代码如下：

#include <stdio.h> #include <stdlib.h> #include <string.h>

define max_dis 100000

typedef char vextype[20];

typedef struct { int N, E;//N是顶点数，E是边数 int** matrix;//储存邻接矩阵 vextype* vertex;//存储节点的名字 } Graph;

Graph createGraph(int n); int isConnected(Graph g); int Diameter(Graph g); int Radius(Graph g); int dijkstra(Graph g, int start, int end, int* path); void printPath(int d, int* diameter_path, Graph g);

void DFS(Graph g, int i, int* visited, int* count); int DFSTraverse(Graph g); void floyd(Graph g, int** dist, int** path);

/**

• 创建一个节点数为n的图
• @param n 节点个数
• @return 返回这个图 / Graph createGraph(int n) { int i, j; Graph g; g.N = n; g.matrix = (int*)malloc(sizeof(int*) * g.N); for (i = 0; i < n; i++) { g.matrix[i] = (int*)malloc(sizeof(int) * g.N); } for (i = 0; i < g.N; i++) { for (j = 0; j < g.N; j++) { g.matrix[i][j] = max_dis; } } for (i = 0; i < g.N; i++) { g.matrix[i][i] = 0; } g.vertex = (vextype*)malloc(sizeof(vextype) * g.N); return g; }

/**

• 根据距离d和路径数组path输出路径，这样就不需要路径的节点数也能正确输出路径
• @param d 路径长度
• @param diameter_path 储存路径的数组
• @param g 图 */ void printPath(int d, int *diameter_path, Graph g) { int k = 0; int path_length = 0; printf("Path: "); do { printf("%s->", g.vertex[diameter_path[k]]); path_length += g.matrix[diameter_path[k]][diameter_path[k + 1]]; k++; } while (path_length < d); printf("%s\n", g.vertex[diameter_path[k]]); }

/**

• 判断图是否连通
• @param g 图
• @return 连通返回1，否则返回0 / int isConnected(Graph g) { int visited = (int*)malloc(sizeof(int) * g.N); memset(visited, 0, sizeof(int) * g.N); DFS(g, 0, visited, NULL); for (int i = 0; i < g.N; i++) { if (visited[i] == 0) { free(visited); return 0; } } free(visited); return 1; }

/**

• 使用dijkstra算法计算单源最短路径
• @param g 图
• @param start 起点
• @param end 终点
• @param path 从start到end的路径, [start,...,end]
• @return 路径长度 / int dijkstra(Graph g, int start, int end, int path) { int visited = (int)malloc(sizeof(int) * g.N); int* dist = (int*)malloc(sizeof(int) * g.N); memset(visited, 0, sizeof(int) * g.N); memset(dist, max_dis, sizeof(int) * g.N); memcpy(path, visited, sizeof(int) * g.N); dist[start] = 0; for (int i = 0; i < g.N; i++) { int min_dist = max_dis; int u = -1; for (int j = 0; j < g.N; j++) { if (!visited[j] && dist[j] < min_dist) { min_dist = dist[j]; u = j; } } if (u == -1) { break; } visited[u] = 1; for (int v = 0; v < g.N; v++) { if (!visited[v] && g.matrix[u][v] < max_dis) { int new_dist = dist[u] + g.matrix[u][v]; if (new_dist < dist[v]) { dist[v] = new_dist; path[v] = u; } } } } free(visited); free(dist); return path[end] == -1 ? max_dis : dist[end]; }

/**

• 计算图的直径。提示：Floyd算法
• @param g 图
• @return 直径的长度 / int Diameter(Graph g) { int* dist = (int**)malloc(sizeof(int*) * g.N); int** path = (int**)malloc(sizeof(int*) * g.N); for (int i = 0; i < g.N; i++) { dist[i] = (int*)malloc(sizeof(int) * g.N); path[i] = (int*)malloc(sizeof(int) * g.N); memcpy(dist[i], g.matrix[i], sizeof(int) * g.N); memset(path[i], -1, sizeof(int) * g.N); } floyd(g, dist, path); int diameter = -1; int* diameter_path = (int*)malloc(sizeof(int) * g.N); memset(diameter_path, -1, sizeof(int) * g.N); for (int i = 0; i < g.N; i++) { for (int j = 0; j < g.N; j++) { if (dist[i][j] > diameter) { diameter = dist[i][j]; diameter_path[0] = i; diameter_path[1] = j; int k = 2; while (path[i][j] != -1) { diameter_path[k] = path[i][j]; j = path[i][j]; k++; } diameter_path[k] = i; } } } printPath(diameter, diameter_path, g); free(diameter_path); for (int i = 0; i < g.N; i++) { free(dist[i]); free(path[i]); } free(dist); free(path); return diameter; }

/**

• 计算图的半径
• @param g 图
• @return 半径长度 / int Radius(Graph g) { int* dist = (int**)malloc(sizeof(int*) * g.N); int** path = (int**)malloc(sizeof(int*) * g.N); for (int i = 0; i < g.N; i++) { dist[i] = (int*)malloc(sizeof(int) * g.N); path[i] = (int*)malloc(sizeof(int) * g.N); memcpy(dist[i], g.matrix[i], sizeof(int) * g.N); memset(path[i], -1, sizeof(int) * g.N); } floyd(g, dist, path); int radius = max_dis; for (int i = 0; i < g.N; i++) { int eccentricity = -1; for (int j = 0; j < g.N; j++) { if (dist[i][j] > eccentricity) { eccentricity = dist[i][j]; } } if (eccentricity < radius) { radius = eccentricity; } } for (int i = 0; i < g.N; i++) { free(dist[i]); free(path[i]); } free(dist); free(path); return radius; }

void DFS(Graph g, int i, int* visited, int* count) { visited[i] = 1; if (count != NULL) { (*count)++; } for (int j = 0; j < g.N; j++) { if (g.matrix[i][j] < max_dis && visited[j] == 0) { DFS(g, j, visited, count); } } }

int DFSTraverse(Graph g) { int* visited = (int*)malloc(sizeof(int) * g.N); memset(visited, 0, sizeof(int) * g.N); int count = 0; for (int i = 0; i < g.N; i++) { if (visited[i] == 0) { DFS(g, i, visited, &count); } } free(visited); return count == g.N; }

void floyd(Graph g, int** dist, int** path) { for (int k = 0; k < g.N; k++) { for (int i = 0; i < g.N; i++) { for (int j = 0; j < g.N; j++) { if (dist[i][k] + dist[k][j] < dist[i][j]) { dist[i][j] = dist[i][k] + dist[k][j]; path[i][j] = k; } } } } }

int main() { int node_num; int edge_num;

scanf("%d %d", &node_num, &edge_num);

Graph g = createGraph(node_num);
for(int i = 0; i < node_num; i++) {
    sprintf(g.vertex[i], "%d", i);
}
for (int i = 0; i < edge_num; i++) {
    int start_idx, end_idx, weight;
    scanf("%d %d %d", &start_idx, &end_idx, &weight);
    g.matrix[start_idx][end_idx] = weight;
    g.matrix[end_idx][start_idx] = weight;
}
printf("connected: %d\n", DFSTraverse(g));

if (DFSTraverse(g))
{
    int* short_path = (int*)malloc(sizeof(int) * g.N);
    int dis = dijkstra(g, 1, 3, short_path);
    printf("the minimum fare between 1 and 3: %d\n", dis);
    printPath(dis, short_path, g);
    free(short_path);
    int d = Diameter(g);
    printf("diameter:%d\n", d);

    int r = Radius(g);
    printf("radius:%d\n", r);
}

return 0;
