Raster Graphics System Architecture: A Simple Explanation

A raster-graphics system is used to create and manipulate digital images. The architecture of a simple raster-graphics system consists of the following components:

Frame buffer: The frame buffer is a portion of the computer's memory used to store the pixel data of the image being displayed on the screen. It is a two-dimensional array of memory cells, with each cell representing a pixel on the screen.
Graphics processing unit (GPU): The GPU is responsible for performing operations on the pixel data stored in the frame buffer. It handles tasks like drawing lines, rendering shapes, applying colors, and performing transformations on the image. The GPU works in conjunction with the CPU to process and update the frame buffer.
Display controller: The display controller takes the pixel data from the frame buffer and sends it to the monitor for display. It controls the timing and synchronization of the image display, refreshing the screen at a specific rate to create a continuous display.
Input devices: The input devices, such as a keyboard or mouse, allow the user to interact with the graphics system. They provide input for operations like drawing, selecting, or manipulating objects on the screen.

When an image is to be displayed, the CPU sends the necessary instructions and data to the GPU. The GPU then performs the requested operations on the pixel data stored in the frame buffer. For example, if a line is to be drawn, the GPU calculates the coordinates of the line and updates the corresponding pixels in the frame buffer.

The display controller continuously reads the pixel data from the frame buffer and sends it to the monitor for display. It refreshes the screen at a specific rate (typically 60 times per second) to create smooth motion and animation.

The input devices provide user input to the system, allowing users to interact with the graphics system. For example, if the user wants to draw a shape, the input device relays the coordinates to the CPU, which then instructs the GPU to update the frame buffer accordingly.

Overall, a simple raster-graphics system works by processing and manipulating pixel data stored in the frame buffer using a GPU, which is then displayed on a monitor by the display controller. Input devices allow users to interact with the system, providing instructions for drawing or manipulating images.
