help me change this paragraph to english 此外由于每个放大器单元都具有扼流管使得整体PUF具有极低的功耗特别适用于物联网设备的终端应用。在本文余下的内容里所提出的PUF电路结构和非线性数学模型将分别在section II和section III进行描述section IV则是所设计chip的测试结果which is通过65nm标准CMOS工艺制造最后sect

In addition, each amplifier unit in the PUF circuit has a choke tube, which results in very low power consumption, making it particularly suitable for terminal applications in the Internet of Things. The PUF circuit structure and nonlinear mathematical model proposed in this paper will be described in sections II and III, respectively. Section IV presents the test results of the designed chip, which was manufactured using the 65nm standard CMOS process. Finally, section V provides a summary of this paper.
