Due to the fact that the smaller the diameter of the ceramic reflector, the higher the absorption efficiency of the crystal [15], we have reduced the inner diameter of the reflector to a minimum of 8mm while ensuring the cooling effect of the crystal. Meanwhile, the inner diameter of the glass tube is designed to be 6mm. As a result, the distance between the LD emission surface and the crystal axis is only 6mm, which enables a higher pumping light power density in the crystal rod and facilitates high-power laser output.

由于陶瓷反射器的直径越小,晶体的吸收效率越高[15],因此我们在保证晶体冷却效果的前提下,将反射器的内径缩短至最小的8mm,同时将玻璃管的内径设计为6mm。这样,LD发光面到晶体轴中心的距离仅为6mm,能够在晶体棒中获得较高的抽运光功率密度,有利于实现高功率激光输出
