GALAXY PW test manual in EnglishTest ManualofUninterrupted Power SupplyRevision HistoryRevisionChangesCommentsPrepared ByDate10AllLiu Cuitian2008-05-15 Contents1

Supply PanelN/A7. Design Drawing of UPSN/A8. Design Drawing of Battery CabinetN/A3 Purpose of TestThe purpose of this test is to verify that the MGE Galaxy PW UPS has been installed correctly and is functioning properly. This test will also ensure that the UPS is capable of providing uninterrupted power supply to the connected loads.4 Instruments and ToolsThe following instruments and tools are required for the test:1. Multimeter2. Clamp meter3. Oscilloscope4. IR thermometer5. Torque wrench6. Screwdriver7. Insulation resistance tester8. Load bank (if necessary)9. Laptop computer with appropriate software for UPS parameter monitoring and control5 AbbreviationsAbbreviationDescriptionACAlternating CurrentDCDirect CurrentUPSUninterrupted Power SupplyEMSElectromagnetic InterferencePFPower FactorPMPulse ModulationTHDTotal Harmonic Distortion6 Preparations before TestBefore the test, the following preparations should be made:1. Ensure that the UPS has been installed according to the manufacturer's instructions.2. Check the connections of the input and output power, battery, and communication cables.3. Verify that the UPS is properly grounded.4. Ensure that all equipment connected to the UPS is turned off.5. Make sure that the UPS batteries are fully charged.6. Verify that the bypass switch is in the "Normal" position.7. Verify that the emergency off switch is in the "Off" position.8. Verify that the maintenance bypass switch is in the "Normal" position.9. Ensure that the UPS is in standby mode.10. Ensure that the UPS software is installed and configured on the laptop computer.7 Inspection & Test7.1 Operation Condition InspectionCheck the operation condition of the UPS by verifying the following:1. The UPS is turned on and functioning properly.2. The UPS display shows no error messages.3. The UPS fans are working properly.4. The UPS batteries are fully charged.5. The UPS is in standby mode.6. The UPS is not overloaded.7.2 Installation InspectionCheck the installation of the UPS by verifying the following:1. The UPS is installed according to the manufacturer's instructions.2. The input and output power cables are connected properly.3. The battery cables are connected properly.4. The communication cables are connected properly.5. The UPS is properly grounded.7.3 Energizing PreparationBefore energizing the UPS, verify the following:1. The bypass switch is in the "Normal" position.2. The emergency off switch is in the "Off" position.3. The maintenance bypass switch is in the "Normal" position.4. All equipment connected to the UPS is turned off.5. The UPS batteries are fully charged.6. The UPS is in standby mode.7. The UPS software is installed and configured on the laptop computer.7.4 Check of UPS ParametersCheck the UPS parameters by performing the following steps:1. Connect the laptop computer to the UPS.2. Start the UPS software on the laptop computer.3. Monitor the UPS parameters, including input and output voltage and frequency, battery voltage and temperature, and load status.4. Verify that the UPS parameters are within the specified range.7.5 Test of On-line ModeTest the on-line mode of the UPS by performing the following steps:1. Connect a load bank to the UPS output.2. Turn on the load bank.3. Verify that the UPS switches to on-line mode.4. Monitor the UPS parameters, including input and output voltage and frequency, battery voltage and temperature, and load status.5. Verify that the UPS parameters are within the specified range.7.6 Shutdown and Start-up of InverterTest the shutdown and start-up of the inverter by performing the following steps:1. Turn off the load bank.2. Verify that the UPS switches to standby mode.3. Turn on the load bank again.4. Verify that the UPS switches to on-line mode.7.7 Maintenance BypassTest the maintenance bypass of the UPS by performing the following steps:1. Turn off the load bank.2. Turn the maintenance bypass switch to the "Bypass" position.3. Verify that the UPS switches to bypass mode.4. Turn on the load bank.5. Verify that the UPS supplies power to the load bank in bypass mode.7.8 Emergency OffTest the emergency off of the UPS by performing the following steps:1. Press the emergency off button.2. Verify that the UPS shuts down immediately.7.9 Data MeasureMeasure the following parameters using the instruments and tools listed in Section 4:1. Input and output voltage and frequency2. Battery voltage and temperature3. Load current and power factor4. Inverter efficiency and THD8 Appendix 1 - General Characteristics of MGE Galaxy PW UPSThe following table lists the general characteristics of MGE Galaxy PW UPS:ModelGalaxy PW 20kvaGalaxy PW 30kvaGalaxy PW 40kvaGalaxy PW 60kvaGalaxy PW 80kvaInputVoltage range380/400/415VAC±20%Frequency range40-70HzPower factor>0.99OutputVoltage range380/400/415VAC±1%Frequency range50/60Hz±0.1%Power factor0.9Efficiency>94%BatteryTypeValve-regulated lead-acid batteryBackup time10-15 minutes (full load)Charge time6 hoursCommunicationInterfaceRS232, SNMP, dry contactDimensions(W×D×H)480×860×1330mmWeight(kg)2853603805506509 Appendix 2 - Test Report of MGE Galaxy PW UPSThe test report should include the following information:1. Model and serial number of the UPS2. Date and time of the test3. Name of the tester4. Test results, including all parameters measured during the test5. Any abnormalities or issues encountered during the test6. Signature of the tester and approval of the superviso
