1. 引入ESRI.ArcGIS.Geoprocessor库和ESRI.ArcGIS.DataSourcesRaster库。
  2. 创建一个Geoprocessor对象和一个RasterMapAlgebraOp对象。
  3. 调用RasterMapAlgebraOp对象的BindRaster方法,将需要进行栅格计算的栅格数据绑定到RasterMapAlgebraOp对象上。
  4. 构建栅格计算表达式,使用IMapAlgebraOp接口中的方法进行计算。
  5. 调用RasterMapAlgebraOp对象的Execute方法,将计算结果保存到输出栅格数据中。
  6. 将输出栅格数据添加到MapControl中显示。

具体流程:

  1. 首先,我们需要在代码文件的开头引入ESRI.ArcGIS.Geoprocessor库和ESRI.ArcGIS.DataSourcesRaster库。这两个库中包含了进行栅格计算所需的类和接口。
using ESRI.ArcGIS.Geoprocessor;
using ESRI.ArcGIS.DataSourcesRaster;
  1. 创建一个Geoprocessor对象和一个RasterMapAlgebraOp对象。Geoprocessor对象用于执行各种地理处理操作,而RasterMapAlgebraOp对象用于进行栅格计算。
Geoprocessor gp = new Geoprocessor();
RasterMapAlgebraOp rasterMapAlgebraOp = new RasterMapAlgebraOp();
  1. 调用RasterMapAlgebraOp对象的BindRaster方法,将需要进行栅格计算的栅格数据绑定到RasterMapAlgebraOp对象上。这里假设我们有三个栅格数据需要进行计算,分别为raster1、raster2和raster3。我们可以将它们绑定到RasterMapAlgebraOp对象上:
rasterMapAlgebraOp.BindRaster(raster1, "raster1");
rasterMapAlgebraOp.BindRaster(raster2, "raster2");
rasterMapAlgebraOp.BindRaster(raster3, "raster3");
  1. 构建栅格计算表达式,使用IMapAlgebraOp接口中的方法进行计算。这里我们假设要计算三个栅格数据的平均值,表达式为"(raster1 + raster2 + raster3) / 3"。我们可以使用IMapAlgebraOp中的方法构建表达式:
IMapAlgebraOp mapAlgebraOp = rasterMapAlgebraOp as IMapAlgebraOp;
string expression = "(raster1 + raster2 + raster3) / 3";
object rasOut = mapAlgebraOp.Execute(expression);
  1. 调用RasterMapAlgebraOp对象的Execute方法,将计算结果保存到输出栅格数据中。这里我们可以指定输出栅格数据的名称和路径:
string outRaster = @"C:\output_raster.tif";
rasterMapAlgebraOp.Execute(outRaster);
  1. 将输出栅格数据添加到MapControl中显示。首先需要通过IRasterLayer接口创建一个RasterLayer对象,然后将它添加到MapControl中:
IRasterLayer rasterLayer = new RasterLayerClass();
rasterLayer.CreateFromFilePath(outRaster);
mapControl.AddLayer(rasterLayer);

至此,多个栅格数据的栅格计算并将结果显示在MapControl中的流程就完成了

C#中使用IMapAlgebraOp接口和RasterMapAlgebraOp类进行多个栅格数据的栅格计算并将结果显示在mapcontorl中的具体流程用文字详细的描述这一过程
