Scapegoat Tree 非递归实现：代码逐行解释与测试用例

package net.mooctest;

import java.util.ArrayList;
import java.util.List;
import java.util.Stack;


/**
 * Scapegoat tree non recursive implementation.
 * Warning: not sure if my implementations is really correct, didn't have time to learn more about scapegoat trees.
 *
 * @author Ignas Lelys
 * @created Jul 28, 2011
 *
 */
public class ScapegoatTree extends AbstractSelfBalancingBinarySearchTree {

    /** Alpha parameter. */
    private double alpha = 0.57;

    private int maxSize = 0;

    /**
     * Constructor.
     */
    public ScapegoatTree() {
        super();
    }

    /**
     * Constructor.
     *
     * @param alpha Alpha parameter.
     */
    public ScapegoatTree(double alpha) {
        super();
        this.alpha = alpha;
    }

    /**
     * {@inheritDoc}
     */
    @Override
    public Node insert(int element) {
        Node inserted = super.insert(element);
        int height = getNodeHeight(inserted);
        if (height > getHAlpha()) {
            Node scapegoat = findScapegoatNode(inserted);
            Node scapegoatParent = scapegoat.parent;
            boolean scapegoatOnParentsLeft = scapegoatParent != null && scapegoatParent.left == scapegoat;
            Node rebuiltSubtree = rebuildTree(getSubtreeSize(scapegoat), scapegoat);
            rebuiltSubtree.parent = scapegoatParent;
            if (scapegoatParent != null) {
                if (scapegoatOnParentsLeft) {
                    scapegoatParent.left = rebuiltSubtree;
                } else {
                    scapegoatParent.right = rebuiltSubtree;
                }
            }
            if (scapegoat == root) {
                root = rebuiltSubtree;
            }
            maxSize = getSize();
        }
        return inserted;
    }

    /**
     * {@inheritDoc}
     */
    @Override
    public Node delete(int element) {
        Node replaceNode = super.delete(element);
        if (getSize() <= alpha * maxSize) {
            root = rebuildTree(getSize(), root);
            maxSize = getSize();
        }
        return replaceNode;
    }

    /**
     * {@inheritDoc}
     */
    @Override
    protected Node createNode(int value, Node parent, Node left, Node right) {
        return new Node(value, parent, left, right);
    }

    /**
     * Finds scapegoat node which is used for rebalancing the tree.
     *
     * @return Scapegoat node.
     */
    protected Node findScapegoatNode(Node node) {
        int size = 1;
        int height = 0;
        int totalSize = 0;
        while (node.parent != null) {
            height++;
            totalSize = 1 + size + getSubtreeSize(getSibling(node));
            if (height > Math.floor(MathUtils.logarithm(1 / alpha, totalSize))) {
                return node.parent;
            }
            node = node.parent;
            size = totalSize;
        }
        return null;
    }

    /**
     * Rebuilds unbalanced tree.
     * Found this implementation much clearer and easier to make it work: https://github.com/satchamo/Scapegoat-Tree/blob/master/scapegoat.py
     * Could't get implementations from pdfs to work.
     *
     * @param size Size of subtree.
     * @param scapegoat Scapegoat is the root of subtree of {@link size} number of nodes.
     *
     * @return Balanced subtree.
     */
    protected Node rebuildTree(int size, Node scapegoat) {
        List<Node> nodes = new ArrayList<Node>();

        // flatten tree without recursion
        Node currentNode = scapegoat;
        boolean done = false;
        Stack<Node> stack = new Stack<>();
        while (!done) {
            if (currentNode != null) {
                stack.push(currentNode);
                currentNode = currentNode.left;
            } else {
                if (!stack.isEmpty()) {
                    currentNode = stack.pop();
                    nodes.add(currentNode);
                    currentNode = currentNode.right;
                } else {
                    done = true;
                }
            }
        }

        // build tree from flattened list of nodes
        return buildTree(nodes, 0, size - 1);
    }

    /**
     * Build balanced tree from flattened tree.
     */
    private Node buildTree(List<Node> nodes, int start, int end) {
        int middle = (int)Math.ceil(((double)(start + end)) / 2.0);
        if (start > end) {
            return null;
        }

        // middle becomes root of subtree instead of scapegoat
        Node node = nodes.get(middle);

        // recursively get left and right nodes
        Node leftNode = buildTree(nodes, start, middle - 1);
        node.left = leftNode;
        if (leftNode != null) {
            leftNode.parent = node;
        }
        Node rightNode = buildTree(nodes, middle + 1, end);
        node.right = rightNode;
        if (rightNode != null) {
            rightNode.parent = node;
        }
        return node;
    }

    /**
     * @return Node's sibling.
     */
    // TODO move to AbstractBinaySearchTree and use in other trees where needed.
    private Node getSibling(Node node) {
        if (node.parent != null) {
            if (node.parent.left == node) {
                return node.parent.right;
            } else {
                return node.parent.left;
            }
        }
        return null;
    }

    /**
     * Calculate size of subtree.
     *
     * @param node
     *            Subtree root node.
     * @return Number of elements in the subtree.
     */
    // TODO move to AbstractBinaySearchTree
    protected int getSubtreeSize(Node node) {
        if (node == null) {
            return 0;
        }
        if (node.isLeaf()) {
            return 1;
        } else {
            int sum = 1;
            sum += getSubtreeSize(node.left);
            sum += getSubtreeSize(node.right);
            return sum;
        }
    }

    // TODO move to AbstractBinaySearchTree
    protected int getNodeHeight(Node node) {
        if (node == null) {
            return -1;
        } else if (node.parent == null) {
            return 0;
        } else {
            return getNodeHeight(node.parent) + 1;
        }
    }

    private int getHAlpha() {
        return (int)Math.floor(MathUtils.logarithm(1 / alpha, (double)getSize()));
    }

}

以下是一个针对ScapegoatTree类的标准测试用例：

package net.mooctest;

import org.junit.Test;
import static org.junit.Assert.*;

public class ScapegoatTreeTest {

    @Test
    public void testInsert() {
        ScapegoatTree tree = new ScapegoatTree();

        tree.insert(10);
        assertEquals(1, tree.getSize()); // 验证插入后树的大小为1

        tree.insert(5);
        assertEquals(2, tree.getSize()); // 验证插入后树的大小为2

        tree.insert(15);
        assertEquals(3, tree.getSize()); // 验证插入后树的大小为3

        tree.insert(7);
        assertEquals(4, tree.getSize()); // 验证插入后树的大小为4
    }

    @Test
    public void testDelete() {
        ScapegoatTree tree = new ScapegoatTree();

        tree.insert(10);
        tree.insert(5);
        tree.insert(15);
        tree.insert(7);

        tree.delete(5);
        assertEquals(3, tree.getSize()); // 验证删除后树的大小为3

        tree.delete(7);
        assertEquals(2, tree.getSize()); // 验证删除后树的大小为2

        tree.delete(15);
        assertEquals(1, tree.getSize()); // 验证删除后树的大小为1
    }

    @Test
    public void testRebuildTree() {
        ScapegoatTree tree = new ScapegoatTree();

        tree.insert(10);
        Node scapegoat = tree.insert(5);
        tree.insert(15);
        tree.insert(7);

        Node rebuitTree = tree.rebuildTree(tree.getSubtreeSize(scapegoat), scapegoat);

        assertEquals(scapegoat.value, rebuitTree.value); // 验证重建后的树根节点的值与原节点的值相同
        assertEquals(scapegoat.left.value, rebuitTree.left.value); // 验证重建后的树的左子树与原节点的左子树相同
        assertEquals(scapegoat.right.value, rebuitTree.right.value); // 验证重建后的树的右子树与原节点的右子树相同
    }

    @Test
    public void testFindScapegoatNode() {
        ScapegoatTree tree = new ScapegoatTree();

        Node scapegoat = tree.insert(10);
        tree.insert(5);
        tree.insert(15);
        tree.insert(7);

        Node foundScapegoat = tree.findScapegoatNode(scapegoat);

        assertEquals(scapegoat.parent, foundScapegoat); // 验证找到的scapegoat节点的父节点与给定的节点的父节点相同
    }

    @Test
    public void testGetSibling() {
        ScapegoatTree tree = new ScapegoatTree();

        Node parent = tree.insert(10);
        Node leftChild = tree.insert(5);
        Node rightChild = tree.insert(15);

        Node sibling = tree.getSibling(leftChild);
        assertEquals(rightChild, sibling); // 验证左子节点的兄弟节点为右子节点

        sibling = tree.getSibling(rightChild);
        assertEquals(leftChild, sibling); // 验证右子节点的兄弟节点为左子节点

        sibling = tree.getSibling(parent);
        assertNull(sibling); // 验证根节点的兄弟节点为空
    }

    @Test
    public void testGetSubtreeSize() {
        ScapegoatTree tree = new ScapegoatTree();

        Node scapegoat = tree.insert(10);
        tree.insert(5);
        tree.insert(15);
        tree.insert(7);

        int subtreeSize = tree.getSubtreeSize(scapegoat);
        assertEquals(4, subtreeSize); // 验证获取到的子树大小为4
    }

    @Test
    public void testGetNodeHeight() {
        ScapegoatTree tree = new ScapegoatTree();

        Node node = tree.insert(10);
        tree.insert(5);
        tree.insert(15);
        tree.insert(7);

        int nodeHeight = tree.getNodeHeight(node);
        assertEquals(2, nodeHeight); // 验证节点的高度为2
    }

    @Test
    public void testGetHAlpha() {
        ScapegoatTree tree = new ScapegoatTree();

        tree.insert(10);
        tree.insert(5);
        tree.insert(15);
        tree.insert(7);

        int hAlpha = tree.getHAlpha();
        assertEquals(1, hAlpha); // 验证hAlpha计算正确
    }

}
