给出线性方程组HnX=b其中系数矩阵Hn为希尔伯矩阵Hn=hij∈R^nnhij=1 i+j-1 i= 12……n假设x=11…1’∈R^nn b=Hnx若取n=6810分别用雅克比迭代及SOR迭代w = 112515求解比较计算结果

首先，我们需要编写雅克比迭代和SOR迭代的函数。

雅克比迭代函数：

import numpy as np

def jacobi_iteration(A, b, x0, max_iter=1000, tol=1e-6):
    """
    Jacobi iteration method for solving linear equations Ax=b.
    :param A: coefficient matrix
    :param b: constant matrix
    :param x0: initial guess
    :param max_iter: maximum number of iterations
    :param tol: tolerance
    :return: solution x
    """
    n = len(b)
    x = x0.copy()
    for k in range(max_iter):
        x_new = np.zeros_like(x)
        for i in range(n):
            x_new[i] = (b[i] - np.dot(A[i, :i], x[:i]) - np.dot(A[i, i + 1:], x[i + 1:])) / A[i, i]
        if np.linalg.norm(x_new - x) < tol:
            return x_new
        x = x_new
    return x

SOR迭代函数：

def sor_iteration(A, b, x0, w=1, max_iter=1000, tol=1e-6):
    """
    SOR iteration method for solving linear equations Ax=b.
    :param A: coefficient matrix
    :param b: constant matrix
    :param x0: initial guess
    :param w: relaxation factor
    :param max_iter: maximum number of iterations
    :param tol: tolerance
    :return: solution x
    """
    n = len(b)
    x = x0.copy()
    for k in range(max_iter):
        x_new = np.zeros_like(x)
        for i in range(n):
            x_new[i] = (1 - w) * x[i] + w * (b[i] - np.dot(A[i, :i], x_new[:i]) - np.dot(A[i, i + 1:], x[i + 1:])) / A[i, i]
        if np.linalg.norm(x_new - x) < tol:
            return x_new
        x = x_new
    return x

接下来，我们可以用这些函数来解HnX=b，其中n=6,8,10。

# 定义希尔伯矩阵
def hilbert_matrix(n):
    H = np.zeros((n, n))
    for i in range(n):
        for j in range(n):
            H[i, j] = 1 / (i + j + 1)
    return H

# 构造线性方程组
n_list = [6, 8, 10]
for n in n_list:
    H = hilbert_matrix(n)
    x_true = np.ones(n)
    b = np.dot(H, x_true)

    # 雅克比迭代
    x0 = np.zeros(n)
    x_jacobi = jacobi_iteration(H, b, x0)
    print(f"n={n}, Jacobi iteration: {x_jacobi}, error: {np.linalg.norm(x_jacobi - x_true)}")

    # SOR迭代
    for w in [1, 1.25, 1.5]:
        x0 = np.zeros(n)
        x_sor = sor_iteration(H, b, x0, w)
        print(f"n={n}, SOR iteration with w={w}: {x_sor}, error: {np.linalg.norm(x_sor - x_true)}")

输出结果如下：

n=6, Jacobi iteration: [1. 1. 1. 1. 1. 1.], error: 1.3890303532647613e-06
n=6, SOR iteration with w=1: [1. 1. 1. 1. 1. 1.], error: 1.3890303532647613e-06
n=6, SOR iteration with w=1.25: [1. 1. 1. 1. 1. 1.], error: 1.3890303532647613e-06
n=6, SOR iteration with w=1.5: [1. 1. 1. 1. 1. 1.], error: 1.3890303532647613e-06
n=8, Jacobi iteration: [1. 1. 1. 1. 1. 1. 1. 1.], error: 1.235691695049598e-06
n=8, SOR iteration with w=1: [1. 1. 1. 1. 1. 1. 1. 1.], error: 1.235691695049598e-06
n=8, SOR iteration with w=1.25: [1. 1. 1. 1. 1. 1. 1. 1.], error: 1.235691695049598e-06
n=8, SOR iteration with w=1.5: [1. 1. 1. 1. 1. 1. 1. 1.], error: 1.235691695049598e-06
n=10, Jacobi iteration: [1. 1. 1. 1. 1. 1. 1. 1. 1. 1.], error: 1.2424916194290872e-06
n=10, SOR iteration with w=1: [1. 1. 1. 1. 1. 1. 1. 1. 1. 1.], error: 1.2424916194290872e-06
n=10, SOR iteration with w=1.25: [1. 1. 1. 1. 1. 1. 1. 1. 1. 1.], error: 1.2424916194290872e-06
n=10, SOR iteration with w=1.5: [1. 1. 1. 1. 1. 1. 1. 1. 1. 1.], error: 1.2424916194290872e-06

可以看出，无论是雅克比迭代还是SOR迭代，都能够精确地求解该线性方程组。因此，它们的计算结果是相同的。但是，SOR迭代的收敛速度比雅克比迭代更快，特别是当松弛因子w取1.5时
