CentOS7系统部署 ETCD 350 3个节点采用 tls并且再部署一个etcd UI管理请给出软件的下载地址和部署步骤及优化ETCD

下载ETCD 3.5.0：

官方下载地址：https://github.com/etcd-io/etcd/releases/tag/v3.5.0

部署ETCD 3.5.0：

步骤如下：

（1）安装etcd：

yum install etcd -y

（2）配置etcd：

在三台机器上，分别创建配置文件：

mkdir -p /etc/etcd/cert

# node1
cat > /etc/etcd/etcd.conf <<EOF
#[member]
ETCD_NAME="node1"
ETCD_DATA_DIR="/var/lib/etcd/default.etcd"
ETCD_LISTEN_PEER_URLS="https://192.168.1.11:2380"
ETCD_LISTEN_CLIENT_URLS="https://192.168.1.11:2379"

#[cluster]
ETCD_INITIAL_ADVERTISE_PEER_URLS="https://192.168.1.11:2380"
ETCD_INITIAL_CLUSTER="node1=https://192.168.1.11:2380,node2=https://192.168.1.12:2380,node3=https://192.168.1.13:2380"
ETCD_INITIAL_CLUSTER_STATE="new"
ETCD_INITIAL_CLUSTER_TOKEN="my-etcd-token"
ETCD_ADVERTISE_CLIENT_URLS="https://192.168.1.11:2379"
ETCD_CERT_FILE="/etc/etcd/cert/node1.pem"
ETCD_KEY_FILE="/etc/etcd/cert/node1-key.pem"
ETCD_TRUSTED_CA_FILE="/etc/etcd/cert/ca.pem"
EOF

# node2
cat > /etc/etcd/etcd.conf <<EOF
#[member]
ETCD_NAME="node2"
ETCD_DATA_DIR="/var/lib/etcd/default.etcd"
ETCD_LISTEN_PEER_URLS="https://192.168.1.12:2380"
ETCD_LISTEN_CLIENT_URLS="https://192.168.1.12:2379"

#[cluster]
ETCD_INITIAL_ADVERTISE_PEER_URLS="https://192.168.1.12:2380"
ETCD_INITIAL_CLUSTER="node1=https://192.168.1.11:2380,node2=https://192.168.1.12:2380,node3=https://192.168.1.13:2380"
ETCD_INITIAL_CLUSTER_STATE="new"
ETCD_INITIAL_CLUSTER_TOKEN="my-etcd-token"
ETCD_ADVERTISE_CLIENT_URLS="https://192.168.1.12:2379"
ETCD_CERT_FILE="/etc/etcd/cert/node2.pem"
ETCD_KEY_FILE="/etc/etcd/cert/node2-key.pem"
ETCD_TRUSTED_CA_FILE="/etc/etcd/cert/ca.pem"
EOF

# node3
cat > /etc/etcd/etcd.conf <<EOF
#[member]
ETCD_NAME="node3"
ETCD_DATA_DIR="/var/lib/etcd/default.etcd"
ETCD_LISTEN_PEER_URLS="https://192.168.1.13:2380"
ETCD_LISTEN_CLIENT_URLS="https://192.168.1.13:2379"

#[cluster]
ETCD_INITIAL_ADVERTISE_PEER_URLS="https://192.168.1.13:2380"
ETCD_INITIAL_CLUSTER="node1=https://192.168.1.11:2380,node2=https://192.168.1.12:2380,node3=https://192.168.1.13:2380"
ETCD_INITIAL_CLUSTER_STATE="new"
ETCD_INITIAL_CLUSTER_TOKEN="my-etcd-token"
ETCD_ADVERTISE_CLIENT_URLS="https://192.168.1.13:2379"
ETCD_CERT_FILE="/etc/etcd/cert/node3.pem"
ETCD_KEY_FILE="/etc/etcd/cert/node3-key.pem"
ETCD_TRUSTED_CA_FILE="/etc/etcd/cert/ca.pem"
EOF

（3）生成证书：

cd /etc/etcd/cert

# CA证书
cat > ca-config.json << EOF
{
    "signing": {
        "default": {
            "expiry": "87600h"
        },
        "profiles": {
            "server": {
                "expiry": "87600h",
                "usages": [
                    "signing",
                    "key encipherment",
                    "server auth"
                ]
            },
            "client": {
                "expiry": "87600h",
                "usages": [
                    "signing",
                    "key encipherment",
                    "client auth"
                ]
            },
            "peer": {
                "expiry": "87600h",
                "usages": [
                    "signing",
                    "key encipherment",
                    "server auth",
                    "client auth"
                ]
            }
        }
    }
}
EOF

cat > ca-csr.json << EOF
{
    "CN": "etcd-ca",
    "key": {
        "algo": "rsa",
        "size": 2048
    },
    "names": [
        {
            "C": "CN",
            "L": "Beijing",
            "O": "etcd",
            "OU": "etcd",
            "ST": "Beijing"
        }
    ]
}
EOF

cfssl gencert -initca ca-csr.json | cfssljson -bare ca

# 生成etcd证书
cat > etcd-csr.json << EOF
{
    "CN": "etcd",
    "hosts": [
        "127.0.0.1",
        "192.168.1.11",
        "192.168.1.12",
        "192.168.1.13"
    ],
    "key": {
        "algo": "rsa",
        "size": 2048
    },
    "names": [
        {
            "C": "CN",
            "L": "Beijing",
            "O": "etcd",
            "OU": "etcd",
            "ST": "Beijing"
        }
    ]
}
EOF

cfssl gencert -ca=ca.pem -ca-key=ca-key.pem -config=ca-config.json -profile=peer etcd-csr.json | cfssljson -bare etcd

（4）启动etcd：

在三台机器上，启动etcd：

systemctl daemon-reload
systemctl enable etcd
systemctl start etcd
systemctl status etcd

（5）检查etcd：

在一台机器上，使用etcdctl查看etcd集群状态：

ETCDCTL_API=3 etcdctl --endpoints=https://192.168.1.11:2379,https://192.168.1.12:2379,https://192.168.1.13:2379 --cacert=/etc/etcd/cert/ca.pem --cert=/etc/etcd/cert/node1.pem --key=/etc/etcd/cert/node1-key.pem endpoint health

部署ETCD UI管理：

步骤如下：

（1）下载etcd-ui：

git clone https://github.com/soyking/etcd-ui.git

（2）修改etcd-ui配置文件：

cd etcd-ui
cp config.sample.json config.json
vi config.json

修改config.json中的etcd地址和证书路径：

{
  "etcd": {
    "hosts": [
      "https://192.168.1.11:2379",
      "https://192.168.1.12:2379",
      "https://192.168.1.13:2379"
    ],
    "tls": {
      "cert": "/etc/etcd/cert/node1.pem",
      "key": "/etc/etcd/cert/node1-key.pem",
      "caCert": "/etc/etcd/cert/ca.pem"
    }
  },
  "port": 8000,
  "logLevel": "INFO"
}

（3）安装依赖：

npm install

（4）启动etcd-ui：

npm start

访问 http://your_ip:8000 即可。

优化ETCD：

（1）优化网络：

ETCD需要使用高速网络才能保证性能，建议使用千兆网卡或更高速的网络设备。

（2）优化存储：

ETCD的存储需要使用SSD或者NVMe等高速存储设备，可以使用RAID0或者分布式存储等方式提高性能。

（3）优化配置：

可以根据实际情况调整ETCD的配置，例如调整选举超时时间、心跳超时时间、最大请求大小等。

（4）监控和告警：

建议在ETCD集群中部署监控和告警系统，例如Prometheus、Grafana等，及时发现和解决问题。
