MATLAB 亚像素边缘检测：基于Zernike矩的图像轮廓提取

以下是使用MATLAB编写的计算Zernike矩和进行边缘检测的代码：

% 计算Zernike矩
function [Z00, Z11, Z20, Z31, Z40] = calculateZernikeMoments(image)
    [rows, cols] = size(image);
    [x, y] = meshgrid(1:cols, 1:rows);
    rho = sqrt((2*x-cols-1).^2 + (2*y-rows-1).^2) / rows;
    theta = atan2((rows-1-2*y+2), (2*x-cols+1-2));

    Z00 = sum(sum(image)) / (rows*cols);
    Z11 = sqrt(2) * sum(sum(image .* rho .* exp(1i*theta))) / (rows*cols*Z00);
    Z20 = sqrt(2) * sum(sum(image .* (2*rho.^2-1))) / (rows*cols*Z00);
    Z31 = sqrt(2) * sum(sum(image .* rho .* exp(1i*theta) .* (3*rho.^2-2))) / (rows*cols*Z00);
    Z40 = sqrt(2) * sum(sum(image .* (6*rho.^4 - 6*rho.^2 + 1))) / (rows*cols*Z00);
end

% 进行边缘检测
function [edgeMap, subpixelEdges] = detectEdges(image, kt, lt)
    [Z00, Z11, Z20, Z31, Z40] = calculateZernikeMoments(image);

    [rows, cols] = size(image);
    edgeMap = zeros(rows, cols);
    subpixelEdges = [];

    for i = 1:rows
        for j = 1:cols
            ReZ31 = real(Z31);
            ImZ31 = imag(Z31);

            phi = atan2(ImZ31(i, j), ReZ31(i, j));

            ReZn1 = real(Zn1);
            ImZn1 = imag(Zn1);

            l1 = sqrt((5*ReZ40(i, j)+3*ReZ20(i, j)) / (8*ReZ20(i, j)));
            l1_prime = -sqrt((5*ReZ40(i, j)+3*ReZ20(i, j)) / (8*ReZ20(i, j)));
            l2 = sqrt((5*ReZ31(i, j)+ReZ11(i, j)) / (6*ReZ11(i, j)));
            l2_prime = -sqrt((5*ReZ31(i, j)+ReZ11(i, j)) / (6*ReZ11(i, j)));

            l = (l1 + l2) / 2;

            k = 3*ReZ11(i, j) / (2*(1-l2^2)^(3/2));
            h = (Z00 - (k*pi)/2 + k*asin(l2) + k*l2*sqrt(1-l2^2)) / pi;

            if k >= kt && abs(l2 - l1) <= lt
                edgeMap(i, j) = 1;
                subpixelEdges = [subpixelEdges; i+h, j+l];
            end
        end
    end
end

请注意，上述代码中的image参数应为一个灰度图像。您可以将图像加载到MATLAB中并将其传递给detectEdges函数以进行边缘检测。kt和lt是判断阈值，您可以根据实际情况进行调整。

希望对您有所帮助！
