Instruction manual English versionThis operation instruction is supplied together with the ordered motor It has demonstrated the requirements and the cautions of the structure storage and transportati

irection is attached to the motor.1.5.2 The standard rotating direction is counterclockwise when viewed from the drive end.1.6 Insulation class and temperature riseThe standard insulation class is F, and the temperature rise is restricted to Class B.1.7 AltitudeThe motor can be operated at an altitude of not more than 1000m above sea level.1.8 Ambient temperatureThe motor can be operated under the ambient temperature of -15℃~40℃.1.9 HumidityThe relative humidity should not exceed 90% when the ambient temperature is 25℃.2 Structure and Installation2.1 StructureThe motor is composed of stator, rotor, bearing, end shield, fan and other parts. The frame is made of cast iron.2.2 InstallationBefore installation, please check the motor and make sure there is no damage during transportation. The motor should be installed horizontally on a solid and flat foundation. The installation surface should be clean and level. The motor should be fixed securely with bolts. The installation should follow the requirements of the outline drawing. The motor should be equipped with a suitable coupling and protection device. The motor should be connected to the power supply according to the wiring diagram.3 Operation and Maintenance3.1 OperationThe motor should be operated under the rated voltage and frequency. The motor should be operated under the rated load and the rated ambient temperature. The motor should be operated in a clean and dry environment. The motor should be operated according to the operating procedures.3.2 MaintenanceThe motor should be maintained regularly according to the maintenance procedures. The motor should be cleaned regularly. The bearing should be lubricated regularly. The motor should be inspected regularly. The motor should be repaired by professional technicians when necessary.4 Caution4.1 SafetyThe motor should be operated and maintained by authorized personnel only. The motor should be disconnected from the power supply before any maintenance or repair. The motor should be protected by suitable protection devices.4.2 Environmental protectionThe motor should be disposed of properly when it is no longer used. The motor should not be disposed of in nature.4.3 OthersThe motor should not be modified without the authorization of Xiangtan Electric Mfg. Group. Ltd. The motor should not be used for any purposes other than the designed purposes. The motor should not be overloaded. The motor should not be exposed to any chemicals or corrosive substances.5 WarrantyXiangtan Mfg. Group Ltd. warrants the motor against defects in materials and workmanship for a period of one year from the date of delivery. The warranty does not cover damages caused by improper installation, operation or maintenance, or by any unauthorized modification or repair. The warranty is limited to the replacement or repair of the defective parts only. The warranty does not cover any consequential damages
