The overall structure of the feedback amplifier chain SPUF proposed in this article is shown in Figure 1. It consists of four main parts, including the entropy source generator, entropy source quantizer, digital controller, and drive buffer. The entropy source generator module is composed of n cascaded stages, each with m A-Type amplifiers controlled by input excitation, capable of nonlinearly combining different entropy source units based on external excitation. The entropy source quantization module consists of a fixed B-Type amplifier chain, which converts the analog voltage output from the entropy source generator module into preliminary digital form. Finally, the output response is obtained by passing through the drive buffer module.

help me change this paragraph to english 本文所提出的反馈放大器链SPUF整体结构如图1所示整体由四个部分组成包括熵源生成器、熵源量化器、数字控制器以及驱动缓冲器。其中熵源生成模块由n级级联、每一级有m个由输入激励控制的A-Type Amplifier组成实现了根据外部激励选择不同的熵源单元进行非线性叠加的功能;熵源量化模块由固定的一个B-Type Ampl
