旅行商问题 (TSP) 蚂蚁系统算法实现：Matlab 代码详解

以下是使用 Matlab 实现的基本蚂蚁系统 (AS) 算法的代码，包括路径构建和信息素更新两个部分：

num_cities = 31;  % 城市数量
num_ants = 10;  % 蚂蚁数量
alpha = 1;  % 信息素重要程度因子
beta = 5;  % 启发式因子
rho = 0.5;  % 信息素蒸发系数
Q = 100;  % 信息素增量常数
max_iter = 100;  % 最大迭代次数

% 城市坐标
city_coords = [1304, 2312; 3639, 1315; 4177, 2244; 3712, 1399; 3488, 1535; 3326, 1556; 3238, 1229;
    4196, 1044; 4312, 790; 4386, 570; 3007, 1970; 2562, 1756; 2788, 1491; 2381, 1676; 1332, 695; 3715, 1678;
    3918, 2179; 4061, 2370; 3780, 2212; 3676, 2578; 4029, 2838; 4263, 2931; 3429, 1908; 3507, 2376;
    3394, 2643; 3439, 3201; 2935, 3240; 3140, 3550; 2545, 2357; 2778, 2826; 2370, 2975];

% 计算两个城市之间的距离
distance = @(city1, city2) norm(city2 - city1);

% 初始化信息素矩阵
pheromone = ones(num_cities, num_cities);

% 迭代过程
best_distance = inf;
best_path = [];
for iteration = 1:max_iter
    % 蚂蚁路径构建
    paths = zeros(num_ants, num_cities);

    for ant = 1:num_ants
        current_city = randi(num_cities);  % 随机选择起始城市
        unvisited_cities = setdiff(1:num_cities, current_city);

        for step = 1:num_cities-1
            % 选择下一个城市
            prob = zeros(1, numel(unvisited_cities));
            for i = 1:numel(unvisited_cities)
                city = unvisited_cities(i);
                prob(i) = (pheromone(current_city, city)^alpha) * (1 / distance(city_coords(current_city, :), city_coords(city, :))^beta);
            end
            prob = prob / sum(prob);
            next_city = randsample(unvisited_cities, 1, true, prob);

            % 更新路径和未访问城市集合
            paths(ant, step) = next_city;
            unvisited_cities = setdiff(unvisited_cities, next_city);
            current_city = next_city;
        end

        % 最后一步回到起始城市
        paths(ant, end) = unvisited_cities(1);
    end

    % 计算每个蚂蚁路径的长度
    distances = zeros(1, num_ants);
    for ant = 1:num_ants
        for step = 1:num_cities-1
            distances(ant) = distances(ant) + distance(city_coords(paths(ant, step), :), city_coords(paths(ant, step+1), :));
        end
        distances(ant) = distances(ant) + distance(city_coords(paths(ant, end), :), city_coords(paths(ant, 1), :));
    end

    % 更新最佳路径和最佳路径长度
    [min_distance, min_idx] = min(distances);
    if min_distance < best_distance
        best_distance = min_distance;
        best_path = paths(min_idx, :);
    end

    % 信息素更新
    delta_pheromone = zeros(num_cities, num_cities);
    for ant = 1:num_ants
        for step = 1:num_cities-1
            city1 = paths(ant, step);
            city2 = paths(ant, step+1);
            delta_pheromone(city1, city2) = delta_pheromone(city1, city2) + Q / distances(ant);
        end
        delta_pheromone(paths(ant, end), paths(ant, 1)) = delta_pheromone(paths(ant, end), paths(ant, 1)) + Q / distances(ant);
    end

    pheromone = (1 - rho) * pheromone + delta_pheromone;
end

% 输出结果
disp('迭代曲线：');
% 迭代曲线代码

disp('最佳周游路线：');
disp(best_path);

disp('最佳周游路线长度：');
disp(best_distance);

在示例代码中，用来记录每轮迭代的最佳路线的变量是best_path，用来记录最佳路线长度的变量是best_distance。

算法的输出结果将根据每次运行时的随机数生成而有所不同，因此无法提供具体的结果。但是，该算法将生成一条最佳周游路线和该路线的长度。
