vue3 实现上下两个组件拖动分割条的代码示例
以下是一个简单的示例,展示如何使用 Vue3 实现上下两个组件拖动分割条:
<template>
<div class="container">
<div class="top" :style="topStyle" ref="top"></div>
<div class="divider" @mousedown="startDrag"></div>
<div class="bottom" :style="bottomStyle" ref="bottom"></div>
</div>
</template>
<script>
import { ref, reactive } from 'vue'
export default {
setup() {
const container = ref(null)
const top = ref(null)
const bottom = ref(null)
const dragging = reactive({
active: false,
startY: 0,
startHeight: 0
})
const startDrag = e => {
dragging.active = true
dragging.startY = e.clientY
dragging.startHeight = top.value.offsetHeight
}
const stopDrag = () => {
dragging.active = false
}
const handleDrag = e => {
if (!dragging.active) return
const delta = e.clientY - dragging.startY
top.value.style.height = `${dragging.startHeight + delta}px`
}
const topStyle = { height: '50%' }
const bottomStyle = { height: '50%' }
return {
container,
top,
bottom,
dragging,
startDrag,
stopDrag,
handleDrag,
topStyle,
bottomStyle
}
},
mounted() {
document.addEventListener('mousemove', this.handleDrag)
document.addEventListener('mouseup', this.stopDrag)
},
unmounted() {
document.removeEventListener('mousemove', this.handleDrag)
document.removeEventListener('mouseup', this.stopDrag)
}
}
</script>
<style scoped>
.container {
position: relative;
height: 100%;
}
.top {
background-color: #f0f0f0;
position: absolute;
top: 0;
left: 0;
right: 0;
bottom: auto;
overflow: auto;
}
.divider {
background-color: #ddd;
position: absolute;
top: 50%;
left: 0;
right: 0;
height: 10px;
cursor: ns-resize;
z-index: 1;
}
.bottom {
background-color: #f0f0f0;
position: absolute;
top: auto;
left: 0;
right: 0;
bottom: 0;
overflow: auto;
}
</style>
这个示例中,我们使用了 Vue3 的 ref 和 reactive 来创建一些响应式的变量。我们用 ref 来获取组件的 DOM 元素,并将其作为 ref 变量暴露给模板中的元素。我们还使用 reactive 来创建一个对象,该对象包含一个布尔值 active,以指示是否正在拖动分割条,以及鼠标位置和顶部组件的初始高度。
我们在模板中渲染了三个 div 元素,分别代表顶部组件、分割条和底部组件。我们使用 :style 绑定了顶部和底部组件的高度,这样我们就可以在拖动分割条时动态调整它们的高度。
我们在分割条元素上添加了一个 @mousedown 事件监听器,以便在用户开始拖动分割条时调用 startDrag 方法。在此方法中,我们设置了 dragging 对象的属性,以指示拖动正在进行,并记录鼠标位置和顶部组件的初始高度。
我们还添加了一个 @mouseup 事件监听器,以在用户停止拖动时调用 stopDrag 方法。在此方法中,我们将 dragging.active 设置为 false,以指示拖动已结束。
我们还添加了一个 @mousemove 事件监听器,以在用户拖动分割条时调用 handleDrag 方法。在此方法中,我们检查 dragging.active 是否为 true,以确定用户是否正在拖动分割条。如果是,我们计算鼠标位置相对于初始位置的偏移量,并将其添加到顶部组件的初始高度中,以获得新的高度。
最后,我们定义了一些 CSS 样式,以设置组件的外观和布局
