基于深度学习的肺部病灶分割代码解析：Unet 模型实现与网络结构分析

这段代码是一个基于深度学习的图像分割任务，使用 Unet 模型进行肺部病灶分割。

首先，导入必要的库和数据集路径。

import os
import sys
import random

import numpy as np
import cv2
import matplotlib.pyplot as plt


from tensorflow import keras
import tensorflow as tf
import cv2
import os
import tensorflow as tf
import numpy as np
from sklearn.model_selection import train_test_split
from keras.preprocessing.image import ImageDataGenerator
from tqdm import tqdm
#gpus = tf.config.list_physical_devices(device_type='GPU')
#for gpu in gpus:
#    tf.config.experimental.set_memory_growth(device=gpu, enable=True)
os.environ['CUDA_VISIBLE_DEVICES']='2'
dir_img="Train_Data/Images/"
dir_mask="Train_Data/Vts/"

width=512
height=512
channels=3

tab_img=[]
tab_mask=[]

for n, i in tqdm(enumerate(os.listdir(dir_img)), total=len(os.listdir(dir_img))):
    tab_img.append(cv2.resize(cv2.imread(dir_img+i), (width, height))/255)

    img_mask=cv2.resize(cv2.imread(dir_mask+i), (width, height))[:,:,2]
    img_mask_result=np.zeros(shape=(height, width, 1), dtype=np.float32)
    img_mask_result[:,:,0][img_mask==255]=1.
    tab_mask.append(img_mask_result)

tab_img=np.array(tab_img)
tab_mask=np.array(tab_mask)


from keras.preprocessing import image

# Creating the training Image and Mask generator
image_datagen = image.ImageDataGenerator(shear_range=0.5, rotation_range=50, zoom_range=0.2, width_shift_range=0.2, height_shift_range=0.2, fill_mode='reflect')
mask_datagen = image.ImageDataGenerator(shear_range=0.5, rotation_range=50, zoom_range=0.2, width_shift_range=0.2, height_shift_range=0.2, fill_mode='reflect')

seed = 42
image_datagen.fit(tab_img[:int(tab_img.shape[0]*0.9)], augment=True, seed=seed)
mask_datagen.fit(tab_mask[:int(tab_mask.shape[0]*0.9)], augment=True, seed=seed)

BATCH_SIZE = 16
x=image_datagen.flow(tab_img[:int(tab_img.shape[0]*0.9)],batch_size=BATCH_SIZE,shuffle=True, seed=seed)
y=mask_datagen.flow(tab_mask[:int(tab_mask.shape[0]*0.9)],batch_size=BATCH_SIZE,shuffle=True, seed=seed)

# Creating the validation Image and Mask generator
image_datagen_val = image.ImageDataGenerator()
mask_datagen_val = image.ImageDataGenerator()

image_datagen_val.fit(tab_img[int(tab_img.shape[0]*0.9):], augment=True, seed=seed)
mask_datagen_val.fit(tab_mask[int(tab_mask.shape[0]*0.9):], augment=True, seed=seed)

x_val=image_datagen_val.flow(tab_img[int(tab_img.shape[0]*0.9):],batch_size=BATCH_SIZE,shuffle=True, seed=seed)
y_val=mask_datagen_val.flow(tab_mask[int(tab_mask.shape[0]*0.9):],batch_size=BATCH_SIZE,shuffle=True, seed=seed)

#creating a training and validation generator that generate masks and images
train_generator = zip(x, y)
val_generator = zip(x_val, y_val)

Valid_dir_img="Valid_Data/Images/"
Valid_dir_mask="Valid_Data/Vts/"

width=512
height=512
channels=3

Valid_tab_img=[]
Valid_tab_mask=[]

for n, i in tqdm(enumerate(os.listdir(Valid_dir_img)), total=len(os.listdir(Valid_dir_img))):
    Valid_tab_img.append(cv2.resize(cv2.imread(Valid_dir_img+i), (width, height))/255)

    img_mask=cv2.resize(cv2.imread(Valid_dir_mask+i), (width, height))[:,:,2]
    img_mask_result=np.zeros(shape=(height, width, 1), dtype=np.float32)
    img_mask_result[:,:,0][img_mask==255]=1.
    Valid_tab_mask.append(img_mask_result)

Valid_tab_img=np.array(Valid_tab_img)
Valid_tab_mask=np.array(Valid_tab_mask)

from keras.preprocessing import image

# Creating the training Image and Mask generator
image_datagen = image.ImageDataGenerator(shear_range=0.5, rotation_range=50, zoom_range=0.2, width_shift_range=0.2, height_shift_range=0.2, fill_mode='reflect')
mask_datagen = image.ImageDataGenerator(shear_range=0.5, rotation_range=50, zoom_range=0.2, width_shift_range=0.2, height_shift_range=0.2, fill_mode='reflect')

seed = 42
image_datagen.fit(tab_img, augment=True, seed=seed)
mask_datagen.fit(tab_mask, augment=True, seed=seed)

BATCH_SIZE = 16
x=image_datagen.flow(tab_img,batch_size=BATCH_SIZE,shuffle=True, seed=seed)
y=mask_datagen.flow(tab_mask,batch_size=BATCH_SIZE,shuffle=True, seed=seed)

# Creating the validation Image and Mask generator
image_datagen_val = image.ImageDataGenerator()
mask_datagen_val = image.ImageDataGenerator()

image_datagen_val.fit(Valid_tab_img, augment=True, seed=seed)
mask_datagen_val.fit(Valid_tab_mask, augment=True, seed=seed)

x_val=image_datagen_val.flow(Valid_tab_img,batch_size=BATCH_SIZE,shuffle=True, seed=seed)
y_val=mask_datagen_val.flow(Valid_tab_mask,batch_size=BATCH_SIZE,shuffle=True, seed=seed)

#creating a training and validation generator that generate masks and images
train_generator = zip(x, y)
val_generator = zip(x_val, y_val)

#pip install segmentation-models

from segmentation_models import Unet
import segmentation_models as sm
sm.set_framework('tf.keras')
sm.framework()
model = Unet('resnet34', encoder_weights='imagenet', classes=1, input_shape=(512,512, 3), activation='sigmoid')

model.compile('Adam', loss="binary_crossentropy", metrics=["acc"])
model.summary()
from keras.models import load_model
#model.load_weights('Unet_weights.h5')

results = model.fit_generator(train_generator, validation_data=val_generator, validation_steps=500, steps_per_epoch=100,epochs=100)
model.save_weights('Unet_weights.h5')



def SEG_EVAL(Seg,GT):
    # Seg : Segmented image, must be binary (1 = regions of interest 0 = background)
    # GT : Ground truth, must be binary (1 = regions of interest 0 = background)
    Seg.astype(np.bool)
    GT.astype(np.bool)

    #dice_coefficient
    intersection = np.logical_and(Seg, GT)
    dice_coefficient = 2. * intersection.sum() / (Seg.sum() + GT.sum())

    #IoU
    TP = np.logical_and(Seg, GT)
    IoU = TP.sum() / (GT.sum() + Seg.sum() - TP.sum())

    #recall
    recall = TP.sum() / GT.sum()

    #precision
    precision = TP.sum() / Seg.sum()

    EVAL = [dice_coefficient,IoU,recall,precision]

    return EVAL

def VIS_EVAL(Image, Seg, GT, option = 'contour'):
    # Image : Gray image
    # Seg : Segmented image, must be binary (1 = regions of interest 0 = background)
    # GT : Ground truth, must be binary (1 = regions of interest 0 = background)
    # option = 'contour' For contour plotting
    # option = 'region' For color the region

    Image = cv2.cvtColor(np.array(Image, np.uint8), cv2.COLOR_GRAY2RGB)
    GT = np.array(255*GT, dtype=np.uint8)
    Seg = np.array(255*Seg, dtype=np.uint8)
    GT = cv2.cvtColor(GT, cv2.COLOR_GRAY2RGB)
    Seg = cv2.cvtColor(Seg, cv2.COLOR_GRAY2RGB)

    if option == 'region':
        GT[:, :, 1:2] = 0*GT[:, :, 1:2]
        Seg[:, :, 0] = 0*Seg[:, :, 0]
        Seg[:, :, 2] = 0*Seg[:, :, 2]

        VIS_Seg = cv2.addWeighted(Image, 1, Seg, 0.5, 0)
        VIS_GT = cv2.addWeighted(Image, 1, GT, 0.5, 0)

    elif option == 'contour':

        contours_GT = cv2.Canny(GT, 250, 260)
        contours_Seg = cv2.Canny(Seg, 250, 260)

        contours_GT = cv2.cvtColor(contours_GT, cv2.COLOR_GRAY2RGB)
        contours_Seg = cv2.cvtColor(contours_Seg, cv2.COLOR_GRAY2RGB)

        contours_GT[:, :, 1:2] = 0*contours_GT[:, :, 1:2]
        contours_Seg[:, :, 0] = 0*contours_Seg[:, :, 0]
        contours_Seg[:, :, 2] = 0*contours_Seg[:, :, 2]

        VIS_Seg = cv2.addWeighted(Image, 1, contours_Seg, 0.5, 0)
        VIS_GT = cv2.addWeighted(Image, 1, contours_GT, 0.5, 0)

    return VIS_Seg,VIS_GT

dir_img = "Test_Data/Images/"
dir_mask = "Test_Data/Vts/"
Eval = []

Dice = []
TP = []
FP = []

width=512
height=512
channels=3

for i in os.listdir(dir_img):
    Image_Test = cv2.resize(cv2.imread(dir_img+i), (width, height))/255
    Image = cv2.resize(cv2.imread(dir_img+i), (width, height))[:,:,2]
    VT=cv2.resize(cv2.imread(dir_mask+i), (width, height))[:,:,2]
    VT=(VT==255).astype(int)

    Image_Test = np.expand_dims(Image_Test, axis=0)
    Seg = model.predict(Image_Test)
    Seg = ((Seg[0,:,:,0]*255)>5).astype(int)

    Eval.append(SEG_EVAL(Seg,VT))

    VIS_Seg,VIS_GT=VIS_EVAL(Image, Seg, VT, option = 'contour')
    cv2.imwrite('CNN_Results/Seg_'+i, VIS_Seg)
    cv2.imwrite('CNN_Results/GT_'+i, VIS_GT)
    #cv2.imwrite('FPN_Results/Mask_Seg_'+i, Seg)

np.savetxt("CNN_Results.csv", Eval, delimiter=",")


然后，通过OpenCV库读取图像，并将其缩放为512×512像素大小。

for n, i in tqdm(enumerate(os.listdir(dir_img)), total=len(os.listdir(dir_img))):
    tab_img.append(cv2.resize(cv2.imread(dir_img+i), (width, height))/255)

接下来，从每个图像中提取肺部病灶掩码。掩码是二进制图像，其中1代表图像中的肺部病灶，0代表背景。

    img_mask=cv2.resize(cv2.imread(dir_mask+i), (width, height))[:,:,2]
    img_mask_result=np.zeros(shape=(height, width, 1), dtype=np.float32)
    img_mask_result[:,:,0][img_mask==255]=1.
    tab_mask.append(img_mask_result)

这些图像和掩码数据被分别存储在tab_img和tab_mask数组中。

在这里，使用了数据增强技术来扩充训练数据集，包括旋转、剪切、缩放等。

# Creating the training Image and Mask generator
image_datagen = image.ImageDataGenerator(shear_range=0.5, rotation_range=50, zoom_range=0.2, width_shift_range=0.2, height_shift_range=0.2, fill_mode='reflect')
mask_datagen = image.ImageDataGenerator(shear_range=0.5, rotation_range=50, zoom_range=0.2, width_shift_range=0.2, height_shift_range=0.2, fill_mode='reflect')

seed = 42
image_datagen.fit(tab_img[:int(tab_img.shape[0]*0.9)], augment=True, seed=seed)
mask_datagen.fit(tab_mask[:int(tab_mask.shape[0]*0.9)], augment=True, seed=seed)

然后，使用Keras的生成器函数将增强的数据提供给模型进行训练。

BATCH_SIZE = 16
x=image_datagen.flow(tab_img[:int(tab_img.shape[0]*0.9)],batch_size=BATCH_SIZE,shuffle=True, seed=seed)
y=mask_datagen.flow(tab_mask[:int(tab_mask.shape[0]*0.9)],batch_size=BATCH_SIZE,shuffle=True, seed=seed)

# Creating the validation Image and Mask generator
image_datagen_val = image.ImageDataGenerator()
mask_datagen_val = image.ImageDataGenerator()

image_datagen_val.fit(tab_img[int(tab_img.shape[0]*0.9):], augment=True, seed=seed)
mask_datagen_val.fit(tab_mask[int(tab_mask.shape[0]*0.9):], augment=True, seed=seed)

x_val=image_datagen_val.flow(tab_img[int(tab_img.shape[0]*0.9):],batch_size=BATCH_SIZE,shuffle=True, seed=seed)
y_val=mask_datagen_val.flow(tab_mask[int(tab_mask.shape[0]*0.9):],batch_size=BATCH_SIZE,shuffle=True, seed=seed)

#creating a training and validation generator that generate masks and images
train_generator = zip(x, y)
val_generator = zip(x_val, y_val)

在这里，使用了Unet模型，该模型使用ResNet34作为编码器。

#pip install segmentation-models

from segmentation_models import Unet
import segmentation_models as sm
sm.set_framework('tf.keras')
sm.framework()
model = Unet('resnet34', encoder_weights='imagenet', classes=1, input_shape=(512,512, 3), activation='sigmoid')

model.compile('Adam', loss="binary_crossentropy", metrics=["acc"])
model.summary()
from keras.models import load_model
#model.load_weights('Unet_weights.h5')

results = model.fit_generator(train_generator, validation_data=val_generator, validation_steps=500, steps_per_epoch=100,epochs=100)
model.save_weights('Unet_weights.h5')

最后，对测试数据进行肺部病灶分割，并将结果与真实掩码进行比较并评估模型的性能。评估指标包括Dice系数、IoU、召回率和精确度。

def SEG_EVAL(Seg,GT):
    # Seg : Segmented image, must be binary (1 = regions of interest 0 = background)
    # GT : Ground truth, must be binary (1 = regions of interest 0 = background)
    Seg.astype(np.bool)
    GT.astype(np.bool)

    #dice_coefficient
    intersection = np.logical_and(Seg, GT)
    dice_coefficient = 2. * intersection.sum() / (Seg.sum() + GT.sum())

    #IoU
    TP = np.logical_and(Seg, GT)
    IoU = TP.sum() / (GT.sum() + Seg.sum() - TP.sum())

    #recall
    recall = TP.sum() / GT.sum()

    #precision
    precision = TP.sum() / Seg.sum()

    EVAL = [dice_coefficient,IoU,recall,precision]

    return EVAL

def VIS_EVAL(Image, Seg, GT, option = 'contour'):
    # Image : Gray image
    # Seg : Segmented image, must be binary (1 = regions of interest 0 = background)
    # GT : Ground truth, must be binary (1 = regions of interest 0 = background)
    # option = 'contour' For contour plotting
    # option = 'region' For color the region

    Image = cv2.cvtColor(np.array(Image, np.uint8), cv2.COLOR_GRAY2RGB)
    GT = np.array(255*GT, dtype=np.uint8)
    Seg = np.array(255*Seg, dtype=np.uint8)
    GT = cv2.cvtColor(GT, cv2.COLOR_GRAY2RGB)
    Seg = cv2.cvtColor(Seg, cv2.COLOR_GRAY2RGB)

    if option == 'region':
        GT[:, :, 1:2] = 0*GT[:, :, 1:2]
        Seg[:, :, 0] = 0*Seg[:, :, 0]
        Seg[:, :, 2] = 0*Seg[:, :, 2]

        VIS_Seg = cv2.addWeighted(Image, 1, Seg, 0.5, 0)
        VIS_GT = cv2.addWeighted(Image, 1, GT, 0.5, 0)

    elif option == 'contour':

        contours_GT = cv2.Canny(GT, 250, 260)
        contours_Seg = cv2.Canny(Seg, 250, 260)

        contours_GT = cv2.cvtColor(contours_GT, cv2.COLOR_GRAY2RGB)
        contours_Seg = cv2.cvtColor(contours_Seg, cv2.COLOR_GRAY2RGB)

        contours_GT[:, :, 1:2] = 0*contours_GT[:, :, 1:2]
        contours_Seg[:, :, 0] = 0*contours_Seg[:, :, 0]
        contours_Seg[:, :, 2] = 0*contours_Seg[:, :, 2]

        VIS_Seg = cv2.addWeighted(Image, 1, contours_Seg, 0.5, 0)
        VIS_GT = cv2.addWeighted(Image, 1, contours_GT, 0.5, 0)

    return VIS_Seg,VIS_GT

dir_img = "Test_Data/Images/"
dir_mask = "Test_Data/Vts/"
Eval = []

Dice = []
TP = []
FP = []

width=512
height=512
channels=3

for i in os.listdir(dir_img):
    Image_Test = cv2.resize(cv2.imread(dir_img+i), (width, height))/255
    Image = cv2.resize(cv2.imread(dir_img+i), (width, height))[:,:,2]
    VT=cv2.resize(cv2.imread(dir_mask+i), (width, height))[:,:,2]
    VT=(VT==255).astype(int)

    Image_Test = np.expand_dims(Image_Test, axis=0)
    Seg = model.predict(Image_Test)
    Seg = ((Seg[0,:,:,0]*255)>5).astype(int)

    Eval.append(SEG_EVAL(Seg,VT))

    VIS_Seg,VIS_GT=VIS_EVAL(Image, Seg, VT, option = 'contour')
    cv2.imwrite('CNN_Results/Seg_'+i, VIS_Seg)
    cv2.imwrite('CNN_Results/GT_'+i, VIS_GT)
    #cv2.imwrite('FPN_Results/Mask_Seg_'+i, Seg)

np.savetxt("CNN_Results.csv", Eval, delimiter=",")


最后，将评估结果保存到CSV文件中。

网络结构如下图所示：
