wellcat load presentation English versionCustom Load Tube Custom Load has tabs you use to specify density pressure and temperature profiles inside and outside the current string that are not available

log box are used for this load case. Fields and Controls Tubing Weight The weight of the tubing per unit length. Buoyancy Factor The ratio of the density of the fluid in the tubing to the density of the fluid in the annulus. Overpull Force The force applied to the tubing in addition to the air weight of the tubing. Operation or Load This drop-down list box has the names of all loads or operations defined for the current string that can be linked to other loads. Selecting one of these items allows the code to use the temperature profile from the item as initial temperature conditions for the current load case. Compression (Tube) This load case models compression in the tubing string due to the weight of the fluid in the tubing. The temperatures specified on the Initial Conditions dialog box are used for this load case. Fields and Controls Tubing Weight The weight of the tubing per unit length. Operation or Load This drop-down list box has the names of all loads or operations defined for the current string that can be linked to other loads. Selecting one of these items allows the code to use the temperature profile from the item as initial temperature conditions for the current load case. Compression (Annulus) This load case models compression in the annulus due to the weight of the fluid in the annulus. The temperatures specified on the Initial Conditions dialog box are used for this load case. Fields and Controls Annulus Weight The weight of the fluid in the annulus per unit length. Operation or Load This drop-down list box has the names of all loads or operations defined for the current string that can be linked to other loads. Selecting one of these items allows the code to use the temperature profile from the item as initial temperature conditions for the current load case
