智能家居设备状态监控与建议系统

本文介绍一个基于 C 语言、SQLite 数据库和网络通信的智能家居设备状态监控与建议系统。该系统能够接收用户设备的状态信息，并根据预设规则生成相应的建议，例如空调温度过高或过低时，建议用户调整温度。

服务器端代码c#include <stdio.h>#include <stdlib.h>#include <string.h>#include <unistd.h>#include <sys/socket.h>#include <sys/select.h>#include <arpa/inet.h>#include <sqlite3.h>

#define MAX_BUFFER_SIZE 1024

typedef struct { int uid; char device_name[10]; char device_state[10]; char value[10]; char mode[10];} Status;

typedef struct { int sockfd; struct sockaddr_in client_addr; socklen_t client_addr_len; sqlite3 *db;} ServerContext;

void handleClientRequest(ServerContext *context) { char buffer[MAX_BUFFER_SIZE]; int userid;

// 接收客户端发送的userid    ssize_t recvSize = recv(context->sockfd, &userid, sizeof(int), 0);    if (recvSize == -1) {        perror('userid接受失败

recv'); return; } userid = ntohl(userid); // 转换为主机字节序 printf('客户端已连接 '); printf('userid:%d',userid); // 查询数据库获取设备状态信息 char sql[100]; snprintf(sql, sizeof(sql), 'SELECT * FROM Status WHERE uid = %d', userid); sqlite3_stmt *stmt; int rc = sqlite3_prepare_v2(context->db, sql, -1, &stmt, NULL); if (rc != SQLITE_OK) { fprintf(stderr, '无法执行的语句: %s ', sqlite3_errmsg(context->db)); return; }

Status status;    memset(&status, 0, sizeof(Status)); // 清空status结构体    while (sqlite3_step(stmt) == SQLITE_ROW) {        status.uid = sqlite3_column_int(stmt, 1);        printf('%d',status.uid);        strncpy(status.device_name, sqlite3_column_text(stmt, 2), sizeof(status.device_name));        printf('%s',status.device_name);        strncpy(status.device_state, sqlite3_column_text(stmt, 3), sizeof(status.device_state));        strncpy(status.value, sqlite3_column_text(stmt, 4), sizeof(status.value));        strncpy(status.mode, sqlite3_column_text(stmt, 5), sizeof(status.mode));    }    int columnCount = sqlite3_column_count(stmt);      printf('列数：%d

', columnCount); if (sqlite3_column_count(stmt) == 0) { fprintf(stderr, '查询结果为空 '); return; } sqlite3_finalize(stmt);

if (strlen(status.device_name) == 0) {        perror('接收设备状态信息失败');        return;    }

// 分析设备状态并生成建议    char suggestion[MAX_BUFFER_SIZE];    if (strcmp(status.device_name, '空调') == 0) {        int temperature = atoi(status.value);        if (temperature < 24) {            snprintf(suggestion, sizeof(suggestion), '空调温度过低，建议提高温度至26℃');        } else {            snprintf(suggestion, sizeof(suggestion), '空调温度正常');        }    } else if (strcmp(status.device_name, '加湿器') == 0) {        int humidity = atoi(status.value);        if (humidity < 40 || humidity > 70) {            snprintf(suggestion, sizeof(suggestion), '加湿器湿度过高或过低，建议调整加湿器湿度');        } else {            snprintf(suggestion, sizeof(suggestion), '加湿器湿度正常');        }    } else {        snprintf(suggestion, sizeof(suggestion), '设备状态未知');    }

// 向客户端发送建议    ssize_t sendSize = send(context->sockfd, suggestion, strlen(suggestion), 0);    if (sendSize == -1) {        perror('发送失败

send'); return; } printf('%s',suggestion);}

int main() { printf('正在连接中... '); int sockfd = socket(AF_INET, SOCK_STREAM, 0); if (sockfd == -1) { perror('连接失败 socket'); return 1; }

struct sockaddr_in server_addr;    server_addr.sin_family = AF_INET;    server_addr.sin_addr.s_addr = INADDR_ANY;    server_addr.sin_port = htons(12345);

if (bind(sockfd, (struct sockaddr *)&server_addr, sizeof(server_addr)) == -1) {        perror('连接失败

bind'); close(sockfd); return 1; }

if (listen(sockfd, 5) == -1) {        perror('连接失败

listen'); close(sockfd); return 1; }

sqlite3 *db;    int rc = sqlite3_open('/mnt/g/Qt/Client/Smarthome_Client/database/database.db', &db);    if (rc != SQLITE_OK) {        fprintf(stderr, '数据库打开失败: %s

', sqlite3_errmsg(db)); return 1; }

ServerContext context;    context.sockfd = sockfd;    context.client_addr_len = sizeof(context.client_addr);    context.db = db;

fd_set readfds;    int maxfd = sockfd;

while (1) {        FD_ZERO(&readfds);        FD_SET(sockfd, &readfds);

    int activity = select(maxfd + 1, &readfds, NULL, NULL, NULL);        if (activity == -1) {            perror('select');            break;        }

    if (FD_ISSET(sockfd, &readfds)) {            int clientSockfd = accept(sockfd, (struct sockaddr *)&context.client_addr, &context.client_addr_len);            if (clientSockfd == -1) {                perror('套接字接收失败

accept'); break; }

        context.sockfd = clientSockfd;            handleClientRequest(&context);

        close(clientSockfd);        }    }    sqlite3_close(db);    close(sockfd);    printf('服务器已关闭

');

return 0;}

客户端代码cpp#include 'procession.h'#include 'ui_procession.h'#include #include

Procession::Procession(int userid,QWidget *parent) : QWidget(parent), ui(new Ui::Procession), userid(userid){ ui->setupUi(this); processionWidget(); m_socket = new QTcpSocket(this); //connect(ui->connectBtn, &QPushButton::clicked, this, &Procession::on_connectBtn_clicked); connect(m_socket, &QTcpSocket::readyRead, this, &Procession::readyRead); connect(m_socket, &QTcpSocket::connected, this, &Procession::connected); connect(m_socket, &QTcpSocket::disconnected,this,&Procession::disconnected); connect(m_socket, QOverloadQAbstractSocket::SocketError::of(&QTcpSocket::error), this, &Procession::displayError);}

Procession::~Procession(){ delete ui;}

void Procession::processionWidget(){ setWindowTitle('服务器通信'); setAutoFillBackground(true); QPalette palette=this->palette(); QPixmap pixmap(':/user/image/image/net.jpg'); palette.setBrush(QPalette::Window, QBrush(pixmap)); setPalette(palette); setFixedSize(600,400);}

void Procession::connected(){ ui->message->append('连接成功'); int userid = this->userid; userid = htonl(userid); // 转换为网络字节序 QByteArray block; block.append(reinterpret_cast<char*>(&userid), sizeof(userid)); if (m_socket->write(block) == -1) { ui->message->append('发送userid失败'); m_socket->close(); }}

void Procession::disconnected(){ ui->message->append('连接失败'); m_socket->close();}

void Procession::readyRead(){ QByteArray data = m_socket->readAll(); if (data.isEmpty()) { ui->message->append('读取的数据为空'); return; } // 解析服务器返回的数据 QString suggestion = QString::fromUtf8(data); if (suggestion.isEmpty()) { ui->message->append('解析服务器返回的数据失败'); return; } ui->message->append(suggestion); m_socket->close();}

void Procession::displayError(QAbstractSocket::SocketError error){ QString errorMessage; switch (error) { case QAbstractSocket::ConnectionRefusedError: errorMessage = '连接被拒绝'; break; case QAbstractSocket::RemoteHostClosedError: errorMessage = '远程主机关闭'; break; case QAbstractSocket::HostNotFoundError: errorMessage = '未找到主机'; break; case QAbstractSocket::SocketTimeoutError: errorMessage = '连接超时'; break; case QAbstractSocket::NetworkError: errorMessage = '网络错误'; break; default: errorMessage = '未知错误'; break; } ui->message->append('连接失败：' + errorMessage);}

void Procession::on_connectBtn_clicked(){ if (m_socket->state() == QAbstractSocket::ConnectedState) { m_socket->disconnectFromHost(); // 先关闭套接字 qDebug()<<'1'; }

ui->message->append('已经连接上服务器');    QString ip = ui->IP->text();    QString port = ui->port->text();

if (ip.isEmpty() || port.isEmpty()) {        ui->message->clear();        ui->message->append('请输入有效的IP地址和端口号');        return;    }

ui->message->clear();    ui->message->append('正在连接中...');    m_socket->connectToHost(ip, static_cast<quint16>(ui->port->text().toInt()));}

#ifndef PROCESSION_H#define PROCESSION_H

#include #include #include #include #include

namespace Ui {class Procession;}

class Procession : public QWidget{ Q_OBJECT

public: explicit Procession(int userid,QWidget *parent = nullptr); ~Procession(); void processionWidget();

private slots: //void on_pushButton_clicked(); void connected(); void disconnected(); void readyRead(); void displayError(QAbstractSocket::SocketError error);

void on_connectBtn_clicked();

private: Ui::Procession ui; int userid; QTcpSocket m_socket;};

#endif // PROCESSION_H

使用说明

  1. 将服务器端代码编译成可执行文件，例如 smarthome_server。2. 将客户端代码编译成可执行文件，例如 smarthome_client。3. 确保 database.db 文件存在于服务器端代码指定的目录下，并创建 Status 表，表结构如下：sqlCREATE TABLE Status ( id INTEGER PRIMARY KEY AUTOINCREMENT, uid INTEGER, device_name TEXT, device_state TEXT, value TEXT, mode TEXT);

  2. 运行服务器端程序，例如 ./smarthome_server。5. 运行客户端程序，输入服务器 IP 地址和端口号（默认端口号为 12345）。6. 客户端将向服务器发送 userid，服务器将查询数据库获取对应设备的状态信息，并生成建议返回给客户端。

注意事项

  • 客户端代码中的 :/user/image/image/net.jpg 需要替换成实际的图片文件路径。- 服务器端代码中使用的数据库路径需要根据实际情况进行修改。- 该系统仅为示例，用户可以根据自己的需求进行扩展和修改。

总结

本系统使用 C 语言、SQLite 数据库和网络通信技术实现了智能家居设备状态监控与建议的功能，能够帮助用户了解设备状态并获得相应的建议，提升用户体
