编写一个完整的驱动程序 Hi3521DV100芯片接收BT1120输入配置GPIO1_7为输入写入VI_DATA0配置GPIO1_6为输入写入VI_DATA1
以下是一个简单的驱动程序示例,用于Hi3521DV100芯片接收BT1120输入。此程序将配置GPIO1_7为输入,将数据写入VI_DATA0,配置GPIO1_6为输入,将数据写入VI_DATA1。
#include <linux/module.h>
#include <linux/init.h>
#include <linux/platform_device.h>
#include <linux/io.h>
#define GPIO1_BASE_ADDR 0x20140000
#define GPIO1_DIR_OFFSET 0x400
#define GPIO1_DATA_OFFSET 0x200
static int hi3521bt1120_probe(struct platform_device *pdev)
{
void __iomem *gpio1_base;
u32 gpio1_dir, gpio1_data;
// Map GPIO1 registers to virtual memory
gpio1_base = ioremap(GPIO1_BASE_ADDR, SZ_4K);
if (!gpio1_base) {
pr_err("Failed to map GPIO1 registers\n");
return -ENOMEM;
}
// Configure GPIO1_7 as input and write data to VI_DATA0
gpio1_dir = readl(gpio1_base + GPIO1_DIR_OFFSET);
gpio1_dir &= ~(1 << 7); // set bit 7 to 0 (input)
writel(gpio1_dir, gpio1_base + GPIO1_DIR_OFFSET);
gpio1_data = readl(gpio1_base + GPIO1_DATA_OFFSET);
gpio1_data |= (1 << 0); // set bit 0 to 1 (VI_DATA0)
writel(gpio1_data, gpio1_base + GPIO1_DATA_OFFSET);
// Configure GPIO1_6 as input and write data to VI_DATA1
gpio1_dir &= ~(1 << 6); // set bit 6 to 0 (input)
writel(gpio1_dir, gpio1_base + GPIO1_DIR_OFFSET);
gpio1_data = readl(gpio1_base + GPIO1_DATA_OFFSET);
gpio1_data |= (1 << 1); // set bit 1 to 1 (VI_DATA1)
writel(gpio1_data, gpio1_base + GPIO1_DATA_OFFSET);
iounmap(gpio1_base);
return 0;
}
static int hi3521bt1120_remove(struct platform_device *pdev)
{
return 0;
}
static struct platform_driver hi3521bt1120_driver = {
.driver = {
.name = "hi3521bt1120",
},
.probe = hi3521bt1120_probe,
.remove = hi3521bt1120_remove,
};
module_platform_driver(hi3521bt1120_driver);
MODULE_LICENSE("GPL");
MODULE_AUTHOR("Your Name");
MODULE_DESCRIPTION("Hi3521DV100 BT1120 Driver");
此驱动程序使用ioremap()函数将GPIO1寄存器映射到虚拟内存中,然后使用readl()和writel()函数读写GPIO1寄存器。首先,将GPIO1_7配置为输入并将数据写入VI_DATA0,然后将GPIO1_6配置为输入并将数据写入VI_DATA1。最后,使用iounmap()函数解除GPIO1寄存器的映射
