Python决策树算法实现与可视化

from math import log
import operator
from sklearn import tree
import graphviz

def calcShannonEnt(dataSet):  # 计算数据的熵(entropy)
    numEntries = len(dataSet)  # 数据条数
    labelCounts = {}
    for featVec in dataSet:
        currentLabel = featVec[-1] # 每行数据的最后一个字（类别）
        if currentLabel not in labelCounts.keys():
            labelCounts[currentLabel] = 0
        labelCounts[currentLabel] += 1  # 统计有多少个类以及每个类的数量
    shannonEnt = 0
    for key in labelCounts:
        prob = float(labelCounts[key]) / numEntries # 计算单个类的熵值
        shannonEnt -= prob * log(prob, 2) # 累加每个类的熵值
    return shannonEnt

def createDataSet1():    # 创造示例数据
    dataSet = [['长', '粗', '男'],
               ['短', '粗', '男'],
               ['短', '粗', '男'],
               ['长', '细', '女'],
               ['短', '细', '女'],
               ['短', '粗', '女'],
               ['长', '粗', '女'],
               ['长', '粗', '女']]
    labels = ['头发','声音']  #两个特征
    return dataSet,labels

def splitDataSet(dataSet, axis, value): # 按某个特征分类后的数据
    retDataSet=[]
    for featVec in dataSet:
        if featVec[axis] == value:
            reducedFeatVec = featVec[:axis]
            reducedFeatVec.extend(featVec[axis+1:])
            retDataSet.append(reducedFeatVec)
    return retDataSet

def chooseBestFeatureToSplit(dataSet):  # 选择最优的分类特征
    numFeatures = len(dataSet[0]) - 1
    baseEntropy = calcShannonEnt(dataSet)  # 原始的熵
    bestInfoGain = 0
    bestFeature = -1
    for i in range(numFeatures):
        featList = [example[i] for example in dataSet]
        uniqueVals = set(featList)
        newEntropy = 0
        for value in uniqueVals:
            subDataSet = splitDataSet(dataSet, i, value)
            prob = len(subDataSet) / float(len(dataSet))
            newEntropy += prob * calcShannonEnt(subDataSet)  # 按特征分类后的熵
        infoGain = baseEntropy - newEntropy  # 原始熵与按特征分类后的熵的差值
        if infoGain > bestInfoGain:   # 若按某特征划分后，熵值减少的最大，则次特征为最优分类特征
            bestInfoGain = infoGain
            bestFeature = i
    return bestFeature

def majorityCnt(classList):    #按分类后类别数量排序，比如：最后分类为2男1女，则判定为男；
    classCount={}
    for vote in classList:
        if vote not in classCount.keys():
            classCount[vote]=0
        classCount[vote] += 1
    sortedClassCount = sorted(classCount.items(),key=operator.itemgetter(1),reverse=True)
    return sortedClassCount[0][0]

def createTree(dataSet, labels):
    classList = [example[-1] for example in dataSet]  # 类别：男或女
    if classList.count(classList[0]) == len(classList):
        return classList[0]
    if len(dataSet[0]) == 1:
        return majorityCnt(classList)
    bestFeat = chooseBestFeatureToSplit(dataSet) #选择最优特征
    bestFeatLabel = labels[bestFeat]
    myTree = {bestFeatLabel: {}} #分类结果以字典形式保存
    del(labels[bestFeat])
    featValues = [example[bestFeat] for example in dataSet]
    uniqueVals = set(featValues)
    for value in uniqueVals:
        subLabels = labels[:]
        myTree[bestFeatLabel][value] = createTree(splitDataSet(dataSet, bestFeat, value), subLabels)
    return myTree

if __name__ == '__main__':
    dataSet, labels = createDataSet1()  # 创造示列数据
    print('手动实现决策树:\n', createTree(dataSet, labels))  # 输出决策树模型结果

    # 数据编码
    data_encoded = [[0, 0, 0], [1, 0, 0], [1, 0, 0], [0, 1, 1],
                    [1, 1, 1], [1, 0, 1], [0, 0, 1], [0, 0, 1]]

    # 分离特征和标签
    X = [item[:-1] for item in data_encoded]
    y = [item[-1] for item in data_encoded]

    # 创建决策树分类器并训练
    clf = tree.DecisionTreeClassifier()
    clf = clf.fit(X, y)
    dot_data = tree.export_graphviz(clf, out_file=None,
                                    feature_names=['头发', '声音'],
                                    class_names=['男', '女'],
                                    filled=True, rounded=True,
                                    special_characters=True)
    graph = graphviz.Source(dot_data)
    graph.render('decision_tree')  # 保存决策树图像为 decision_tree.pdf
    # graph  # 在 Jupyter Notebook 中显示决策树
