MATLAB代码：读取实验原理中的水平模板图像并提取直线度

% 读取水平模板图像 I = imread('horiz_template.png');

% 转换为灰度图像 Igray = rgb2gray(I);

% 二值化图像 thresh = graythresh(Igray); Ibw = imbinarize(Igray, thresh);

% 去除小的噪点 Iclean = bwareaopen(Ibw, 50);

% 提取水平直线 [H,theta,rho] = hough(Iclean,'Theta',-90:0.1:90); P = houghpeaks(H,5,'threshold',ceil(0.3*max(H(:)))); lines = houghlines(Iclean,theta,rho,P,'FillGap',5,'MinLength',7);

% 绘制直线 figure, imshow(Igray), hold on max_len = 0; for k = 1:length(lines) xy = [lines(k).point1; lines(k).point2];

% 计算直线长度 len = norm(lines(k).point1 - lines(k).point2);

% 仅绘制长度较长的直线 if ( len > max_len) max_len = len; xy_long = xy; end end plot(xy_long(:,1),xy_long(:,2),'LineWidth',2,'Color','red');

% 计算直线的角度 angle = atan2(abs(xy_long(1,2)-xy_long(2,2)),abs(xy_long(1,1)-xy_long(2,1)))*180/pi; fprintf('水平直线的角度为：%f ', angle);
