chartjs273显示所有tooltip
要在Chart.js 2.7.3中显示所有的tooltip,可以使用以下代码:
Chart.defaults.global.tooltips.enabled = false;
Chart.defaults.global.tooltips.custom = function(tooltip) {
// Tooltip Element
var tooltipEl = document.getElementById('chartjs-tooltip');
// Create element on first render
if (!tooltipEl) {
tooltipEl = document.createElement('div');
tooltipEl.id = 'chartjs-tooltip';
tooltipEl.innerHTML = '<table></table>';
document.body.appendChild(tooltipEl);
}
// Hide if no tooltip
if (tooltip.opacity === 0) {
tooltipEl.style.opacity = 0;
return;
}
// Set caret Position
tooltipEl.classList.remove('above', 'below', 'no-transform');
if (tooltip.yAlign) {
tooltipEl.classList.add(tooltip.yAlign);
} else {
tooltipEl.classList.add('no-transform');
}
// Set Text
if (tooltip.body) {
var innerHtml = '<thead>';
tooltip.body.forEach(function(bodyItem) {
innerHtml += '<tr><th>' + bodyItem.lines + '</th></tr>';
});
innerHtml += '</thead><tbody>';
tooltip.title.forEach(function(titleItem) {
innerHtml += '<tr><td>' + titleItem + '</td></tr>';
});
innerHtml += '</tbody>';
var tableRoot = tooltipEl.querySelector('table');
tableRoot.innerHTML = innerHtml;
}
// `this` will be the overall tooltip
var position = this._chart.canvas.getBoundingClientRect();
// Display, position, and set styles for font
tooltipEl.style.opacity = 1;
tooltipEl.style.position = 'absolute';
tooltipEl.style.left = position.left + window.pageXOffset + tooltip.caretX + 'px';
tooltipEl.style.top = position.top + window.pageYOffset + tooltip.caretY + 'px';
tooltipEl.style.fontFamily = tooltip._fontFamily;
tooltipEl.style.fontSize = tooltip.fontSize;
tooltipEl.style.fontStyle = tooltip._fontStyle;
tooltipEl.style.padding = tooltip.yPadding + 'px ' + tooltip.xPadding + 'px';
tooltipEl.style.pointerEvents = 'none';
};
这将禁用默认的tooltip,并在鼠标悬停时创建一个自定义的tooltip元素。要使用这个代码,将其放在Chart.js图表的初始化代码中,例如:
var ctx = document.getElementById('myChart').getContext('2d');
var myChart = new Chart(ctx, {
type: 'line',
data: {
// ...
},
options: {
// ...
}
});
Chart.defaults.global.tooltips.enabled = false;
Chart.defaults.global.tooltips.custom = function(tooltip) {
// ...
};
请注意,在这种情况下,您需要在HTML页面中创建一个具有id“chartjs-tooltip”的div元素,以便tooltip能够显示在正确的位置。例如:
<div id="chartjs-tooltip"></div>
希望这可以帮助你显示所有的tooltip!
