msp430f5529uart通讯协议接收到字符串0x55 0xfd 0xaa 0x00 0x02 0x61 0x01 0x62并将这几个字符储存到一个数组里

以下是一个示例代码，可以实现msp430f5529的UART通讯协议接收到字符串“0x55 0xfd 0xaa 0x00 0x02 0x61 0x01 0x62”并将这几个字符储存到一个数组里：

#include <msp430.h>

#define BUFFER_SIZE 8

volatile unsigned char buffer[BUFFER_SIZE];
volatile unsigned int buffer_index = 0;

int main(void) {
    WDTCTL = WDTPW | WDTHOLD;   // stop watchdog timer
    PM5CTL0 &= ~LOCKLPM5;       // disable the GPIO power-on default high-impedance mode

    // configure UART
    P3SEL1 |= BIT4 | BIT5;      // configure P3.4 and P3.5 as UART pins
    P3SEL0 &= ~(BIT4 | BIT5);
    UCA0CTLW0 |= UCSWRST;       // put UART in reset mode
    UCA0CTLW0 |= UCSSEL__SMCLK; // select SMCLK as clock source
    UCA0BRW = 52;               // set baud rate to 9600
    UCA0MCTLW = UCBRS_1 | UCBRF_0 | UCOS16;
    UCA0CTLW0 &= ~UCSWRST;      // release UART from reset mode
    UCA0IE |= UCRXIE;           // enable UART receive interrupt

    __bis_SR_register(LPM0_bits | GIE); // enter low power mode 0 with interrupts enabled

    return 0;
}

#pragma vector=USCI_A0_VECTOR
__interrupt void USCI_A0_ISR(void) {
    switch(__even_in_range(UCA0IV, USCI_UART_UCTXCPTIFG)) {
        case USCI_NONE: break;           // no interrupt
        case USCI_UART_UCRXIFG:          // receive interrupt
            buffer[buffer_index++] = UCA0RXBUF; // store received byte in buffer
            if (buffer_index == BUFFER_SIZE) {  // buffer full
                buffer_index = 0;               // reset buffer index
                // process received data here
            }
            break;
        case USCI_UART_UCTXIFG: break;   // transmit interrupt
        case USCI_UART_UCSTTIFG: break;  // start bit interrupt
        case USCI_UART_UCTXCPTIFG: break; // transmit complete interrupt
    }
}

在上面的代码中，我们首先配置了UART接口，然后启用了接收中断。在接收中断处理函数中，我们将接收到的字节存储到一个数组中，并在数组填满后进行数据处理。在这个例子中，我们只是简单地将接收到的数据存储到数组中，没有进行进一步的处理。如果你需要对接收到的数据进行解析，你需要编写相应的解析代码
