使用flink过滤日志数据中的脏数据非JSON格式的字符串并提取ts字段作为最大时间戳生成水位线最大乱序程度为5秒

假设我们的日志数据格式为JSON字符串，包含字段"ts"表示时间戳。可以使用Flink的JSON解析器来解析JSON数据，并过滤掉非法数据。代码示例如下：

import org.apache.flink.api.common.functions.FilterFunction;
import org.apache.flink.api.common.functions.MapFunction;
import org.apache.flink.api.common.serialization.SimpleStringSchema;
import org.apache.flink.api.java.utils.ParameterTool;
import org.apache.flink.streaming.api.TimeCharacteristic;
import org.apache.flink.streaming.api.datastream.DataStream;
import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
import org.apache.flink.streaming.api.functions.AssignerWithPeriodicWatermarks;
import org.apache.flink.streaming.api.functions.timestamps.BoundedOutOfOrdernessTimestampExtractor;
import org.apache.flink.streaming.api.watermark.Watermark;
import org.apache.flink.streaming.connectors.kafka.FlinkKafkaConsumer;
import org.apache.flink.streaming.connectors.kafka.FlinkKafkaProducer;
import org.apache.flink.streaming.util.serialization.JSONKeyValueDeserializationSchema;
import org.apache.flink.util.StringUtils;

import javax.annotation.Nullable;
import java.text.SimpleDateFormat;
import java.util.Date;
import java.util.Properties;

public class LogFilter {
    public static void main(String[] args) throws Exception {
        final ParameterTool params = ParameterTool.fromArgs(args);
        final StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();

        env.setStreamTimeCharacteristic(TimeCharacteristic.EventTime);

        Properties kafkaProps = new Properties();
        kafkaProps.setProperty("bootstrap.servers", params.get("bootstrap.servers", "localhost:9092"));
        kafkaProps.setProperty("group.id", params.get("group.id", "flink-log-filter"));

        FlinkKafkaConsumer<String> kafkaConsumer = new FlinkKafkaConsumer<>(
                params.get("input.topic", "log-topic"),
                new SimpleStringSchema(),
                kafkaProps);

        DataStream<String> logStream = env
                .addSource(kafkaConsumer)
                .filter(new FilterFunction<String>() {
                    @Override
                    public boolean filter(String value) throws Exception {
                        try {
                            // 尝试解析为JSON对象
                            JSONObject json = new JSONObject(value);
                            // 判断是否包含ts字段
                            return json.has("ts");
                        } catch (JSONException e) {
                            // 解析失败，说明不是JSON格式的字符串
                            return false;
                        }
                    }
                });

        // 提取时间戳，并生成Watermark
        DataStream<String> timestampedStream = logStream
                .map(new MapFunction<String, Tuple2<Long, String>>() {
                    @Override
                    public Tuple2<Long, String> map(String value) throws Exception {
                        JSONObject json = new JSONObject(value);
                        long ts = json.getLong("ts");
                        return Tuple2.of(ts, value);
                    }
                })
                .assignTimestampsAndWatermarks(new BoundedOutOfOrdernessTimestampExtractor<Tuple2<Long, String>>(Time.seconds(5)) {
                    @Override
                    public long extractTimestamp(Tuple2<Long, String> element) {
                        return element.f0;
                    }
                })
                .map(new MapFunction<Tuple2<Long, String>, String>() {
                    @Override
                    public String map(Tuple2<Long, String> value) throws Exception {
                        return value.f1;
                    }
                });

        // 输出到Kafka
        FlinkKafkaProducer<String> kafkaProducer = new FlinkKafkaProducer<>(
                params.get("output.topic", "filtered-log-topic"),
                new SimpleStringSchema(),
                kafkaProps);

        timestampedStream.addSink(kafkaProducer);

        env.execute("LogFilter");
    }
}

在代码中，我们使用了Flink的JSON解析器org.apache.flink.shaded.jackson2.com.fasterxml.jackson.databind.JsonNode来解析JSON字符串，判断是否包含"ts"字段。如果解析失败，说明该字符串不是一个合法的JSON格式，就过滤掉。

接着，我们使用map操作提取出时间戳，并使用assignTimestampsAndWatermarks操作生成Watermark。其中，我们使用了BoundedOutOfOrdernessTimestampExtractor作为时间戳分配器，设置最大乱序程度为5秒。

最后，我们将过滤后的日志数据输出到Kafka中
