Admin Panel: Manage Products and Categories with SQLite
from tkinter import *
from tkinter import messagebox
from tkinter.font import Font
from tkinter import ttk
# import mysql.connector as mysql
import sqlite3
# Creating Tkinter Window
Admin = Tk()
Admin.geometry('1330x750')
Admin.resizable(0, 0)
Admin.iconbitmap('./images/Logo.ico')
Admin.title('Admin')
# Creating Mysql connection
dbconn = sqlite3.connect('./Database/RSgroceries.db')
# Create a cursor to give commands
cursor = dbconn.cursor()
# Create Tables
# category Table
cursor.execute('''CREATE TABLE if not exists category(
category varchar(100) NOT NULL primary key
)
''')
dbconn.commit()
cursor.execute('''CREATE TABLE if not exists products(
product_id int not null primary key,
product_name varchar(100) not null,
product_rate int not null,
category varchar(100) not null references category(category)
)
''')
dbconn.commit()
cursor.execute('SELECT * FROM products')
prod_1 = cursor.fetchall()
# print(prod_1)
dbconn.commit()
# Fixing GUI Background
Background = PhotoImage(file='./images/Admin_bg.png')
Bg_label = Label(Admin, image=Background)
Bg_label.place(x=0, y=0, relwidth=1, relheight=1)
# Creating invoice
table = ttk.Treeview(Admin)
table['columns'] = ('ID','Product Name','Category', 'Rate')
table.column('#0', width=0,stretch=NO)
table.column('#1', width=50,anchor='center')
table.column('#2', width=230,anchor='center')
table.column('#3',width=230,anchor='center')
table.column('#4',width=120,anchor='center')
table.heading('#0',text='')
table.heading('#1',text='ID')
table.heading('#2',text='Product Name')
table.heading('#3',text='Category')
table.heading('#4',text='Rate')
table.place(relx=0.50,rely=0.1139,height=528.8, width=630)
Scroll_invoice = Scrollbar(orient='vertical',command=table.yview)
table.configure(yscroll=Scroll_invoice.set)
Scroll_invoice.place(relx=0.961,rely=0.1140, height=527.3)
for row in prod_1:
table.insert('',index='end',values=(row[0],row[1],row[3],row[2]))
# Defining Exit function
def Exit():
sure = messagebox.askyesno('Exit','Are you sure you want to exit?', parent=Admin)
if sure == True:
Admin.destroy()
# adm.destroy()
# Creating logout button
logout_img = PhotoImage(file='./images/logout.png')
logout_button = Button(Admin, image=logout_img, borderwidth=0,relief='flat',overrelief='flat', command=Exit)
logout_button.place(relx=0.0155, rely=0.038,width=39,height=31)
# Creating all the required widgets
# Creating text variables
cat = StringVar()
pro_name = StringVar()
pro_rate = StringVar()
font_1 = Font(family='Calibri',size=15,weight='bold')
# All Entry widgets
# Product Category Widget
Entry_1 = Entry(Admin,font=font_1,relief='flat',bg='#fefffe')
Entry_1.place(relx=0.043,rely=0.622,width=423,height=50)
# Product Rate Widget
Entry_2 = Entry(Admin, font=font_1,relief='flat',bg='#fefffe')
Entry_2.place(relx=0.043,rely=0.780,width=423,height=50)
# Product Name Widget
Entry_3 = Entry(Admin,font=font_1,relief='flat',bg='#fefffe')
Entry_3.place(relx=0.043,rely=0.463,width=423,height=50)
# Product Id Widget
Entry_4 = Entry(Admin,font=font_1,relief='flat',bg='#fefffe')
Entry_4.place(relx=0.043,rely=0.3205,width=423,height=50)
# Search code Entry Widget
Entry_5 = Entry(Admin, font=font_1,relief='flat',bg='#fefafa')
Entry_5.place(relx=0.161,rely=0.115,width=255,height=40)
# Defining all the required functions
# CREATING FUNCTION TO REMOVE UNWANTED CATEGORY
def unwanted_cat():
category_delete_1 = table.get_children()
categories_avail = []
for rec in category_delete_1:
values = table.item(rec).get('values')[2]
categories_avail.append(values)
cursor.execute('SELECT category FROM category')
cat_t = cursor.fetchall()
all_cat = []
for i in cat_t:
all_cat.append(i[0])
available_category = []
for fin in all_cat:
if fin in categories_avail:
available_category.append(fin)
else:
pass
cursor.execute('DROP TABLE category')
dbconn.commit()
# Creating table product if not exist
cursor.execute('''CREATE TABLE if not exists category(
category varchar(100) NOT NULL primary key
)
''')
dbconn.commit()
for last in available_category:
try:
cursor.execute('INSERT INTO category VALUES('{}')'.format(last))
dbconn.commit()
except sqlite3.IntegrityError:
pass
# Add to cart
def add_to_cart():
# Creating table product if not exist
cursor.execute('''CREATE TABLE if not exists category(
category varchar(100) NOT NULL primary key
)
''')
cursor.execute('''CREATE TABLE if not exists products(
product_id int not null primary key,
product_name varchar(100) not null,
product_rate int not null,
category varchar(100) not null references category(category)
)
''')
dbconn.commit()
all_rec = table.get_children()
ids = []
for rec in all_rec:
values = table.item(rec).get('values')[0]
ids.append(values)
if (Entry_2.get().isdigit() or Entry_2.get()=='') :
try:
if Entry_1.get() != '' and Entry_2.get() != '' and Entry_3.get() != '' and Entry_4.get() != '':
n = messagebox.askyesno('Add to Market', 'Are you sure you want to add it to the Market?')
if n == 1:
cursor.execute('SELECT product_id FROM products')
id_check = cursor.fetchall()
id_check_fin = []
dbconn.commit()
if (int(Entry_4.get()),) in id_check:
messagebox.showerror('Error', 'Product id already in the market')
else:
table.insert('', index='end', values=(Entry_4.get(), Entry_3.get(), Entry_1.get(), Entry_2.get()))
cursor.execute('INSERT INTO products VALUES(:product_id, :product_name, :product_rate, :category)',
{
'product_id': Entry_4.get(),
'product_name': Entry_3.get(),
'product_rate': Entry_2.get(),
'category': Entry_1.get()
}
)
cursor.execute('SELECT category FROM category')
categories_db = cursor.fetchall()
categories = []
for i in categories_db:
categories.append(i[0])
if Entry_1.get() not in categories:
cursor.execute('INSERT INTO category VALUES(:category)',
{'category': Entry_1.get()})
dbconn.commit()
else:
pass
dbconn.commit()
Entry_1.delete(0, END)
Entry_2.delete(0, END)
Entry_3.delete(0, END)
Entry_4.delete(0, END)
unwanted_cat()
else:
pass
else:
messagebox.showerror('Error', 'Please fill the details')
except ValueError:
messagebox.showerror('Error', 'Please enter correct product ID!')
else:
Entry_2.delete(0, END)
messagebox.showerror('Error', 'Please enter correct quantity!')
# Update
def update():
# Creating table product if not exist
cursor.execute('''CREATE TABLE if not exists category(
category varchar(100) NOT NULL primary key
)
''')
cursor.execute('''CREATE TABLE if not exists products(
product_id int not null primary key,
product_name varchar(100) not null,
product_rate int not null,
category varchar(100) not null references category(category)
)
''')
dbconn.commit()
Button_1.configure(state='active')
if Entry_1.get() != '' and Entry_2.get() != '' and Entry_3.get() != '' and Entry_4.get() != '':
cursor.execute('SELECT product_id FROM products')
id_check = cursor.fetchall()
dbconn.commit()
if (int(Entry_4.get()),) in id_check:
all_rows = table.get_children()
k = []
for i in all_rows:
if table.item(i).get('values')[0] == int(Entry_4.get()):
k.append(i)
else:
pass
table.item(k[0], text='', values=(int(Entry_4.get()) ,Entry_3.get(), Entry_1.get(), Entry_2.get()))
cursor.execute('''
UPDATE products SET product_name = '{}', category = '{}', product_rate = {} WHERE product_id = {}'''
.format(Entry_3.get(), Entry_1.get(), Entry_2.get(), int(Entry_4.get())))
dbconn.commit()
cursor.execute('SELECT category FROM category')
categories_db = cursor.fetchall()
categories = []
for i in categories_db:
categories.append(i[0])
if Entry_1.get() not in categories:
cursor.execute('INSERT INTO category VALUES(:category)',
{'category': Entry_1.get()})
dbconn.commit()
Entry_1.delete(0, END)
Entry_2.delete(0, END)
Entry_3.delete(0, END)
Entry_4.delete(0, END)
unwanted_cat()
else:
messagebox.showerror('Error', 'Product ID not in the market')
else:
messagebox.showerror('Error', 'Fill all the details')
# Clear
def clear():
# Creating table product if not exist
cursor.execute('''CREATE TABLE if not exists category(
category varchar(100) NOT NULL primary key
)
''')
cursor.execute('''CREATE TABLE if not exists products(
product_id int not null primary key,
product_name varchar(100) not null,
product_rate int not null,
category varchar(100) not null references category(category)
)
''')
dbconn.commit()
Entry_1.delete(0, END)
Entry_2.delete(0, END)
Entry_3.delete(0, END)
Entry_4.delete(0, END)
Button_1.configure(state='active')
unwanted_cat()
# Select Item
def select_item():
# Creating table product if not exist
cursor.execute('''CREATE TABLE if not exists category(
category varchar(100) NOT NULL primary key
)
''')
cursor.execute('''CREATE TABLE if not exists products(
product_id int not null primary key,
product_name varchar(100) not null,
product_rate int not null,
category varchar(100) not null references category(category)
)
''')
dbconn.commit()
items_n = table.selection()
if len(items_n)>1:
messagebox.showerror('Error', 'Two or more items are selected')
else:
if items_n == ():
messagebox.showerror('Error', 'No Item(s) selected')
else:
Entry_1.delete(0, END)
Entry_2.delete(0, END)
Entry_3.delete(0, END)
Entry_4.delete(0, END)
sel_item = []
for i in items_n:
k = table.item(i, 'values')
for j in k:
sel_item.append(j)
Entry_4.insert(0, sel_item[0])
Entry_3.insert(0, sel_item[1])
Entry_2.insert(0, sel_item[3])
Entry_1.insert(0, sel_item[2])
unwanted_cat()
Button_1.configure(state='disabled')
# Delete item(s)
def delete_many():
# Creating table product if not exist
cursor.execute('''CREATE TABLE if not exists category(
category varchar(100) NOT NULL primary key
)
''')
cursor.execute('''CREATE TABLE if not exists products(
product_id int not null primary key,
product_name varchar(100) not null,
product_rate int not null,
category varchar(100) not null references category(category)
)
''')
dbconn.commit()
items_n = table.selection()
if items_n == ():
messagebox.showerror('Error', 'No Item(s) selected')
else:
n = messagebox.askyesno('Delete item(s)','Are you sure you want to delete the selected item(s)?')
if n == 1:
pro_id = []
for i in items_n:
k = table.item(i, 'values')
pro_id.append(k[0])
for rows_n in items_n:
table.delete(rows_n)
for row in pro_id:
cursor.execute('DELETE FROM products WHERE product_id={}'.format(row))
dbconn.commit()
unwanted_cat()
else:
pass
# Clear All
def clear_all():
# Creating table product if not exist
cursor.execute('''CREATE TABLE if not exists category(
category varchar(100) NOT NULL primary key
)
''')
cursor.execute('''CREATE TABLE if not exists products(
product_id int not null primary key,
product_name varchar(100) not null,
product_rate int not null,
category varchar(100) not null references category(category)
)
''')
dbconn.commit()
if table.get_children() == ():
messagebox.showerror('Error','No Items in the Market')
else:
n = messagebox.askyesno('Clear All', 'Are you sure you want to clear all the items?')
if n == 1:
for rows in table.get_children():
table.delete(rows)
cursor.execute('DROP TABLE products')
dbconn.commit()
unwanted_cat()
else:
pass
def search_id():
if Entry_5.get() == '':
messagebox.showerror('Error', 'Enter ID to search')
else:
id = int(Entry_5.get())
cursor.execute('SELECT product_id FROM products')
id_check = cursor.fetchall()
dbconn.commit()
all_rows = table.get_children()
row = []
for i in all_rows:
if table.item(i).get('values')[0] == id:
row.append(i)
if row == []:
messagebox.showerror('Error', 'No product with ID {}'.format(id))
else:
Button_1.configure(state='disabled')
for j in row:
Entry_1.delete(0, END)
Entry_2.delete(0, END)
Entry_3.delete(0, END)
Entry_4.delete(0, END)
values = table.item(j).get('values')
Entry_4.insert(0, values[0])
Entry_3.insert(0, values[1])
Entry_2.insert(0, values[3])
Entry_1.insert(0, values[2])
Entry_5.delete(0, END)
unwanted_cat()
# All Button Widgets
# Non-Table widgets
# Add to Market
Button_1 = Button(Admin, text='Add to market', relief='flat', bg='#fe1716',fg='black',borderwidth=0,font=font_1,command=add_to_cart)
Button_1.configure(activebackground='#fe1716')
Button_1.place(relx=0.04325,rely=0.878,width=135,height=43)
# Modify
Button_2 = Button(Admin, text='Update', relief='flat', bg='#fe1716', fg='black', borderwidth=0, font=font_1, command=update)
Button_2.configure(activebackground='#fe1716')
Button_2.place(relx=0.161, rely=0.878, width=135, height=43)
# Clear
Button_3 = Button(Admin, text='Clear', relief='flat', bg='#fe1716', fg='black', borderwidth=0, font=font_1,command=clear)
Button_3.configure(activebackground='#fe1716')
Button_3.place(relx=0.278, rely=0.878, width=135, height=43)
# Search
search_img = PhotoImage(file='./images/search.png')
search_button = Button(Admin, image=search_img, borderwidth=0,relief='flat',overrelief='flat', command=search_id)
search_button.place(relx=0.3713, rely=0.1175)
# Table widgets
# Select
Button_4 = Button(Admin, text='Select', relief='flat', bg='#fe1716', fg='black', borderwidth=0, font=font_1,command=select_item)
Button_4.configure(activebackground='#fe1716')
Button_4.place(relx=0.512, rely=0.8855, width=135, height=43)
# Delete item(s)
Button_5 = Button(Admin, text='Delete item(s)', relief='flat', bg='#fe1716',fg='black',borderwidth=0,font=font_1, command=delete_many)
Button_5.configure(activebackground='#fe1716')
Button_5.place(relx=0.686,rely=0.8855,width=135,height=43)
# Clear All
Button_6 = Button(Admin, text='Clear All', relief='flat', bg='#fe1716', fg='black', borderwidth=0, font=font_1, command=clear_all)
Button_6.configure(activebackground='#fe1716')
Button_6.place(relx=0.862, rely=0.8855, width=135, height=43)
Admin.protocol('WM_DELETE_WINDOW', Exit)
Admin.mainloop()
This code creates a simple GUI application using the tkinter library. The application is an admin panel for managing products and categories stored in an SQLite database. Here's a breakdown of the code:
-
Imports: The code imports the necessary libraries:
tkinter: For creating the GUI elements.messagebox: For displaying dialog boxes.Font: For customizing fonts.ttk: For using themed widgets.sqlite3: For interacting with the SQLite database.
-
Window Setup:
Admin = Tk(): Creates the main window of the application.Admin.geometry('1330x750'): Sets the window size to 1330 pixels wide and 750 pixels tall.Admin.resizable(0, 0): Prevents the window from being resized.Admin.iconbitmap('./images/Logo.ico'): Sets the window icon to Logo.ico.Admin.title('Admin'): Sets the window title to 'Admin'.
-
Database Connection:
dbconn = sqlite3.connect('./Database/RSgroceries.db'): Establishes a connection to the SQLite database file 'RSgroceries.db'.cursor = dbconn.cursor(): Creates a cursor object to execute SQL commands.
-
Table Creation:
- The code creates two tables in the database if they don't exist:
category: Stores categories for the products.products: Stores the product details.
- The code creates two tables in the database if they don't exist:
-
GUI Elements:
- Background: Loads a background image from './images/Admin_bg.png' and places it as the background of the window.
- Invoice Table: Creates a
ttk.Treeviewwidget to display the products from the database. The columns are 'ID', 'Product Name', 'Category', and 'Rate'. - Scrollbar: Creates a vertical scrollbar for the table.
- Entry Widgets: Creates several
Entrywidgets for users to input product details (product name, category, rate, and ID). - Buttons: Creates buttons for various actions:
- Add to Market: Adds a new product to the database and table.
- Update: Updates an existing product in the database and table.
- Clear: Clears the input fields.
- Search: Searches for a product by ID.
- Select: Selects a product from the table and fills the input fields.
- Delete item(s): Deletes selected products from the database and table.
- Clear All: Clears all products from the database and table.
- Logout: Closes the window.
-
Functions:
- Exit(): Asks for confirmation before closing the window.
- unwanted_cat(): Removes unused categories from the database and table.
- add_to_cart(): Adds a new product to the database and table, ensuring that the product ID is unique and the category exists.
- update(): Updates an existing product in the database and table.
- clear(): Clears the input fields.
- select_item(): Selects a product from the table and fills the input fields.
- delete_many(): Deletes selected products from the database and table.
- clear_all(): Clears all products from the database and table.
- search_id(): Searches for a product by ID and fills the input fields.
-
Event Handling:
- Admin.protocol('WM_DELETE_WINDOW', Exit): Sets the
Exit()function to be called when the user tries to close the window.
- Admin.protocol('WM_DELETE_WINDOW', Exit): Sets the
-
Main Loop:
Admin.mainloop(): Starts the Tkinter event loop, which handles user interactions and keeps the window open until it's closed.
This code demonstrates how to use Tkinter to create a basic admin panel for managing data stored in an SQLite database. It includes common GUI elements and functionality like adding, updating, deleting, and searching dat
原文地址: https://www.cveoy.top/t/topic/bfJF 著作权归作者所有。请勿转载和采集!
