Python代码实现：基于Dijkstra算法的逻辑网络到物理网络的映射

本文提供了一份Python代码，用于解决将逻辑网络映射到物理网络的问题。代码的目标是在满足以下条件的情况下，为每条逻辑链路找到一条主路径和一条备份路径：

物理网络的一条边可能同时承载逻辑网络多条边的业务。* 配置总负载应小于物理网络边最大承载能力。* 物理网络配置的主路径负载和备份路径负载相同，且不小于逻辑网络的需求。* 负载同一条逻辑边配置的物理主路径和备份路径，尽可能不要有重复的边。* 备份路径资源不允许被其他路径占用。

**代码如下：**pythonimport numpy as npimport pandas as pdimport heapq

def dijkstra(start, end, weights): queue = [(0, start, [])] seen = set() min_distance = {start: 0} while queue: (distance, v, path) = heapq.heappop(queue) if v not in seen: seen.add(v) path = path + [v] if v == end: return np.array(path) + 1 for next_node in range(weights.shape[0]): if weights[v][next_node] > 0 and next_node not in seen: old_distance = min_distance.get(next_node, None) new_distance = min_distance[v] + weights[v][next_node] if old_distance is None or new_distance < old_distance: heapq.heappush(queue, (new_distance, next_node, path)) min_distance[next_node] = new_distance return []

def check_validity(main_path, logical_network, physical_network): if physical_network[main_path[:-1] - 1, main_path[1:] - 1].min() < logical_network[main_path[0] - 1, main_path[-1] - 1]: return False return True

def configure_network(logical_network, physical_network): paths = {} existing_paths = set() max_capacity = physical_network.max()

for i in range(logical_network.shape[0]):        for j in range(i + 1, logical_network.shape[1]):            if logical_network[i, j] > 0:                main_path = dijkstra(i, j, physical_network)                backup_path = dijkstra(i, j, physical_network)                if len(main_path) == 0 or len(backup_path) == 0:                    print(f'Cannot find valid paths for link ({i + 1}, {j + 1}).')                    continue                if not check_validity(main_path, logical_network, physical_network) or not check_validity(backup_path, logical_network, physical_network):                    print(f'Cannot find valid paths for link ({i + 1}, {j + 1}).')                    continue                main_capacity = max(logical_network[i, j], physical_network[main_path[:-1] - 1, main_path[1:] - 1].min())                backup_capacity = max(logical_network[i, j], physical_network[backup_path[:-1] - 1, backup_path[1:] - 1].min())                if main_capacity < logical_network[i, j] or backup_capacity < logical_network[i, j]:                    print(f'Cannot meet the demand for link ({i + 1}, {j + 1}).')                    continue                if main_capacity > max_capacity or backup_capacity > max_capacity:                    print(f'Cannot exceed the maximum capacity for link ({i + 1}, {j + 1}).')                    continue                if tuple(main_path) in existing_paths:                    print(f'Duplicate edges in main path for link ({i + 1}, {j + 1}).')                    continue                paths[(i + 1, j + 1)] = (main_path, backup_path)                physical_network[backup_path[:-1] - 1, backup_path[1:] - 1] -= 10                existing_paths.add(tuple(main_path))    return paths

physical_network = pd.read_excel('物理网络1.xls', header=None).to_numpy()logical_network = pd.read_excel('逻辑网络1.xls', header=None).to_numpy()paths = configure_network(logical_network, physical_network)for link, (main_path, backup_path) in paths.items(): print(f'For link {link}, main path is {main_path}, backup path is {backup_path}.')

代码说明:

dijkstra(start, end, weights) 函数: * 利用Dijkstra算法找到从节点 start 到节点 end 的最短路径。 * weights 是一个二维数组，表示物理网络的连接关系和权重。2. check_validity(main_path, logical_network, physical_network) 函数: * 检查找到的 main_path 是否满足逻辑网络的需求，即路径上的最小容量是否大于等于逻辑链路的需求。3. configure_network(logical_network, physical_network) 函数: * 遍历逻辑网络的每条边，利用 dijkstra 函数找到主备路径，并进行一系列检查，确保找到的路径满足题目要求。 * 将找到的路径存储在 paths 字典中，并更新物理网络的剩余容量。

使用说明:

将代码保存为 .py 文件，例如 network_mapping.py。2. 将物理网络数据存储在 物理网络1.xls 文件中，将逻辑网络数据存储在 逻辑网络1.xls 文件中，并将文件路径修改为代码中对应的路径。3. 运行代码，程序会打印出每条逻辑链路的主备路径。

注意:

代码中的 physical_network[backup_path[:-1] - 1, backup_path[1:] - 1] -= 10 表示为备份路径预留了10个单位的带宽，可以根据实际情况修改。* 代码中假设物理网络和逻辑网络的节点编号从1开始，如果实际编号不同，需要对代码进行相应的修改。

希望这份代码可以帮助您解决问题！
