Aircraft Fuel Supply System with Three Tanks By The MathWorks Inc The fuel supply system represented in the example consists of three tanks and an engine The engine is fed from the central tank while

The fuel levels in the three tanks are measured by respective sensors and the data is fed back to the control system. The control system regulates the pumping stations to ensure that the fuel level in the central tank remains within a desired range. The system also includes safety measures such as overflow valves to prevent fuel spills.

The model is implemented in Simulink, a simulation software tool, and can be used to study the dynamics of the fuel supply system under different operating conditions. For example, the system can be tested for its response to changes in engine demand, pump failures, or sensor errors.

Overall, the aircraft fuel supply system with three tanks is a complex system that requires careful design and testing to ensure safe and reliable operation. The Simulink model provides a useful tool for studying the system and identifying potential issues before they occur in real-world operation.
