写一个在Revit中C#写的遍历墙体参数并通过Taskdialog展示的代码
以下是一个示例代码,它会遍历Revit中所有墙体的参数,并通过Taskdialog展示它们的值:
using System.Collections.Generic;
using Autodesk.Revit.DB;
using Autodesk.Revit.UI;
public void TraverseWallParameters(UIApplication uiapp)
{
// 获取当前打开的文档
Document doc = uiapp.ActiveUIDocument.Document;
// 获取所有墙体元素
FilteredElementCollector walls = new FilteredElementCollector(doc)
.OfCategory(BuiltInCategory.OST_Walls)
.WhereElementIsNotElementType();
// 创建一个字符串列表,用于保存参数值
List<string> parameters = new List<string>();
// 遍历每一个墙体元素
foreach (Element wall in walls)
{
// 获取墙体元素的所有参数
ParameterSet paramSet = wall.Parameters;
// 遍历每一个参数
foreach (Parameter param in paramSet)
{
// 如果参数可读取,则获取它的值
if (param.IsReadOnly == false)
{
string value = param.AsValueString();
// 将参数名称和值添加到字符串列表中
string name = param.Definition.Name;
parameters.Add(name + ": " + value);
}
}
}
// 创建一个Taskdialog,展示所有墙体的参数值
TaskDialog dialog = new TaskDialog("Wall Parameters");
// 将参数列表作为消息内容
dialog.MainInstruction = "The following parameters were found:";
dialog.MainContent = string.Join("\n", parameters);
// 显示Taskdialog
dialog.Show();
}
