已知出租车轨迹中的纬度、经度、时间数据请利用python分析热点交互网络并进行可视化展示输出代码不使用folium库

为了分析出租车轨迹中的热点交互网络，我们可以先进行以下步骤：

1. 根据数据中的经纬度信息，将地图划分成一定数量的网格。
2. 统计每个网格内出现的出租车数量。
3. 对于每个网格，计算其周围八个网格的出租车数量和距离，并计算其与周围网格的交互强度。
4. 将每个网格的交互强度作为节点，将每个网格与周围八个网格的交互强度作为边，构成一个无向加权图。
5. 对于图中的每个节点，计算其度数和介数中心性，并标记出度数和介数中心性较高的节点作为热点网格。
6. 将热点网格的位置标记在地图上，并将热点网格之间的边以不同的颜色和宽度绘制在地图上，以展示热点交互网络。

以下是实现上述步骤的Python代码：

import numpy as np
import pandas as pd
import matplotlib.pyplot as plt

# 读取数据
data = pd.read_csv('taxi_trajectory.csv')

# 将经纬度信息转换为网格坐标
min_lon, max_lon = data['lon'].min(), data['lon'].max()
min_lat, max_lat = data['lat'].min(), data['lat'].max()

# 网格数量
grid_size = 50

# 计算每个网格的经纬度范围
lon_step = (max_lon - min_lon) / grid_size
lat_step = (max_lat - min_lat) / grid_size

lon_range = [(min_lon + i * lon_step, min_lon + (i + 1) * lon_step)
             for i in range(grid_size)]
lat_range = [(min_lat + i * lat_step, min_lat + (i + 1) * lat_step)
             for i in range(grid_size)]

# 统计每个网格内出现的出租车数量
grid_counts = np.zeros((grid_size, grid_size))
for _, row in data.iterrows():
    lon, lat = row['lon'], row['lat']
    # 找到所在的网格
    for i, (lon_min, lon_max) in enumerate(lon_range):
        if lon_min <= lon < lon_max:
            for j, (lat_min, lat_max) in enumerate(lat_range):
                if lat_min <= lat < lat_max:
                    grid_counts[i, j] += 1
                    break
            break

# 计算每个网格的交互强度
interaction_strength = np.zeros((grid_size, grid_size, 8))
for i in range(grid_size):
    for j in range(grid_size):
        for k, (delta_i, delta_j) in enumerate([(1, 0), (1, 1), (0, 1),
                                                 (-1, 1), (-1, 0),
                                                 (-1, -1), (0, -1), (1, -1)]):
            # 计算相邻网格的坐标
            adjacent_i, adjacent_j = i + delta_i, j + delta_j
            if 0 <= adjacent_i < grid_size and 0 <= adjacent_j < grid_size:
                # 计算距离和交互强度
                distance = np.sqrt(delta_i ** 2 + delta_j ** 2)
                interaction_strength[i, j, k] = (grid_counts[adjacent_i, adjacent_j]
                                                 / distance)

# 构建无向加权图
edges = []
edge_weights = []
for i in range(grid_size):
    for j in range(grid_size):
        if grid_counts[i, j] > 0:
            # 添加自环
            edges.append((i, j, 0))
            edge_weights.append(0)
            # 添加相邻边
            for k in range(8):
                adjacent_i, adjacent_j = i + delta_i, j + delta_j
                if 0 <= adjacent_i < grid_size and 0 <= adjacent_j < grid_size:
                    weight = interaction_strength[i, j, k]
                    if weight > 0:
                        edges.append((i, j, 1))
                        edge_weights.append(weight)

# 计算节点的度数和介数中心性
node_degrees = np.sum(grid_counts > 0, axis=2)
node_betweenness = np.zeros((grid_size, grid_size))
for i in range(grid_size):
    for j in range(grid_size):
        if grid_counts[i, j] > 0:
            # 计算节点的介数中心性
            adjacencies = [(i + delta_i, j + delta_j)
                           for delta_i, delta_j in [(1, 0), (1, 1), (0, 1),
                                                    (-1, 1), (-1, 0),
                                                    (-1, -1), (0, -1), (1, -1)]
                           if 0 <= i + delta_i < grid_size and 0 <= j + delta_j < grid_size]
            for k, (delta_i, delta_j) in enumerate(adjacencies):
                if grid_counts[delta_i, delta_j] > 0:
                    node_betweenness[i, j] += (node_degrees[delta_i, delta_j]
                                               / node_degrees[i, j])

# 标记热点网格
threshold_degree = np.percentile(node_degrees, 90)
threshold_betweenness = np.percentile(node_betweenness, 90)
hotspots = [(i, j) for i in range(grid_size)
            for j in range(grid_size)
            if node_degrees[i, j] >= threshold_degree
            or node_betweenness[i, j] >= threshold_betweenness]

# 可视化展示
fig, ax = plt.subplots(figsize=(10, 10))
ax.set_xlim(min_lon, max_lon)
ax.set_ylim(min_lat, max_lat)

# 绘制网格
for i in range(grid_size):
    for j in range(grid_size):
        if grid_counts[i, j] > 0:
            lon_min, lat_min = lon_range[i][0], lat_range[j][0]
            ax.add_patch(plt.Rectangle((lon_min, lat_min), lon_step, lat_step,
                                        facecolor='none', edgecolor='gray'))

# 绘制热点网格
for i, j in hotspots:
    lon_min, lat_min = lon_range[i][0], lat_range[j][0]
    ax.add_patch(plt.Rectangle((lon_min, lat_min), lon_step, lat_step,
                                facecolor='red', edgecolor='none'))

# 绘制热点网格之间的边
for i, j in hotspots:
    for k, (delta_i, delta_j) in enumerate([(1, 0), (1, 1), (0, 1),
                                             (-1, 1), (-1, 0),
                                             (-1, -1), (0, -1), (1, -1)]):
        adjacent_i, adjacent_j = i + delta_i, j + delta_j
        if 0 <= adjacent_i < grid_size and 0 <= adjacent_j < grid_size:
            if (adjacent_i, adjacent_j) in hotspots:
                weight = interaction_strength[i, j, k]
                if weight > 0:
                    x = [lon_range[i][0] + lon_step / 2,
                         lon_range[adjacent_i][0] + lon_step / 2]
                    y = [lat_range[j][0] + lat_step / 2,
                         lat_range[adjacent_j][0] + lat_step / 2]
                    color = 'red' if weight >= np.percentile(edge_weights, 90) else 'gray'
                    width = weight / np.percentile(edge_weights, 90) * 5
                    ax.plot(x, y, color=color, linewidth=width)

plt.show()

在以上代码中，我们首先根据数据中的经纬度信息，将地图划分成了一个50x50的网格，并统计了每个网格内出现的出租车数量。然后，我们计算了每个网格的交互强度，并根据交互强度构建了一个无向加权图。接着，我们计算了每个节点的度数和介数中心性，并标记了度数和介数中心性较高的节点作为热点网格。最后，我们将热点网格的位置标记在地图上，并将热点网格之间的边以不同的颜色和宽度绘制在地图上，展示了热点交互网络
