ⅷ.Change the lamp1. Turn off the power switch and unplug the power cord from the power supply.2. Remove the lamp cover from the back of the light source.3. Remove the old lamp from the lamp holder and replace it with a new lamp.4. Install the lamp cover and tighten the screws.5. Connect the power cord to the power supply and turn on the power switch.Ⅸ.TroubleshootingFault phenomenonPossible causeSolutionThe light source does not work after power onThe power cord is not connected properlyConnect the power cord properlyThe fuse is blownReplace the fuseThe light bulb is damagedReplace the light bulbThe brightness is too lowThe brightness knob is not adjusted properlyAdjust the brightness knobThe light bulb is agingReplace the light bulbThe fan is not working properlyCheck the fan and replace it if necessaryThe color temperature is abnormalThe light bulb is agingReplace the light bulbThe wrong light bulb is usedReplace with the correct light bulbThe brightness is unstableThe power supply voltage is unstableCheck the power supply voltageThe light bulb is agingReplace the light bulbThe light source is affected by the high frequency interferenceChange the installation location or install an electromagnetic interference filter
