在这个互联网普及的时代人们将互联网的使用从工作带到了生活中。智能家居是互联网家居走进人们生活的一大步。但随着生活节奏的加快科技的不断创新人们对生活的品质要求越来越高智能小家电产品走进了人们的生活中。本文是基于WiFi的智能养生壶设计。该设计主要是对电路板进行设计以实现智能养生壶4种形式的加热功能、基本的保护功能和记忆功能。除此之外本设计对手机APP端也进行了设计以实现手机APP端对智能养生壶的控制

In this era of widespread internet use, people have brought internet usage from work into their daily lives. Smart home technology is a major step for internet-based homes entering people's lives. However, as the pace of life accelerates and technology continuously innovates, people's demands for quality of life are increasing, and smart small home appliances have entered people's lives. This article is based on the design of a WiFi-based smart health pot. The design mainly involves the design of the circuit board to achieve four forms of heating functions, basic protection functions, and memory functions. In addition, this design also includes the design of a mobile app to control the smart health pot.

This article proposes a hardware design for a WiFi-based smart health pot, which has functions such as automatic temperature control, water level detection, and intelligent reminders. The hardware design uses the STM32 microcontroller as the main control chip and communicates with the mobile app through the WiFi module to achieve remote control and data transmission. At the same time, a water level detection circuit and temperature control circuit are designed to achieve automatic adjustment of the water temperature in the pot and real-time monitoring of the water level. Finally, based on the hardware design, a connection with the mobile app is established to achieve remote control and data display functions for the health pot. The aim of this design is to create a WiFi-based smart health pot that can achieve multiple functions such as water temperature and water level monitoring and control, as well as intelligent reminders, to meet users' demands for high-quality, intelligent, and healthy living. The health pot uses multiple sensors such as temperature sensors and water level sensors, and communicates with the mobile app through the WiFi module, allowing users to remotely monitor and control various parameters of the health pot.

The smart health pot is a smart home product that combines traditional health tea culture with modern technology. Its main functions include insulation, boiling water, cooking, and temperature adjustment, and users can control the pot's working status through the mobile app. The control module of the pot uses the ESP8266 microcontroller, which integrates the WiFi module and microcontroller to achieve communication between the pot and the user's mobile app. The control module also includes temperature sensors, water level sensors, and more. The temperature control module controls the water temperature by controlling the heating module's heating time and temperature. The water level detection module detects the water level to ensure that the heating module does not become damaged due to lack of water. The pot's power module uses an AC-DC converter to convert the mains voltage of 220V into the low voltage power required for the pot's operation. The power module also includes a power management chip that can charge and manage the battery to ensure stable operation of the pot. The pot's display module uses an OLED display screen to display the pot's working status, temperature, time, and other information. The display module also includes touch buttons and indicator lights for user operation and status display. In addition, this article uses a WiFi module to connect to the cloud platform, achieving remote control and data transmission. Through the mobile app, users can control the pot's heating and insulation at any time, as well as view parameters such as water temperature and quantity.

Finally, through multiple experiments, this design is proven to be feasible.
