智能家居状态监控系统 - 数据库设计与实现

数据库设计:

  • 用户表 (users):
CREATE TABLE IF NOT EXISTS users (
    uid INTEGER PRIMARY KEY AUTOINCREMENT,
    username varchar(10),
    passwd varchar(10)
);
  • 智能家居状态表 (Status):
CREATE TABLE IF NOT EXISTS Status (
    sid INTEGER PRIMARY KEY AUTOINCREMENT,
    uid INTEGER ,
    device_name varchar(10),
    device_state varchar(10),
    value varchar(10),
    mode varchar(10),
    FOREIGN KEY (uid) REFERENCES users (uid)
);

服务端代码:

#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <unistd.h>
#include <sys/socket.h>
#include <arpa/inet.h>
#include <sqlite3.h>

#define MAX_BUFFER_SIZE 1024

typedef struct {
    int uid;
    char device_name[10];
    char device_state[10];
    char value[10];
    char mode[10];
} Status;

typedef struct {
    int sockfd;
    struct sockaddr_in client_addr;
    socklen_t client_addr_len;
    sqlite3 *db;
} ServerContext;

void handleClientRequest(ServerContext *context) {
    char buffer[MAX_BUFFER_SIZE];
    int userid;

    // 接收客户端发送的userid
    ssize_t recvSize = recv(context->sockfd, &userid, sizeof(int), 0);
    if (recvSize == -1) {
        perror('userid接受失败\nrecv');
        return;
    }
    printf('客户端已连接\n');

    // 查询数据库获取设备状态信息
    char sql[100];
    snprintf(sql, sizeof(sql), 'SELECT * FROM Status WHERE uid = %d', userid);
    sqlite3_stmt *stmt;
    int rc = sqlite3_prepare_v2(context->db, sql, -1, &stmt, NULL);
    if (rc != SQLITE_OK) {
        fprintf(stderr, '无法执行的语句: %s\n', sqlite3_errmsg(context->db));
        return;
    }

    Status status;
    while (sqlite3_step(stmt) == SQLITE_ROW) {
        status.uid = sqlite3_column_int(stmt, 1);
        strncpy(status.device_name, sqlite3_column_text(stmt, 2), sizeof(status.device_name));
        strncpy(status.device_state, sqlite3_column_text(stmt, 3), sizeof(status.device_state));
        strncpy(status.value, sqlite3_column_text(stmt, 4), sizeof(status.value));
        strncpy(status.mode, sqlite3_column_text(stmt, 5), sizeof(status.mode));
    }
    sqlite3_finalize(stmt);

    // 分析设备状态并生成建议
    char suggestion[MAX_BUFFER_SIZE];
    if (strcmp(status.device_name, '空调') == 0) {
        int temperature = atoi(status.value);
        if (temperature < 24) {
            snprintf(suggestion, sizeof(suggestion), '空调温度过低，建议提高温度至26℃');
        } else {
            snprintf(suggestion, sizeof(suggestion), '空调温度正常');
        }
    } else if (strcmp(status.device_name, '加湿器') == 0) {
        int humidity = atoi(status.value);
        if (humidity < 40 || humidity > 70) {
            snprintf(suggestion, sizeof(suggestion), '加湿器湿度过高或过低，建议调整加湿器湿度');
        } else {
            snprintf(suggestion, sizeof(suggestion), '加湿器湿度正常');
        }
    } else {
        snprintf(suggestion, sizeof(suggestion), '设备状态未知');
    }

    // 向客户端发送建议
    ssize_t sendSize = send(context->sockfd, suggestion, strlen(suggestion), 0);
    if (sendSize == -1) {
        perror('发送失败\nsend');
        return;
    }
}

void handleClientConnection(ServerContext *context) {
    int clientSockfd = accept(context->sockfd, (struct sockaddr *)&context->client_addr, &context->client_addr_len);
    if (clientSockfd == -1) {
        perror('套接字接收失败\naccept');
        return;
    }

    ServerContext clientContext;
    clientContext.sockfd = clientSockfd;
    clientContext.client_addr_len = sizeof(clientContext.client_addr);
    clientContext.db = context->db;
    handleClientRequest(&clientContext);

    close(clientSockfd);
}

int main() {
    printf('正在连接中...\n');
    int sockfd = socket(AF_INET, SOCK_STREAM, 0);
    if (sockfd == -1) {
        perror('连接失败\nsocket');
        return 1;
    }

    struct sockaddr_in server_addr;
    server_addr.sin_family = AF_INET;
    server_addr.sin_addr.s_addr = INADDR_ANY;
    server_addr.sin_port = htons(12345);

    if (bind(sockfd, (struct sockaddr *)&server_addr, sizeof(server_addr)) == -1) {
        perror('连接失败\nbind');
        close(sockfd);
        return 1;
    }

    if (listen(sockfd, 5) == -1) {
        perror('连接失败\nlisten');
        close(sockfd);
        return 1;
    }


    sqlite3 *db;
    int rc = sqlite3_open('/mnt/g/Qt/Client/Smarthome_Client/database/database.db', &db);
    if (rc != SQLITE_OK) {
        fprintf(stderr, '数据库打开失败: %s\n', sqlite3_errmsg(db));
        return 1;
    }

    ServerContext context;
    context.sockfd = sockfd;
    context.client_addr_len = sizeof(context.client_addr);
    context.db = db;


    while (1) {
        sleep(1);
        handleClientConnection(&context);
    }

    sqlite3_close(db);
    close(sockfd);
    printf('服务器已关闭\n');

    return 0;
}

#include 'procession.h'
#include 'ui_procession.h'
#include <QAbstractSocket>
#include <QDebug>

Procession::Procession(int userid,QWidget *parent) :  QWidget(parent),  ui(new Ui::Procession),  userid(userid) {
    ui->setupUi(this);
    processionWidget();
    m_socket = new QTcpSocket(this);
    connect(ui->connectBtn, &QPushButton::clicked, this, &Procession::on_connectBtn_clicked);
    connect(m_socket, &QTcpSocket::readyRead, this, &Procession::readyRead);
    connect(m_socket, &QTcpSocket::connected, this, &Procession::connected);
    connect(m_socket, &QTcpSocket::disconnected,this,&Procession::disconnected);
    connect(m_socket, QOverload<QAbstractSocket::SocketError>::of(&QTcpSocket::error), this, &Procession::displayError);
}

Procession::~Procession() {
    delete ui;
}

void Procession::processionWidget() {
    setWindowTitle('服务器通信');
    setAutoFillBackground(true);
    QPalette palette=this->palette();
    QPixmap pixmap(':/user/image/image/net.jpg');
    palette.setBrush(QPalette::Window, QBrush(pixmap));
    setPalette(palette);
    setFixedSize(600,400);
}


void Procession::connected() {
    ui->message->append('连接成功');
    // 发送userid给服务器
    QByteArray block;
    QDataStream out(&block, QIODevice::WriteOnly);
    out << this->userid;
    if (m_socket->write(block) == -1) {
        ui->message->append('发送userid失败');
        m_socket->close();
    }
}

void Procession::disconnected() {
    ui->message->append('连接失败');
    m_socket->close();
}

void Procession::readyRead() {
    QByteArray data = m_socket->readAll();
    if (data.isEmpty()) {
        ui->message->append('读取的数据为空');
        return;
    }
    // 解析服务器返回的数据
    QDataStream in(&data, QIODevice::ReadOnly);
    QString suggestion;
    in >> suggestion; // 使用重载的 >> 运算符来读取数据
    if (in.status() != QDataStream::Ok) {
        ui->message->append('解析服务器返回的数据失败');
        return;
    }
    ui->message->append(suggestion);
    m_socket->close();
}

void Procession::displayError(QAbstractSocket::SocketError error) {
    QString errorMessage;
    switch (error) {
    case QAbstractSocket::ConnectionRefusedError:
        errorMessage = '连接被拒绝';
        break;
    case QAbstractSocket::RemoteHostClosedError:
        errorMessage = '远程主机关闭';
        break;
    case QAbstractSocket::HostNotFoundError:
        errorMessage = '未找到主机';
        break;
    case QAbstractSocket::SocketTimeoutError:
        errorMessage = '连接超时';
        break;
    case QAbstractSocket::NetworkError:
        errorMessage = '网络错误';
        break;
    default:
        errorMessage = '未知错误';
        break;
    }
    ui->message->append('连接失败：' + errorMessage);
}

void Procession::on_connectBtn_clicked() {
    if (m_socket->state() == QAbstractSocket::ConnectedState) {
        m_socket->disconnectFromHost(); // 先关闭套接字
    }
    ui->message->append('已经连接上服务器');
    QString ip = ui->IP->text();
    QString port = ui->port->text();

    if (ip.isEmpty() || port.isEmpty()) {
        ui->message->clear();
        ui->message->append('请输入有效的IP地址和端口号');
        return;
    }

    ui->message->clear();
    ui->message->append('正在连接中...');
    m_socket->connectToHost(ip, static_cast<quint16>(ui->port->text().toInt()));
}

客户端代码逻辑:

  1. 客户端程序创建QTcpSocket对象，并连接到服务端的IP地址和端口。
  2. 连接成功后，客户端向服务器发送用户的ID。
  3. 客户端接收服务器返回的设备状态信息，并解析数据。
  4. 客户端显示解析后的设备状态信息。

问题分析:

客户端输出'QAbstractSocket::connectToHost() called when already looking up or connecting/connected to '127.0.0.1''错误的原因是，在连接之前，客户端的QTcpSocket对象已经处于连接状态，而connectToHost()函数不允许在连接状态下调用。

解决方案:

在客户端的on_connectBtn_clicked()函数中添加判断语句，如果套接字的状态为ConnectedState，则先调用disconnectFromHost()函数断开连接，然后再进行连接操作。

修改后的代码:

void Procession::on_connectBtn_clicked() {
    if (m_socket->state() == QAbstractSocket::ConnectedState) {
        m_socket->disconnectFromHost(); // 先关闭套接字
    }
    ui->message->append('已经连接上服务器');
    QString ip = ui->IP->text();
    QString port = ui->port->text();

    if (ip.isEmpty() || port.isEmpty()) {
        ui->message->clear();
        ui->message->append('请输入有效的IP地址和端口号');
        return;
    }

    ui->message->clear();
    ui->message->append('正在连接中...');
    m_socket->connectToHost(ip, static_cast<quint16>(ui->port->text().toInt()));
}

代码逻辑:

  1. 客户端程序创建QTcpSocket对象，并连接到服务端的IP地址和端口。
  2. 连接成功后，客户端向服务器发送用户的ID。
  3. 客户端接收服务器返回的设备状态信息，并解析数据。
  4. 客户端显示解析后的设备状态信息。

修改后的代码解决了连接错误，并实现了客户端和服务端的通信功能。
