Android 自定义上滑抽屉:不使用 DrawerLayout 和 BottomSheetDialog
有多种方法可以实现上滑抽屉,以下是其中一种方式:
- 在布局文件中定义一个线性布局,将其设置为隐藏,并设置其高度为0dp。
<LinearLayout
android:id='@+id/bottom_sheet'
android:layout_width='match_parent'
android:layout_height='0dp'
android:orientation='vertical'
android:background='@android:color/white'
android:elevation='8dp'
android:visibility='gone'
>
<!-- 在这里添加抽屉内容 -->
</LinearLayout>
- 在Activity中,定义一个变量来保存布局文件中的LinearLayout对象,并使用GestureDetector类来检测手势。
public class MainActivity extends AppCompatActivity implements GestureDetector.OnGestureListener {
private GestureDetectorCompat gestureDetector;
private LinearLayout bottomSheet;
@Override
protected void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.activity_main);
bottomSheet = findViewById(R.id.bottom_sheet);
gestureDetector = new GestureDetectorCompat(this, this);
}
@Override
public boolean onTouchEvent(MotionEvent event) {
gestureDetector.onTouchEvent(event);
return super.onTouchEvent(event);
}
@Override
public boolean onDown(MotionEvent e) {
return true;
}
@Override
public boolean onFling(MotionEvent e1, MotionEvent e2, float velocityX, float velocityY) {
if (e2.getY() - e1.getY() > 100 && Math.abs(velocityY) > 100) {
showBottomSheet();
return true;
} else if (e1.getY() - e2.getY() > 100 && Math.abs(velocityY) > 100) {
hideBottomSheet();
return true;
}
return false;
}
@Override
public void onLongPress(MotionEvent e) {}
@Override
public boolean onScroll(MotionEvent e1, MotionEvent e2, float distanceX, float distanceY) {
return false;
}
@Override
public void onShowPress(MotionEvent e) {}
@Override
public boolean onSingleTapUp(MotionEvent e) {
return false;
}
private void showBottomSheet() {
bottomSheet.setVisibility(View.VISIBLE);
bottomSheet.animate().translationY(0).setDuration(500).start();
}
private void hideBottomSheet() {
bottomSheet.animate().translationY(bottomSheet.getHeight()).setDuration(500).withEndAction(new Runnable() {
@Override
public void run() {
bottomSheet.setVisibility(View.GONE);
}
}).start();
}
}
- 在onFling()方法中检测手势,如果检测到向上滑动,则调用showBottomSheet()方法来显示抽屉,如果检测到向下滑动,则调用hideBottomSheet()方法来隐藏抽屉。
这种方法的效果类似于BottomSheetDialog,但是没有使用DrawerLayout,而是使用了手势检测来实现上滑抽屉的效果。
