Kintex-7 上基于 HLS 2018.3 的 Bayer 转 RGB 代码示例

#include "hls_video.h"

#define WIDTH 640 #define HEIGHT 480

typedef ap_axiu<24,1,1,1> AXI_STREAM;

void bayer2rgb(hls::stream<AXI_STREAM>& stream_in, hls::stream<AXI_STREAM>& stream_out) { #pragma HLS INTERFACE axis port=stream_in #pragma HLS INTERFACE axis port=stream_out

hls::Mat<HEIGHT, WIDTH, HLS_8UC1> bayer(HEIGHT, WIDTH);
hls::Mat<HEIGHT, WIDTH, HLS_8UC3> rgb(HEIGHT, WIDTH);

AXI_STREAM in_data;
AXI_STREAM out_data;

// Convert AXI4 Stream to OpenCV Mat
for (int i = 0; i < HEIGHT; i++) {
    for (int j = 0; j < WIDTH; j++) {
        #pragma HLS PIPELINE
        stream_in.read(in_data);
        bayer.data[i][j] = in_data.data;
    }
}

// Bayer to RGB conversion
for (int i = 0; i < HEIGHT; i++) {
    for (int j = 0; j < WIDTH; j++) {
        #pragma HLS PIPELINE
        if (i % 2 == 0 && j % 2 == 0) {
            rgb.data[i][j*3]   = bayer.data[i][j];     // R
            rgb.data[i][j*3+1] = (bayer.data[i][j] + bayer.data[i][j+1]) / 2;   // G
            rgb.data[i][j*3+2] = bayer.data[i][j+1];   // B
        }
        else if (i % 2 == 0 && j % 2 == 1) {
            rgb.data[i][j*3]   = (bayer.data[i][j-1] + bayer.data[i][j]) / 2;   // R
            rgb.data[i][j*3+1] = bayer.data[i][j];     // G
            rgb.data[i][j*3+2] = (bayer.data[i][j] + bayer.data[i][j+1]) / 2;   // B
        }
        else if (i % 2 == 1 && j % 2 == 0) {
            rgb.data[i][j*3]   = (bayer.data[i-1][j] + bayer.data[i][j]) / 2;   // R
            rgb.data[i][j*3+1] = bayer.data[i][j];     // G
            rgb.data[i][j*3+2] = (bayer.data[i][j] + bayer.data[i+1][j]) / 2;   // B
        }
        else {
            rgb.data[i][j*3]   = bayer.data[i][j-1];   // R
            rgb.data[i][j*3+1] = (bayer.data[i][j-1] + bayer.data[i][j]) / 2;   // G
            rgb.data[i][j*3+2] = bayer.data[i][j];     // B
        }
    }
}

// Convert OpenCV Mat to AXI4 Stream
for (int i = 0; i < HEIGHT; i++) {
    for (int j = 0; j < WIDTH; j++) {
        #pragma HLS PIPELINE
        out_data.data = rgb.data[i][j*3] + (rgb.data[i][j*3+1] << 8) + (rgb.data[i][j*3+2] << 16);
        out_data.keep = 0xFF;
        out_data.strb = 0xFF;
        out_data.user = 0;
        out_data.last = 0;
        out_data.id = 0;
        out_data.dest = 0;
        stream_out.write(out_data);
    }
}

}
