事件,可以在这个View上添加其他控件或者绘制自定义图形。

具体实现步骤如下:

  1. 创建一个自定义View,继承自View或者其子类,比如RelativeLayout、FrameLayout等。

  2. 在构造方法中设置View的背景为透明,可以使用setBackgroundColor(Color.TRANSPARENT)方法实现。

  3. 重写onMeasure方法,设置View的宽高,可以使用MeasureSpec.EXACTLY或者MeasureSpec.AT_MOST等模式。

  4. 重写onTouchEvent方法,监听触摸事件,可以使用MotionEvent.ACTION_DOWN、MotionEvent.ACTION_MOVE和MotionEvent.ACTION_UP等事件。

  5. 在View中添加其他控件或者绘制自定义图形,可以在onDraw方法中实现。

  6. 将自定义View添加到Activity中,可以使用addView方法或者在xml布局文件中引入。

示例代码如下:

public class TransparentView extends View {

    public TransparentView(Context context) {
        super(context);
        init();
    }

    public TransparentView(Context context, AttributeSet attrs) {
        super(context, attrs);
        init();
    }

    public TransparentView(Context context, AttributeSet attrs, int defStyleAttr) {
        super(context, attrs, defStyleAttr);
        init();
    }

    private void init() {
        setBackgroundColor(Color.TRANSPARENT);
    }

    @Override
    protected void onMeasure(int widthMeasureSpec, int heightMeasureSpec) {
        int widthMode = MeasureSpec.getMode(widthMeasureSpec);
        int widthSize = MeasureSpec.getSize(widthMeasureSpec);
        int heightMode = MeasureSpec.getMode(heightMeasureSpec);
        int heightSize = MeasureSpec.getSize(heightMeasureSpec);

        int width = 0;
        int height = 0;

        if (widthMode == MeasureSpec.EXACTLY) {
            width = widthSize;
        } else if (widthMode == MeasureSpec.AT_MOST) {
            width = Math.min(width, widthSize);
        }

        if (heightMode == MeasureSpec.EXACTLY) {
            height = heightSize;
        } else if (heightMode == MeasureSpec.AT_MOST) {
            height = Math.min(height, heightSize);
        }

        setMeasuredDimension(width, height);
    }

    @Override
    public boolean onTouchEvent(MotionEvent event) {
        int action = event.getAction();
        switch (action) {
            case MotionEvent.ACTION_DOWN:
                // 处理按下事件
                break;
            case MotionEvent.ACTION_MOVE:
                // 处理移动事件
                break;
            case MotionEvent.ACTION_UP:
                // 处理抬起事件
                break;
        }
        return true;
    }

    @Override
    protected void onDraw(Canvas canvas) {
        super.onDraw(canvas);
        // 绘制自定义图形或者添加其他控件
    }
}

将自定义View添加到Activity中的示例代码如下:

public class MainActivity extends AppCompatActivity {

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        TransparentView transparentView = new TransparentView(this);
        transparentView.setLayoutParams(new ViewGroup.LayoutParams(ViewGroup.LayoutParams.MATCH_PARENT, ViewGroup.LayoutParams.MATCH_PARENT));
        ((FrameLayout) findViewById(R.id.container)).addView(transparentView);
    }
}

在xml布局文件中引入自定义View的示例代码如下:

<FrameLayout
    android:id="@+id/container"
    android:layout_width="match_parent"
    android:layout_height="match_parent">

    <com.example.TransparentView
        android:layout_width="match_parent"
        android:layout_height="match_parent" />

</FrameLayout>
``
我说的意思是 创建一个 透明View 设置View窗口大小 且可以触摸 且监听触摸
