使用matlabGUI 编写出实现输入横轴大小、纵轴大小、井眼半径并且为除了井眼外的两侧地层填充颜色的模型建立功能
以下是一个简单的示例代码,可以实现输入横轴大小、纵轴大小、井眼半径,并且为除了井眼外的两侧地层填充颜色的模型建立功能。具体实现过程可以参考以下代码:
function varargout = well_model(varargin)
% WELL_MODEL MATLAB code for well_model.fig
% WELL_MODEL, by itself, creates a new WELL_MODEL or raises the existing
% singleton*.
%
% H = WELL_MODEL returns the handle to a new WELL_MODEL or the handle to
% the existing singleton*.
%
% WELL_MODEL('CALLBACK',hObject,eventData,handles,...) calls the local
% function named CALLBACK in WELL_MODEL.M with the given input arguments.
%
% WELL_MODEL('Property','Value',...) creates a new WELL_MODEL or raises the
% existing singleton*. Starting from the left, property value pairs are
% applied to the GUI before well_model_OpeningFcn gets called. An
% unrecognized property name or invalid value makes property application
% stop. All inputs are passed to well_model_OpeningFcn via varargin.
%
% *See GUI Options on GUIDE's Tools menu. Choose "GUI allows only one
% instance to run (singleton)".
%
% See also: GUIDE, GUIDATA, GUIHANDLES
% Edit the above text to modify the response to help well_model
% Last Modified by GUIDE v2.5 21-Aug-2021 11:23:23
% Begin initialization code - DO NOT EDIT
gui_Singleton = 1;
gui_State = struct('gui_Name', mfilename, ...
'gui_Singleton', gui_Singleton, ...
'gui_OpeningFcn', @well_model_OpeningFcn, ...
'gui_OutputFcn', @well_model_OutputFcn, ...
'gui_LayoutFcn', [], ...
'gui_Callback', []);
if nargin && ischar(varargin{1})
gui_State.gui_Callback = str2func(varargin{1});
end
if nargout
[varargout{1:nargout}] = gui_mainfcn(gui_State, varargin{:});
else
gui_mainfcn(gui_State, varargin{:});
end
% End initialization code - DO NOT EDIT
% --- Executes just before well_model is made visible.
function well_model_OpeningFcn(hObject, eventdata, handles, varargin)
% This function has no output args, see OutputFcn.
% hObject handle to figure
% eventdata reserved - to be defined in a future version of MATLAB
% handles structure with handles and user data (see GUIDATA)
% varargin command line arguments to well_model (see VARARGIN)
% Choose default command line output for well_model
handles.output = hObject;
% Update handles structure
guidata(hObject, handles);
% UIWAIT makes well_model wait for user response (see UIRESUME)
% uiwait(handles.figure1);
% --- Outputs from this function are returned to the command line.
function varargout = well_model_OutputFcn(hObject, eventdata, handles)
% varargout cell array for returning output args (see VARARGOUT);
% hObject handle to figure
% eventdata reserved - to be defined in a future version of MATLAB
% handles structure with handles and user data (see GUIDATA)
% Get default command line output from handles structure
varargout{1} = handles.output;
% --- Executes on button press in draw_button.
function draw_button_Callback(hObject, eventdata, handles)
% hObject handle to draw_button (see GCBO)
% eventdata reserved - to be defined in a future version of MATLAB
% handles structure with handles and user data (see GUIDATA)
% read parameters
x_size = str2double(get(handles.x_size_edit, 'String'));
y_size = str2double(get(handles.y_size_edit, 'String'));
well_radius = str2double(get(handles.well_radius_edit, 'String'));
% generate x and y coordinates
x = linspace(-x_size/2, x_size/2, 100);
y = linspace(-y_size/2, y_size/2, 100);
[X, Y] = meshgrid(x, y);
% generate well mask
r = sqrt(X.^2 + Y.^2);
well_mask = r <= well_radius;
% generate fill mask
fill_mask = (X > -well_radius/2) & (X < well_radius/2) & (r >= well_radius);
% generate model
model = ones(size(X));
model(well_mask) = 0;
model(fill_mask) = 2;
% plot model
axes(handles.model_axes);
imagesc(x, y, model);
set(gca, 'YDir', 'normal');
xlabel('X (m)');
ylabel('Y (m)');
colormap([1 1 1; 0.5 0.5 0.5; 0 0 1]);
function x_size_edit_Callback(hObject, eventdata, handles)
% hObject handle to x_size_edit (see GCBO)
% eventdata reserved - to be defined in a future version of MATLAB
% handles structure with handles and user data (see GUIDATA)
% --- Executes during object creation, after setting all properties.
function x_size_edit_CreateFcn(hObject, eventdata, handles)
% hObject handle to x_size_edit (see GCBO)
% eventdata reserved - to be defined in a future version of MATLAB
% handles empty - handles not created until after all CreateFcns called
% Hint: edit controls usually have a white background on Windows.
% See ISPC and COMPUTER.
if ispc && isequal(get(hObject,'BackgroundColor'), get(0,'defaultUicontrolBackgroundColor'))
set(hObject,'BackgroundColor','white');
end
function y_size_edit_Callback(hObject, eventdata, handles)
% hObject handle to y_size_edit (see GCBO)
% eventdata reserved - to be defined in a future version of MATLAB
% handles structure with handles and user data (see GUIDATA)
% --- Executes during object creation, after setting all properties.
function y_size_edit_CreateFcn(hObject, eventdata, handles)
% hObject handle to y_size_edit (see GCBO)
% eventdata reserved - to be defined in a future version of MATLAB
% handles empty - handles not created until after all CreateFcns called
% Hint: edit controls usually have a white background on Windows.
% See ISPC and COMPUTER.
if ispc && isequal(get(hObject,'BackgroundColor'), get(0,'defaultUicontrolBackgroundColor'))
set(hObject,'BackgroundColor','white');
end
function well_radius_edit_Callback(hObject, eventdata, handles)
% hObject handle to well_radius_edit (see GCBO)
% eventdata reserved - to be defined in a future version of MATLAB
% handles structure with handles and user data (see GUIDATA)
% --- Executes during object creation, after setting all properties.
function well_radius_edit_CreateFcn(hObject, eventdata, handles)
% hObject handle to well_radius_edit (see GCBO)
% eventdata reserved - to be defined in a future version of MATLAB
% handles empty - handles not created until after all CreateFcns called
% Hint: edit controls usually have a white background on Windows.
% See ISPC and COMPUTER.
if ispc && isequal(get(hObject,'BackgroundColor'), get(0,'defaultUicontrolBackgroundColor'))
set(hObject,'BackgroundColor','white');
end
在这个代码中,我们使用了以下 GUI 元素:
- 一个 Push Button,用于触发绘制模型的事件。
- 三个 Edit Text,分别用于输入横轴大小、纵轴大小和井眼半径。
- 一个 Axes,用于显示模型。
在绘制模型的事件处理程序中,我们首先从三个 Edit Text 中读取参数,然后生成一个网格点矩阵 X 和 Y,接着生成一个井眼掩模和一个填充掩模,最后根据这两个掩模生成模型。我们使用 imagesc 函数将模型绘制在 Axes 中,并使用 colormap 函数将模型分成三个颜色。
这个示例代码可以根据需要进行修改和扩展,例如可以添加更多的参数输入框,或者将颜色分成更多个区域
