动物植物识别小程序 - 图片识别结果可视化
<template>
<view>
<view class='radio-list'>
<view style='color: #DD524D;'> 请选择类别：默认为通用识别</view>
<radio-group class='radioG' @change='radioChange'>
<label class='radioR' v-for='(item, index) in radioItems' :key='item.value'>
<view>
<radio :value='item.value' :checked='item.checked' />
</view>
<view> {{item.name}} </view>
</label>
</radio-group>
<pre><code> </view>
<view class='line'></view>
<view class='content'>
<!-- 选择图片区域 -->
<button class='name-btn' type='primary' @click='imgAdd'>选择图片</button>
<view class='images_box'>
<image class='img' :src='imgTempUrl' mode='aspectFill'></image>
</view>
<!-- 按钮区域 -->
<!-- <button class='btn' type='primary' @click='getToken'>上传识别</button> -->
<button class='name-btn' type='primary' @click='getResult'>获取结果</button>
<!-- 识别结果 -->
<view class='txt' v-for='(item, index) in resItems' :key='item.value'>
<text>有 {{ (item.score * 100).toFixed(1) }}% 概率是{{item.keyword}}{{item.name}} </text>
</view>
<!-- 柱状图展示区域 -->
<view v-if='resItems.length > 0'>
<canvas canvas-id='myChart' style='width: 750rpx; height: 400rpx;'></canvas>
</view>
</view>
</view>
</code></pre>
</template>
<script>
//定义本页用到的变量
import {
pathToBase64,
base64ToPath
} from 'image-tools'
var base64Img = ''
var id = 'eXAZRzuo7xUvp7RWEp0iazRK'
var secret = 'htZFOc5V9rzR4cXFqtysj3T1FnLUMwOL'
var typeUrl = 'https://aip.baidubce.com/rest/2.0/image-classify/v2/advanced_general?access_token=' //默认是动物识别
export default {
data() {
return {
type: 0,
imgTempUrl: '',
resItems: [],
radioItems: [{
value: 0,
name: '动物识别',
checked: false
},
{
value: 1,
name: '植物识别',
checked: false
}
],
}
},
// 分享给朋友
onShareAppMessage: function() {},
//分享到朋友圈
onShareTimeline: function() {},
methods: {
radioChange(e) {
//console.log(e.detail.value)
this.type = e.detail.value
if (this.type == 0) { //动物识别
typeUrl = 'https://aip.baidubce.com/rest/2.0/image-classify/v1/animal?access_token='
}
if (this.type == 1) { //植物识别
typeUrl = 'https://aip.baidubce.com/rest/2.0/image-classify/v1/plant?access_token='
}
},
//选择图片
imgAdd() {
// wx.chooseImage({
// count: 1,
// sizeType: ['original', 'compressed'],
// sourceType: ['album', 'camera'],
// success: (res) => {
// this.imgTempUrl = res.tempFilePaths[0]
// this.getB64ByUrl(this.imgTempUrl) //调用方法并传入参数
// }
// })
uni.chooseImage({
count: 1, //默认9
sizeType: ['original', 'compressed'], //可以指定是原图还是压缩图，默认二者都有。
sourceType: ['album', 'camera'], //从相册选择。
success: (res) => {
console.log('res-----------------------------------------------', res);
// 之前的方法 小程可用 APP不可用
// let base64Img = uni.getFileSystemManager().readFileSync(res.tempFilePaths[0], 'base64'); //转码
// 都可以用
this.imgTempUrl = res.tempFilePaths[0]
pathToBase64(res.tempFilePaths[0])
.then(path => {
uni.setStorageSync('base64I', path)
})
.catch(error => {
console.error(error)
})
// const arrayBuffer = new Uint8Array(res.tempFilePaths[0]); //先将本地图片路径转换成array类型
// const base64Img = uni.arrayBufferToBase64(arrayBuffer); //再转换成base64类型
// uni.setStorageSync('base64I', base64Img)
// console.log(base64Img) //成品就在这里了
},
fail(err) {
}
});
},
plantTap() {
let that = this
this.getToken(function(token) { //先调用getToken方法得到token,再传入getResult方法中运行
// getResult()
});
},
getToken: function(callback) { //回调函数，要有返回值
uni.showLoading({
title: '加载中'
});
uni.request({
method: 'POST',
url: 'https://aip.baidubce.com/oauth/2.0/token?client_id=eXAZRzuo7xUvp7RWEp0iazRK&client_secret=htZFOc5V9rzR4cXFqtysj3T1FnLUMwOL&grant_type=client_credentials',
data: {},
header: {
'Content-Type': 'application/json',
'Accept': 'application/json', // 默认值
},
success(res) {
//console.log(res)
uni.setStorageSync('token', res.data.access_token)
// var token = res.data.access_token
// return callback(token) //返回值
uni.hideLoading();
},
fail(err) {
console.log('错误', err)
}
});
},
getResult: function() {
let that = this
uni.showLoading({
title: '结果获取中'
});
uni.request({
url: typeUrl + uni.getStorageSync('token'),
method: 'post',
data: {
image: uni.getStorageSync('base64I')
},
header: {
'content-type': 'application/x-www-form-urlencoded' // 默认值
},
success(res) {
console.log(res.data)
that.resItems = res.data.result
uni.hideLoading();
// 生成柱状图
this.drawChart(that.resItems);
}
}) // 此处为生成柱状图代码
},
// 柱状图生成方法
drawChart(data) {
const ctx = uni.createCanvasContext('myChart');
// 数据处理，提取识别结果的名称和得分
const labels = data.map(item => item.keyword + item.name);
const scores = data.map(item => (item.score * 100).toFixed(1));
// 设置柱状图样式
ctx.setFillStyle('#007AFF');
ctx.setStrokeStyle('#007AFF');
ctx.setFontSize(12);
// 计算柱状图宽度和间距
const barWidth = 30;
const barSpacing = 20;
// 绘制柱状图
data.forEach((item, index) => {
const x = index * (barWidth + barSpacing) + 20;
const y = 300 - (item.score * 100);
ctx.fillRect(x, y, barWidth, (item.score * 100));
ctx.strokeRect(x, y, barWidth, (item.score * 100));
ctx.fillText(scores[index] + '%', x + barWidth / 2, y - 10);
});
// 绘制X轴标签
ctx.fillText('识别结果', 20, 350);
labels.forEach((label, index) => {
const x = index * (barWidth + barSpacing) + barWidth / 2 + 20;
ctx.fillText(label, x, 380);
});
ctx.draw();
}
}
}
</script>
<style>
.radio-list {
margin-left: 3.3%;
}
.radioG {
display: flex;
flex-direction: row;
flex-wrap: wrap;
justify-content: flex-start;
}
.radioR {
display: flex;
flex-direction: row;
margin: 5rpx;
}
.line {
border-top: 1rpx;
border-top-style: solid;
border-color: #007AFF;
}
.content {
display: flex;
flex-direction: column;
align-items: center;
justify-content: center;
}
.images_box {
border: 1rpx;
border-style: solid;
border-color: rgba(0, 0, 0, 0.452);
width: 98%;
height: 496rpx;
margin: 10rpx;
position: relative;
}
.img {
width: 100%;
height: 100%;
}
.txt {
margin: 10px;
font-size: 20px;
color: #007AFF;
}
.name-btn{
background-color: #007AFF;
border-radius: 100upx;
height: 80upx;
width: 550upx;
line-height: 80upx;
color: #FFFFFF;
margin: 10px;
}
</styl
