写一个使用stm32f103rct6做MCUa3982作为步进电机驱动芯片通过pwm控制步进电机速度的h文件和c文件

由于没有具体的步进电机型号和接线图，以下代码仅供参考，需要根据实际情况进行修改。

.h文件：

#ifndef __STEPPER_H #define __STEPPER_H

#include "stm32f10x.h"

#define STEPPER_PWM_TIM TIM2

void Stepper_Init(void); void Stepper_SetSpeed(uint16_t speed); void Stepper_SetDirection(uint8_t dir); void Stepper_Stop(void);

#endif

.c文件：

#include "stepper.h"

static uint8_t Stepper_Direction = 0;

void Stepper_Init(void) { GPIO_InitTypeDef GPIO_InitStructure; TIM_TimeBaseInitTypeDef TIM_TimeBaseStructure; TIM_OCInitTypeDef TIM_OCInitStructure;

// 使能GPIO和TIM时钟
RCC_APB2PeriphClockCmd(RCC_APB2Periph_GPIOA | RCC_APB2Periph_AFIO, ENABLE);
RCC_APB1PeriphClockCmd(RCC_APB1Periph_TIM2, ENABLE);

// 配置PA0和PA1为复用推挽输出
GPIO_InitStructure.GPIO_Pin = GPIO_Pin_0 | GPIO_Pin_1;
GPIO_InitStructure.GPIO_Mode = GPIO_Mode_AF_PP;
GPIO_InitStructure.GPIO_Speed = GPIO_Speed_50MHz;
GPIO_Init(GPIOA, &GPIO_InitStructure);

// TIM2初始化
TIM_TimeBaseStructure.TIM_Period = 999; // PWM周期为1ms
TIM_TimeBaseStructure.TIM_Prescaler = 72 - 1; // TIM2时钟频率为72MHz，分频系数为72，计数频率为1MHz
TIM_TimeBaseStructure.TIM_ClockDivision = TIM_CKD_DIV1;
TIM_TimeBaseStructure.TIM_CounterMode = TIM_CounterMode_Up;
TIM_TimeBaseInit(STEPPER_PWM_TIM, &TIM_TimeBaseStructure);

// TIM2通道1初始化
TIM_OCInitStructure.TIM_OCMode = TIM_OCMode_PWM1;
TIM_OCInitStructure.TIM_OutputState = TIM_OutputState_Enable;
TIM_OCInitStructure.TIM_Pulse = 0;
TIM_OCInitStructure.TIM_OCPolarity = TIM_OCPolarity_High;
TIM_OC1Init(STEPPER_PWM_TIM, &TIM_OCInitStructure);
TIM_OC1PreloadConfig(STEPPER_PWM_TIM, TIM_OCPreload_Enable);

// TIM2通道2初始化
TIM_OCInitStructure.TIM_OCMode = TIM_OCMode_PWM1;
TIM_OCInitStructure.TIM_OutputState = TIM_OutputState_Enable;
TIM_OCInitStructure.TIM_Pulse = 0;
TIM_OCInitStructure.TIM_OCPolarity = TIM_OCPolarity_High;
TIM_OC2Init(STEPPER_PWM_TIM, &TIM_OCInitStructure);
TIM_OC2PreloadConfig(STEPPER_PWM_TIM, TIM_OCPreload_Enable);

// 启动TIM2
TIM_Cmd(STEPPER_PWM_TIM, ENABLE);

}

void Stepper_SetSpeed(uint16_t speed) { uint16_t pulse = 999 - (999 * speed / 100); // speed为0-100，pulse为0-999，速度越快，占空比越小 TIM_SetCompare1(STEPPER_PWM_TIM, pulse); TIM_SetCompare2(STEPPER_PWM_TIM, pulse); }

void Stepper_SetDirection(uint8_t dir) { Stepper_Direction = dir; if (Stepper_Direction) { GPIO_SetBits(GPIOA, GPIO_Pin_0); GPIO_ResetBits(GPIOA, GPIO_Pin_1); } else { GPIO_SetBits(GPIOA, GPIO_Pin_1); GPIO_ResetBits(GPIOA, GPIO_Pin_0); } }

void Stepper_Stop(void) { TIM_SetCompare1(STEPPER_PWM_TIM, 0); TIM_SetCompare2(STEPPER_PWM_TIM, 0); }

以上代码中，使用了TIM2作为PWM输出，PA0和PA1作为TIM2的通道1和通道2的复用推挽输出，通过改变占空比来控制步进电机的速度，通过改变PA0和PA1的电平来控制步进电机的方向。在使用前需要先调用Stepper_Init()函数进行初始化，之后可以使用Stepper_SetSpeed()函数设置步进电机速度，使用Stepper_SetDirection()函数设置步进电机方向，使用Stepper_Stop()函数停止步进电机。
